  • Page 1 The showerhead and hose supplied with this product are a safety The showerhead and hose supplied with this product are a safety critical part of your shower. Failure to use genuine Triton parts critical part of your shower. Failure to use genuine Triton parts may cause injury and invalidate your guarantee.
  • Page 2 INTRODUCTION - PLEASE READ PLEASE READ THIS IMPORTANT SAFETY INFORMATION Products manufactured by Triton are safe and without risk provided they are installed, used and maintained in good working order in accordance with our instructions and recommendations. WARNING: DO NOT operate shower if frozen, or suspected of being frozen. It must thaw out before using.

  • Page 3: Table Of Contents

    Cleaning and user maintenance shall not be made by children without supervision. To check the product suitability for commercial and multiple installations, please contact Triton’s specification advisory service before installation. Please see back of book for contact information.

  • Page 4: In The Box

    The showerhead and hose supplied with this product are a safety - A 30mA RCD (residual current device) MUST be installed in all UK electrical shower critical part of your shower. Failure to use genuine Triton parts critical part of your shower. Failure to use genuine Triton parts circuits.

  • Page 5: Specifications

    SECTION check list SPECIFICATIONS ELECTRICAL Nominal power - rating at 240V Nominal power - rating at 230V 7.5kW – (32A MCB rating) 6.9kW – (32A MCB rating) 8.5kW – (40A MCB rating) 7.8kW – (40A MCB rating) 9.5kW – (40A MCB rating) 8.7kW –...
  • Page 6 SECTION DIMENSIONS & ENTRY POINTS check list Fig.1 DIMENSIONS 230mm 101mm Fig.2 ENTRY POINTS WATER = Back = Others Left: Bottom, Back, Top & Side. Right: Bottom, Back, Top & Side. = Back = Others CABLE Left: Bottom, Back, Top & Side. Right: Bottom, Back, Top &...

  • Page 7: Electrical Requirements

    SECTION ELECTRICAL REQUIREMENTS check list ELECTRICAL REQUIREMENTS Triton Showers, Fig.3 Triton Road, Nuneaton, Warwickshire, CV11 4NR WARNING! W-006-A xxxx THIS APPLIANCE MUST BE EARTHED The installation, supply cable and circuit protection must conform with BS 7671 (IEE wiring regulations) and be sufficient for the amperage required.
  • Page 8 SECTION check list A 45 amp double pole isolating switch with 9.3 In any event, it is essential that individual a minimum contact gap of 3 mm in both site conditions are assessed by a competent poles must be incorporated in the circuit. electrician in order to determine the correct cable size and permissible circuit length.

  • Page 9: Siting Of The Shower

    SECTION check list Installation - SITING OF THE SHOWER SITING OF THE SHOWER Mains electric supply The installation must be in accordance with (via double pole switch) Water Regulations/Bylaws - see page 10 for water specifications • If it is intended to operate the shower at Double pressures above the maximum or below the pole...
  • Page 10 SECTION check list IMPORTANT: Water regulations (fig.7) WARNING • It is required that the showerhead be The shower MUST NOT be ‘constrained by a fixed or sliding attachment positioned where it will be so that it can only discharge water at a point subjected to freezing conditions.

  • Page 11: Plumbing Installation

    SECTION check list Installation - PLUMBING INSTALLATION PLUMBING INSTALLATION IMPORTANT INFORMATION Plumbing to be carried out before wiring The outlet of the shower acts as a vent • DO NOT use jointing compounds on any and must not be connected to anything pipe fittings for the installation.
  • Page 12 SECTION Installation - FIT TO THE WALL & CONNECT THE SUPPLIES check list FIT TO THE WALL & CONNECT THE Fig.9 SHOWER SUPPLIES • The water inlet filter assembly has been designed to allow left or right fitting, simply choose which side you wish to use and then insert the inlet plug into the opposite side (fig.9).
  • Page 13 SECTION Continued For use of the inlet pipe extension kit Fig.12 unscrew the screw on the Outlet Pipe and swing the outlet up out of the way. (fig.12). Once pipe installation has been completed, the Outlet Pipe MUST be repositioned and the retaining screw replaced and fully tightened.
  • Page 14 SECTION Continued Bottom Left and Bottom Right Pipe Entry Bottom, and rear left pipe entry can be achieved by either using a Plastic Push Fit elbow or a 15mm Compression elbow, (fig 15). Fig.15 Bottom and rear right pipe entry can be achieved by either using a Plastic Push Fit elbow or a 15mm Compression elbow, (fig 16).
  • Page 15 SECTION Continued The backplate has removable top trims (top left Top cable and pipe trims Fig.17 and top right) that may be used for pipe and can be pushed into place before cable entry (fig.17). or after the shower has been Installed onto the wall.
  • Page 16 SECTION Continued Fitting Procedure - using the template Fig.20 NOTE: The fitting template should be used when existing pipework or electrical cable connections are not available - i.e a ‘new build’ house. • Choose the site for the shower, use the fitting template supplied to mark fixing holes establish pipe and electric entry points.

  • Page 17: Electrical Installation

    SECTION Continued ELECTRICAL INSTALLATION NOTE: Deviations from the designated entry points will invalidate product approvals. The IMPORTANT: Switch off the electricity supply at cable entry points are listed on page 6. the mains before proceeding. • Seal around rear entry cable to prevent water •...

