Triton T30IR INSTAFLOW Manual

Handwash
Hide thumbs Also See for T30IR INSTAFLOW:
Table of Contents

Advertisement

Quick Links

T30IR INSTAFLOW
H an d w ash
REGISTER ONLINE
ENTER A PRIZE DRAW
WIN
£100
LOVE2SHOP VOUCHERS
VISIT OUR WEBSITE TODAY
TRITONSHOWERS.CO.UK/REGISTER
THIS OFFER IS NOT VALID OUTSIDE THE UK
FOR YOUR SERVICE REFERENCE
NOTE DOWN THE PRODUCT CODE BELOW
(FROM THE FRONT OR TOP OF THE BOX)
ALTERNATIVELY REGISTER BY TEL: 024 7637 8321
INSTALLATION AND OPERATING INSTRUCTIONS
Please read this book thoroughly and familiarise yourself with all instructions before commencing
installation and keep it for future reference.
The handwash installation MUST be carried out by a suitably qualified person, in the sequence of
this instruction book.
Design registration:
006759700-0001 - 0004
IMPORTANT SAFETY ADVICE
The swivel arm supplied with this product is
a safety critical part of your shower. Failure to
use genuine Triton parts may cause injury and
2181600A - June 2020
100mm arm available
invalidate your guarantee.

Advertisement

Table of Contents
loading

Related Manuals for Triton T30IR INSTAFLOW

Summary of Contents for Triton T30IR INSTAFLOW

  • Page 1 The swivel arm supplied with this product is (FROM THE FRONT OR TOP OF THE BOX) a safety critical part of your shower. Failure to use genuine Triton parts may cause injury and invalidate your guarantee. ALTERNATIVELY REGISTER BY TEL: 024 7637 8321...
  • Page 2 INTRODUCTION - PLEASE READ PLEASE READ THIS IMPORTANT SAFETY INFORMATION Products manufactured by Triton are safe and without risk provided they are installed, used and maintained in good working order in accordance with our instructions and recommendations. ARNING: DO NOT operate handwash if frozen, or suspected of being frozen.
  • Page 3 To check the product suitability for commercial and multiple installations, please contact Triton’s speci cation advisory service before installation. Please see back of book for contact information.

  • Page 4: Important Safety Information & General Guidance Notes (Please Read) General Advice To Users Specification And Advice To Users

    INTRODUCTION ADVICE TO USERS This book contains all the necessary fitting and The following information will help you operation instructions for your T30IR Instaflow understand how the handwash product handwash. Please read carefully. operates. The installation must be carried out by a...

  • Page 5: Table Of Contents

    CONTENTS Page INTRODUCTION IMPORTANT SAFETY INFORMATION & GENERAL GUIDANCE NOTES (please read) GENERAL ADVICE TO USERS Specification and advice to users................4 Key to main components and entry points ............... 6 Electrical requirements ....................7 Water requirements ....................8 Siting of the unit ...................... 8 Fitting the unit to the wall ..................

  • Page 6: Key To Main Components And Entry Points

    MAIN COMPONENTS NOTE: Not all wiring is shown for reasons of clarity Entry Points Key: Water Entry Point Cable Entry Points Inside Unit 1. Terminal block 2. Cable clamp top 3. Cable clamp bottom 4. Mircoswitch 5. Stabiliser valve 6. Pressure Relief Device (PRD) 7.

  • Page 7: Electrical Requirements

    ELECTRICAL REQUIREMENTS Table A CIRCUIT PROTECTION WARNING! THIS APPLIANCE MUST BE EARTHED unit cartridge rating fuse The installation, supply cable and circuit 3.0kW – protection must conform with BS7671 (IEE wiring regulations) and be sufficient for the Table B amperage required. The following notes are for guidance only: Twin and earth PVC insulated cable The unit must only be connected to a...

  • Page 8: Water Requirements

    If it is intended to operate the unit at pressures supplies to the unit at the isolating switch and above the maximum or below the minimum stop valve. stated, contact Triton Customer Experience for Contact Triton Customer Experience for advice advice. on replacing the PRD.

