T90xr
pumped
electric shower
! IMPORTANT !
Under *NO circumstances must
this shower be connected directly
to a mains water supply.
It is designed for GRAVITY FED
COLD WATER systems ONLY !
*
Failure to comply may invalidate product warranty
Installation and
operating
instructions
I
nstallers please note these InstructIons are to be left wIth the user
2180574G
February 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T90xr and is the answer not in the manual?

Questions and answers

Related Manuals for Triton T90xr

Summary of Contents for Triton T90xr

  • Page 1 T90xr pumped electric shower ! IMPORTANT ! Under *NO circumstances must this shower be connected directly to a mains water supply. It is designed for GRAVITY FED COLD WATER systems ONLY ! Failure to comply may invalidate product warranty Installation and...

  • Page 2: Table Of Contents

    Instructions for installers and service engineers only ...... 19 Spare parts ..................20 Fault finding ................21 - 22 Guarantee, service policy, etc...........rear cover To check the product suitability for commercial and multiple installations, please contact Triton’s specification advisory service before installation. Telephone: 0844 980 0730...

  • Page 3: Important Safety Information

    T90xr pumped electric shower PLEASE READ THIS IMPORTANT SAFETY INFORMATION Products manufactured by Triton are safe and without risk provided they are installed, used and  maintained in good working order in accordance with our instructions and recommendations. WARNING: DO NOT operate shower if frozen, or suspected of being frozen. It must thaw out ...

  • Page 4: Introduction

    Meets with Compliance with European Introduction Community Directives (CE). This book contains all the necessary fitting and operating instructions for your Triton pumped ADVICE TO USERS electric shower. Take time to read this book Advice to users thoroughly and familiarise yourself with all The following points will help you understand instructions before installing.

  • Page 5: Main Components

    T90xr pumped electric shower MAIN COMPONENTS Main components Fig. NoTe: Not all wiring shown for reasons of clarity 157 mm 268 mm 49 mm 58 mm 330 mm Inside unit (fig.) 1. Top pipe / cable entry 16. Filter 2. Motor assembly 17.

  • Page 6: Electrical Requirements

    T90xr pumped electric shower ELECTRICAL REQUIREMENTS Shepperton Park, Triton Road, Nuneaton, Warwickshire, CV11 4NR WARNING! W-006-A THIS APPLIANCE MUST BE EARTHED The installation, supply cable and circuit protection must conform with BS 7671 (IEE Fig. wiring regulations) and be sufficient for the amperage required.
  • Page 7 For close circuit protection DO NOT use a above 30°C. Under these conditions, rewireable fuse. Instead use a suitably rated T90xr pumped electric shower derating factors apply and it is necessary to Miniature Circuit Breaker (MCB) or cartridge select a larger cable size.

  • Page 8: Water Requirements

    T90xr pumped electric shower WATeR ReQUIReMeNTS Minimum capacity 114 litres (25 gallons) Cold water WARNING! cistern Under no circumstances must this Mains electric supply Gate Stop (via double pole switch) valve valve shower be connected directly to the mains water supply.

  • Page 9: Siting Of The Shower

    T90xr pumped electric shower SITING oF THe SHoWeR WARNING! IMPORTANT: If installing onto a tiled wall The shower must not be positioned W-008-A always mount the unit on the surface of the where it will be subjected to freezing tiles. nEVER tile up to the unit.
  • Page 10 T90xr pumped electric shower The PRD is situated behind the outlet pipe Fig. (fig.). To access the PRD, FIRST SWITCH OFF THE ELECTRICITy SuPPLy, unscrew the hose then remove the cover. Remove the two screws holding the outlet pipe to the base of the can.

  • Page 11: Fitting The Shower To The Wall

    T90xr pumped electric shower FITTING THe SHoWeR To THe WALL Fig. Note: The control knobs are an integral part of the cover – DO nOT attempt to remove them. IMPORTANT: the unit must be mounted on a flat surface which covers the full width and length of the backplate.
  • Page 12 T90xr pumped electric shower After choosing the site for the shower, use the Fig. backplate as a template (fig.) and mark the four fixing holes 1, 3, 4 and 5. Note: If fixing to an installation with a top water entry point, mark the four fixing holes 2, 3, 4 and 5.

