SAS 9305-16i PCI Express to 12Gb/s SAS Host Bus Adapter User Guide
June 17, 2016
1.3.3

LED Management

The Avago 12Gb/s SAS HBA offers LED management support for your backplane implementation. This configuration
option lets you use the Avago 12Gb/s SAS HBA with backplanes configured for the SGPIO interface. The Avago 12Gb/s
SAS HBA complies with SFF-8485: Specification for Serial GPIO (SGPIO) Bus, Revision 0.7.
1.4

Operating System Support

The Avago 12Gb/s SAS HBA supports all major operating systems: Windows, Linux (Oracle, SuSE, Red Hat), Solaris,
VMware, FreeBSD, CentOS, Canonical, Citrix, Fedora, and Debian.
Refer to http://www.avagotech.com/support/download-search
support. Contact Oracle support for Oracle driver or software support.
1.5 SAS 9305-16i HBA Characteristics
1.5.1

Memory

The 12Gb/s SAS HBA provides one a128Mb Flash ROM to store the firmware and the BIOS.
1.5.2

LEDs

The 12Gb/s SAS HBA has a Heartbeat LED (LT14) that blinks green to indicate that the HBA is capable of general activity,
and a thermal event LED (LT10) that illuminates if the IOC experiences an over-temperature condition.
1.5.3

Connectors

UART Connectors (JT1). The UART connector debug port requires a special cable and Avago support to gather
detailed IOC status. The UART connector uses the following layout.
Table 1 SAS 9305-16i HBA UART Pinout, JT1 UART
Pin
1 UART0_TX
2 Gnd
3 UART0_RX
4 1.8 V
SATA+SAS Connector (JT4). The 12Gb/s SAS HBA supports SATA devices and SAS devices through SFF-8643 mini-SAS
HD internal connectors.
SBR Recovery (JT8). This port enables recovery of corrupted SBR files. Avago support can assist with this process.
PCIe Connector (JT9). The 12Gb/s SAS HBA supports a x8 interface. The PCIe host interface connection is through the
edge connector, JT9, which provides connections on both the top (JT9 B) and bottom (JT9 A) of the board. The signal
definitions and pin numbers conform to the PCIe specification.
LED Indicator (LT10). Temperature LED.
Function
for details on the software versions and device driver
Broadcom
- 5 -
Chapter 1: SAS 9305-16i Host Bus Adapter User Guide
Operating System Support