  • Page 9: Fitting The Unit To The Wall

    FITTING THE UNIT TO THE WALL WARNING Pipe trims CHECK THERE ARE NO HIDDEN CABLES OR PIPES BEFORE DRILLING HOLES FOR WALL PLUGS. USE GREAT CARE WHEN USING POWER TOOLS NEAR WATER. THE USE OF A RESIDUAL CURRENT DEVICE (RCD) IS RECOMMENDED WHEN USING POWER TOOLS.

  • Page 10: Plumbing Connections

    PLUMBING CONNECTIONS Plumbing to be carried out before wiring. Filter DO NOT use jointing compounds on any pipe fittings for the installation. DO NOT use soldered fittings near the unit as heat can transfer along the pipe work and can damage components.

  • Page 11: Electrical Connections

    ELECTRICAL CONNECTIONS SWITCH OFF THE ELECTRICITY SUPPLY AT THE MAINS. Fig.8 shows a schematic wiring diagram. The cable can be surface clipped, hidden or via 20mm conduit. For this handwash unit the minimum cable size will be 1.5mm². The supply cable earth conductor must be sleeved.

  • Page 12: Fitting The Swivel Arm And Cover

    FITTING THE SWIVEL ARM Insert the washer into the swivel arm and screw onto the outlet pipe connection (fig.11). FITTING THE COVER To ensure that the temperature control is correctly positioned on the stabiliser valve, temporarily place the cover in position so that the splines engage.

  • Page 13: Commissioning

    COMMISSIONING Next isolate the electricity supply at the isolation WARNING switch then remove the cover. Remove the RED commissioning block by pulling BEFORE NORMAL OPERATION OF it directly towards you (fig.15) - please keep for THE HANDWASH, IT IS ESSENTIAL THE FOLLOWING COMMISSIONING possible future commissioning requirements such PROCEDURE IS COMPLETED CORRECTLY.

  • Page 14: Operating The Handwash

    OPERATING THE HANDWASH To start the handwash unit Slowly pass your hand in front of the sensor and the water will begin to flow. The product has a Activation activation range of 5cm to 15cm. (fig.16). Range 5-15 The flow of water is controlled by the temperature control.

  • Page 15: Operating Functions

    TEL 024 7634 4441 FAX 024 7632 4424 SHEET GRADE: www.tritonshowers.co.uk DRAWING CHECKED BY 11/03/20 FINISH: DATE: Triton is a division of Norcros Group (Holdings) Limited preventing any maintained temperature rises; water will continue to flow. Power will automatically be restored when adequate water pressure returns.

  • Page 16: Cleaning

    CLEANING THE SPRAYHEAD IMPORTANT: Before cleaning, turn off the unit When the unit is first installed the sprayhead at the isolation switch to avoid the handwash assembly may need cleaning due to debris that being accidentally switched on. Cleaning can be may be left in the pipe work after installation.

  • Page 17: Fault Finding

    1.3 Obstruction in front 1.3.1 Remove any obstruction from in front of the of infrared sensor sensor 1.4.1 Have unit checked. Contact Triton 1.4 Unit malfunction Customer Experience. 2 Water too hot. 2.1 Not enough water 2.1.1 Increase the flow rate.
  • Page 18 FAULT FINDING Problem Cause Action 5 Unit varies from 5.1 Water pressure has 5.1.1 Wait until the water pressure resumes to normal temperature dropped below minimum normal. to cold during use. required 6 Pressure relief 6.1 Blocked sprayhead. 6.1.1 Clean or replace blocked spray rings in device has operated the sprayhead and then fit new PRD.

  • Page 19: Spare Parts

    Please have your model name available. WEEE Directive – Policy Statement As a producer and a supplier of electric showers, Triton Showers is committed to the protection of the environment via our own environmental policy and compliance with the WEEE directive.
  • Page 20 Trade Installer Hotline: 024 7637 8344 Nuneaton www.tritonshowers.co.uk Warwickshire, CV11 4NR E-mail: serviceenquiries@tritonshowers.co.uk Triton is a division of Norcros Group (Holdings) Limited E-mail: technical@tritonshowers.co.uk Triton reserve the right to change product specifi cation without prior notice. E&OE. © TRITON SHOWERS 2020...

This manual is also suitable for:

Instaflow t30ir