  • Page 13: Plumbing Connections

    T90xr pumped electric shower PLUMBING CoNNeCTIoNS WARNING! Plumbing to be carried out before wiring The outlet of the shower acts as a W-004-A DO nOT use jointing compounds on any pipe vent and MUST NOT be connected to fittings for the installation.

  • Page 14: Electrical Connections

    T90xr pumped electric shower eLeCTRICAL CoNNeCTIoNS Fig. SwItch off thE ElEctRIcIty SUPPly at thE maInS. Fig. shows a schematic wiring diagram. The cable entry points are shown in fig.. The cable can be surface clipped, hidden or via 20 mm conduit.

  • Page 15: Commissioning

    T90xr pumped electric shower CoMMISSIoNING Fig. WARNING! Do not switch on the electricity supply until the commissioning procedure has W-010-A been completed and the cover has been fitted. Failure to do so could cause the pump to run dry and invalidate the guarantee.
  • Page 16 T90xr pumped electric shower Note: Make sure the Start/Stop button is not depressed in the cover which indicates ‘ ’. The button should be flush with the start cover, otherwise water will flow as soon as the electricity is switched on.
  • Page 17 T90xr pumped electric shower Replace the cover as described above and Fig. permanently secure with the four retaining screws. IMPORTANT: take care to ensure that the four screws securing the cover are fully tightened – failure to do so may affect compliance with the IPX4 test.

  • Page 18: Operating The Shower

    T90xr pumped electric shower oPeRATING THe SHoWeR Fig. To start the shower WARNING! Pressing the Start/Stop button (fig.) switches Before normal operation of the on the pump, allowing water to immediately shower, it is essential that the flow through the unit.
  • Page 19 T90xr pumped electric shower To adjust the shower temperature WARNING! The shower temperature is altered by increasing After any servicing of mains water or decreasing the flow rate of the water through supply, always flush out the pipework the shower via the temperature control.

  • Page 20: Operating Functions

    CLeANING cleaning products when cleaning the shower as they may damage the unit. Triton Plc recommends that all products are cleaned using warm, soapy water. DO nOT use abrasive or aggressive chemical cleaning products as this may affect the product...

  • Page 21: Instructions For Installers And Service Engineers Only

    T90xr pumped electric shower INSTRUCTIONS FOR INSTALLERS AND SERVICE ENGINEERS ONLY Instructions for installers and service engineers only CLeANING THe FILTeR Fig. It is recommended that the filter is periodically cleaned in order to maintain the performance of the shower. It is essential that this operation is carried out by a competent person.

  • Page 22: Spare Parts

    T90xr pumped electric shower SPARE PARTS Spare parts Triton only supply spare parts for this model as illustrated. NO component of any assembly can be supplied separately. Pump and motor assembly Pipetrim Power selector P15211002 7053604 P15211000 Neon wiring harness...

  • Page 23: Fault Finding

    T90xr pumped electric shower FAULT FINdING IMPORTANT: Switch off the electricity at the mains supply and remove the circuit fuse before attempting any fault finding inside the unit. Problem/Symptom Cause Action/Cure 1 Shower 1.1 Interrupted power 1.1.1 Check if a general power cut. Check other inoperable, supply.

  • Page 24: Fault Finding

    T90xr pumped electric shower FAULT FINdING Problem/Symptom Cause Action/Cure 5 During use, the 5.1 Interrupted power 5.1.1 See 1.1.1 and 1.1.2. water flow ceases supply. abruptly. 5.2 Solenoid valve 5.2.1 Switch off immediately. Have solenoid malfunction (pump checked by a competent electrician or still operates).
  • Page 25 T90xr pumped electric shower...
  • Page 26 T90xr pumped electric shower...
  • Page 27 T90xr pumped electric shower...

  • Page 28: Service Policy

    Warwickshire CV11 4NR www.tritonshowers.co.uk Triton is a division of Norcros Group (Holdings) Limited e-mail: serviceenquiries@tritonshowers.co.uk Extended Warranty AVAILABLE NOW. Call 0844 980 0740 for more details. TRITON reserve the right to change product specification without prior notice. E&OA. © TRITON SHOWERS 2009...
