- Page 1 GigE V ISION AMERAS Prosilica GX Technical Manual V2.3.1 Allied Vision Technologies GmbH // Taschenweg 2a, 07646 Stadtroda / Germany 2017-Apr-07...
-
Page 2: Prosilica Gx At A Glance
The GenICam standard consists of multiple modules that specify tasks to be solved. Allied Vision cameras and software make use of these modules, like the Standard Feature Naming Convention (SFNC) that standardizes feature names and types via an XML file or the transport layer interface (GenTL) that is used to grab images. -
Page 3: Contact Us
Contact us Contact us Connect with Allied Vision by function https://www.alliedvision.com/en/meta-header/contact.html Find an Allied Vision office or Allied Vision distribution partner https://www.alliedvision.com/en/about-us/where-we-are.html Email info@alliedvision.com support@alliedvision.com Sales offices Europe, Middle East, and Africa: +49 36428-677-230 UK, Ireland, Nordic countries: +44 207 1934408... -
Page 4: Table Of Contents
Prosilica GX1050, GX1050C ........ - Page 5 Contents Prosilica GX1660, GX1660C ..............31 Absolute QE.
- Page 6 Contents C-Mount................80 F-Mount .
-
Page 7: Document History And Conventions
Document history and conventions This chapter includes: • Document history • Layout styles and symbols used in this manual Prosilica GX Technical Manual V2.3.1... -
Page 8: Document History
Document history and conventions Document history Version Date Remarks V2.0.0 2011-Jul-14 New manual release status V2.0.1 2011-Dec-06 Added Prosilica GX2750 model information • Specifications • Dimensions • ROI frame rates V2.0.2 2011-Dec-22 Added Prosilica GX6600 model information • Specifications • Dimensions •... - Page 9 Updated Index Updated absolute QE plots in Specifications chapter. V2.1.0 2015-Mar-10 Updated Allied Vision logo Changed AVT and Allied Vision Technologies references to Allied Vision Updated Prosilica GX3300, GX3300C specifications, absolute QE plots, and ROI height vs frame rate information...
- Page 10 Various other improvements and typographic corrections V2.3.1 2017-Apr-07 Added cable color to camera I/O connector pin assignment including pin assignment figure and cross reference to the Allied Vision I/O cable data sheet Table 1: Document history (Continued) Prosilica GX Technical Manual V2.3.1...
-
Page 11: Manual Conventions
Document history and conventions Manual conventions To give this manual an easily understood layout and to emphasize important information, the following typographical styles and symbols are used. Styles Style Function Example Bold Program names, UI elements, highlighting bold important things Italics Publication names, UI non-interactive elements Italics... - Page 12 Document history and conventions Further information available online This symbol highlights URLs for further information. The URL itself is shown in blue. Example: https://www.alliedvision.com Prosilica GX Technical Manual V2.3.1...
-
Page 13: Safety And Legislation
Safety and legislation § This chapter includes: • General safety notes for Prosilica GX cameras • Information about the legal requirements and restrictions for Prosilica GX cameras based on current and relevant legislation • Particular emphasis has been given to legislation of the European Economic Area (CE, RoHS, REACH, WEEE) as well as legislation of the United States of America (FCC) and Canada (ICES) -
Page 14: General Safety Notes
This product can be damaged by some volatile cleaning agents. Avoid cleaning the image sensor unless absolutely necessary. See instructions on optics cleaning in this document. Allied Vision can clean your camera as a service for you, if necessary. For more information, contact Allied Vision support. Prosilica GX Technical Manual V2.3.1... -
Page 15: Regulations
CE, following the provisions of 2004/108/EC directive • RoHS (2011/65/EU) REACH Allied Vision Technologies products are in compliance with the Regulation (EC) No 1907/2006 REACH. WEEE This product must be disposed of in compliance with the directive 2002/96/EC on waste electrical and electronic equipment (WEEE). -
Page 16: Industry Canada Equipment Standard For Digital Equipment (Ices)
Other legal notices Trademarks Unless stated otherwise, all trademarks shown in this document of Allied Vision Technologies are brands protected by law. All other product or company names may be trademarks of their respective owners. Warranty The information provided by Allied Vision Technologies is supplied without any guarantees or warranty whatsoever, be it specific or implicit. -
Page 17: Installation And Hardware
Installation and hardware This chapter describes the components required for your vision system including configuring the host computer, Ethernet adapter settings, and connecting your Prosilica GX camera. Prosilica GX Technical Manual V2.3.1... -
Page 18: Configuring The Host Computer
Installation and hardware Configuring the host computer Allied Vision GigE Vision cameras can operate on 10/100 or Gigabit speed Ethernet adapters. In order to reach the maximum camera frame rate, a Gigabit speed Ethernet adapter with jumbo packet support is required. -
Page 19: Ethernet Adapter Driver Settings
Transmit Buffers 256 bytes Default packet size The default packet size of Allied Vision GigE cameras is 8228 bytes. The host network adapter needs to support a packet size of equal or larger size to stream from the camera. Ethernet adapter For desktop systems, use a PCI Express bus Ethernet adapter. -
Page 20: Connecting Your Camera
Contact your Allied Vision Sales representative or your local Allied Vision distribution partner for lens recommendations. https://www.alliedvision.com/en/meta-header/contact/contact-sales Downloading camera drivers Allied Vision GigE cameras work with any or all of the following software options. Vimba Viewer or Vimba SDK: https://www.alliedvision.com/en/products/software Third-party software solutions: https://www.alliedvision.com/en/products/software/third-party-libraries.html... -
Page 21: Powering Up The Camera
Installation and hardware Powering up the camera A camera power adapter for each GigE camera is available from Allied Vision. See Specifications on page 22 for connector definition and voltage specifications. For Prosilica GX cameras • Use only DC power supplies with insulated cases. -
Page 22: Specifications
Specifications This chapter provides: • Technical specifications • Absolute quantum efficiency plots • Spectral response plots (select models) • ROI height vs. frame rate plots • Comparison of feature availability in various Prosilica GX camera models Prosilica GX Technical Manual V2.3.1... -
Page 23: Notes On Specifications
Prosilica GX color models with ON Semiconductor sensors now use sensors with the new Gen 2 CFA materials. For more information, see the Product Change Notification on the Allied Vision website. Resolution and ROI frame rates This section provides performance information about the impact of reducing the region of interest on the camera’s maximum frame rate. - Page 24 In the example chart below, the frame rate for a 16-bit pixel format is given on a Prosilica GX1050 camera. The upper line shows the frame rate in dual GigE mode, where no bandwidth limitation occurs. The lower line shows the frame rate in single GigE mode, where bandwidth limitation occurs after a data threshold of 124 Mbit/s.
