18P Hex

Program Mode:

In this mode you can choose 1 of 7 programs to run . The fade speed
and program speed are both adjustable.
1. Plug the fixture in and press the MODE button until "P-XX" is dis-
played. "XX" is the current program number displayed.
2. Use the UP of DOWN button to find your desired program.
3. Press the ENTER button to adjust the fade speed, "00" being the
slowest, "30" the fastest.
4. Press the ENTER button again to adjust the color change speed,
"00" being the slowest, "30" the fastest.
P-01 - 63 Color Change with Fade Control
P-02 - 63 Color Change No Fade
P-03 - 63 Color Fade
P-04 - 6 Color Change No Fade
P-05 - 6 Color Change With Fade
P-06 - 63 Color Fade with Sound Control
P-07 - 63 Color Change with Sound Contro l

Sound Active Mode:

In this mode the 18P Hex will react to sound, and chase through the
different colors.
1. Plug the fixture in and press the MODE button until "SoXX" is
displayed. "XX" represents the sound sensitivity level. Use the UP
and DOWN buttons to adjust the sensitivity. "00" is the lowest
sensitivity, "30" is the highest.
Activate RF Control:
This function is used to activate and deactivate the RF Remote
Control. When this function is activated you can control the fixture
using the Dotz Par RF remote. Please see the page 13 for remote
controls and functions.
1. Plug the fixture in and press the MODE button until "rFXX" is dis-
played. "XX" represents either "on" or "oFF".
2. Press the UP or DOWN buttons to either activate the remote func-
tion (On) or deactivate it (Off).
ADJ Products, LLC - www.adj.com - 18P Hex User Manual Page 10
Operating Instructions 18P Hex

Dimmer Curve:

This is used to set the dimmer curve used with DMX mode. See the
Dimmer Curve chart on page 20 for more information.
1. Plug the fixture in and press the MODE button until the DMX
address is displayed.
2. Press the ENTER button until "dCXX" is displayed. This is the
dimmer setting. "XX" represents the current dimming mode.
3. Use the UP and DOWN buttons to find your desired dimmer
curve. Press SET UP when you are finished.
• dC00 - Standard
• dC01 - Stage
• dC02 - TV
• dC03 - Architectural
• dC04 - Theater

DMX State:

This mode is used as a precaution mode, that in case the DMX signal
is lost, the operating mode chosen in this setup is the running mode
the fixture will go into when the DMX signal is lost. You can also set this
as the operating mode you would like the unit to return to when power
is applied.
1. Press the MODE button until the DMX address is displayed. Press
the ENTER button until either "Soun", "HOLd", or "bLC" is dis-
played.
2. Use the UP or DOWN buttons to find the mode you want incase
of power loss or DMX loss.
• "bLC" (Blackout) - If the DMX signal is lost or interrupted, the unit will
automatically go into stand by mode.
• "HOLd" (Last State) - If the DMX signal is lost or interrupted, the fix-
ture will stay in the last DMX set up. If power is applied and this mode
is set, the unit will automatically go into the last DMX set up.
• "Soun" (Sound Active) - If the DMX signal is lost or interrupted, the
unit will automatically go into sound active mode.
3. Find your desired setting and press ENTER. Your setting will be
saved automatically.
ADJ Products, LLC - www.adj.com - 18P Hex User Manual Page 11