  • Page 18: Fitting The Cover

    SECTION Continued IMPORTANT: When connecting the cable fully tighten the terminal block screws and make sure that no cable insulation is trapped under the screws. Loose connections can result in cable overheating. NOTE: The supply cable earth conductor must be sleeved. The outer sheath of the supply cable must be stripped back to the minimum.

  • Page 19: Fitting The Cover

    SECTION Continued FITTING THE COVER - continued Figures 22, 23, 24 and 25 show the correct control knob position when replacing the cover. A. With the cover off the shower - turn the POWER selector spindle clockwise until the flat section is at the bottom (fig.22).

  • Page 20: Commissioning Procedure

    SECTION !! IMPORTANT !! COMMISSIONING check list WARNING Before normal operation of the shower, it is essential the following commissioning procedure is completed correctly. COMMISSIONING PROCEDURE The first operation of the shower is intended to flush out any remaining unit debris, and to make sure the heater unit contains water before the elements are switched on.
  • Page 21 SECTION check list COMMISSIONING Fig.29 Fig.28 START 30 Seconds 4. Slowly rotate the temperature control fully anti-clockwise to the MAXIMUM flow 3. Press the Start/Stop button (fig.28) and wait until water starts to flow from the position (fig.29). It will take about thirty flexible hose.
  • Page 22 SECTION Continued Fig.32 7 Fit the showerhead to the flexible hose and place in the showerhead holder, (fig.32). The shower is now ready for normal operation. After fitting and completing the commissioning procedure then please fit the Fit the Riser Rail and Kit (please refer to separate kit instructions).
  • Page 23 SECTION USER CONTROL GUIDE To START or STOP your shower. The power light will illuminate. To start the shower, press the Start/Stop button. To STOP the shower - press the Start/Stop button, then turn the Turn the isolator switch OFF. main power isolator switch ON To alter the FLOW and Temperature of your shower - HEAT SETTINGS ONLY.

  • Page 24: Operating Functions

    SECTION Continued Fig.33 OPERATING FUNCTIONS Power on indicator (fig.33) When the electricity supply to the shower is switched on at the isolating switch, the neon in the START/STOP button will illuminate. Low pressure TP – Temperature Protection indicator During normal operation if the temperature exceeds the showering safety limit the power to the elements will be removed completely, Power ‘on’...

  • Page 25: Future Maintenance

    FUTURE MAINTENANCE - CLEANING THE FILTER Instructions for installers and service engineers only INSTRUCTIONS FOR INSTALLERS AND SERVICE ENGINEERS ONLY Instructions for installers and service engineers only CLEANING THE FILTER It is recommended that the filter is periodically cleaned in order to maintain the performance of the shower.

  • Page 26: Fault Finding/Troubleshooting

    3.1.1 See 'Water too hot' causes 2.1, 2.2 and 2.3 temperature temperature limiter. and their appropriate action/cures. If it cycling hot/cool continues contact Triton Customer Service. at intervals. 4 Water too cool 4.1 Too much flow. 4.1.1 Reduce flow rate via temperature control.

  • Page 27: Fault Finding/Troubleshooting

    Action/Cure 4 Water too cool 4.4 Electrical 4.4.1 Have unit checked by suitably qualified or cold. malfunction. electrician or contact Triton Customer (continued) Service. 4.5 Safety cut-out 4.5.1 Thermal safety cut-out device has operated. operated. Have the unit checked by a suitably qualified engineer or contact Customer Service.

  • Page 28: Spare Parts

    FUTURE MAINTENANCE - SPARE PARTS Images are for reference only - due to continual development, supplied spares may have modified appearance...

  • Page 29: Spare Parts

    FUTURE MAINTENANCE - SPARE PARTS SPARE PARTS Ref. Description Part No. Model Solenoid Valve & Inlet Filter Assembly ....P82100353 Flow Control Valve ..........P82100352 Heater Can Assembly .........P86200031 (7.5kW) P86200032 (8.5kW) P86200033 (9.5kW) P86200034 (10.5kW) P86200036 (8.5kW ECO) Pressure Switch Assembly ........P22611003 Power Selector Top Assembly ......P82500282 Start/Stop Switch Assembly ........P81901342 Terminal Block &...

  • Page 30: General Guidance Notes

    DO NOT operate the shower if water ceases to flow during use or if water has entered inside the unit because of an incorrectly fitted cover. WARNING: If restarting the shower immediately after stopping, be aware that a slug of IMPORTANT - GENERAL GUIDANCE NOTES hot water will be expelled for the first few seconds.

  • Page 31: Important Advice To Users

    WEEE Directive – Policy Statement As a producer and a supplier of electric showers, Triton Showers is committed to the protection of the environment via our own environmental policy and the compliance with the WEEE directive.

  • Page 32: Uk Service Policy/Uk Guarantee

    Warwickshire CV11 4NR E-mail: serviceenquiries@tritonshowers.co.uk Triton is a division of Norcros Group (Holdings) Limited Extended Warranty AVAILABLE NOW. Call 02476 378495 for more details. 15-12-16 TRITON reserve the right to change product specification without prior notice. E&OE. © TRITON SHOWERS 2016...