- Page 25 Specifications The Prosilica GX camera can be operated near peak sensor frame rates even when using a single interface connection. The frame rate vs. height graphs included in this section provide frame rate performance results for both single GigE interface and dual GigE LAG configurations at 8-bit or 16-bit output formats.
-
Page 26: Prosilica Gx1050, Gx1050C
Vertical: 1 to 8 rows Opto-isolated I/Os 2 inputs, 4 outputs RS232 Voltage requirements 5 to 24 VDC Power consumption 5.4 W (single GigE mode) 6.7 W (dual GigE mode) Table 2: Prosilica GX1050, GX1050C model specifications Prosilica GX Technical Manual V2.3.1... -
Page 27: Absolute Qe
Note: Measured with AR coated cover glass. The uncertainty of measurement of the QE is +/ 10.25%. The values are typical and are subject to minor variations. 1000 1050 Wavelength [nm] Figure 2: Prosilica GX1050, GX1050C (ON Semiconductor KAI-01050) absolute QE Prosilica GX Technical Manual V2.3.1... -
Page 28: Roi Frame Rate
Specifications ROI frame rate 8-bit output format Dual GigE - 8 bit Single GigE - 8 bit 1050 Height [pixels] Figure 3: Frame rate as a function of ROI height (8-bit pixel format) Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 1024 1024... -
Page 29: 16-Bit Output Format
Specifications Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 1024 366.5 366.5 1024 374.7 374.7 1024 381.0 381.0 For maximum speed advantage ROIs are taken as center image, where attribute OffsetY = (full sensor height – ROI height)/2. Table 3: Frame rate as a function of ROI height (8-bit pixel format) (Continued) BinningVertical Height... - Page 30 Specifications Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 1024 1024 57.1 112.1 1000 1024 58.4 114.0 1024 64.8 122.7 1024 72.9 132.8 1024 75.9 136.3 1024 83.2 144.4 1024 96.8 158.6 1024 113.2 173.7 1024 144.3 197.0...
-
Page 31: Prosilica Gx1660, Gx1660C
Specifications Prosilica GX1660, GX1660C Specification Feature Prosilica GX1660 Prosilica GX1660C Resolution 1600 (H) × 1200 (V) 1.9 MP Sensor ON Semiconductor KAI-02050 TRUESENSE Sensor type Interline CCD, Progressive Scan Shutter type Global Sensor size Type 2/3 11.0 mm diagonal Cell size 5.5 µm ×... -
Page 32: Absolute Qe
Specifications Specification Feature Prosilica GX1660 Prosilica GX1660C Mass (typical) 269 g Body dimensions (L × W × H) 107.2 × 53.3 × 33 mm Operating temperature 0 to +50 °C ambient temperature (without condensation) Storage temperature -10 to +70 °C ambient temperature (without condensation) Trigger latency 1.5 µs Trigger jitter... -
Page 33: Roi Frame Rate
Specifications ROI frame rate 8-bit output format Dual GigE - 8 bit Single GigE - 8 bit 1000 1200 Height [pixels] Figure 6: Frame rate as a function of ROI height (8-bit pixel format) Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 1200 1600... -
Page 34: 16-Bit Output Format
Specifications Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 1600 245.2 245.2 1600 250.7 250.7 1600 256.4 256.4 For maximum speed advantage ROIs are taken as center image, where attribute OffsetY = (full sensor height – ROI height)/2. Table 8: Frame rate as a function of ROI height (8-bit pixel format) (Continued) BinningVertical Height... - Page 35 Specifications Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 1200 1600 31.3 62.5 1080 1600 34.7 69.4 1024 1600 36.6 73.2 1600 41.6 81.6 1600 48.7 90.7 1600 62.1 105.6 1600 72.9 115.7 1600 92.6 131.6 1600 122.7...
-
Page 36: Prosilica Gx1910, Gx1910C
Specifications Prosilica GX1910, GX1910C Specification Feature Prosilica GX1910 Prosilica GX1910C Resolution 1920 (H) × 1080 (V) 2.1 MP Sensor ON Semiconductor KAI-02150 TRUESENSE Sensor type Interline CCD, Progressive Scan Shutter type Global Sensor size Type 2/3 12.1 mm diagonal Cell size 5.5 µm ×... -
Page 37: Absolute Qe
Specifications Specification Feature Prosilica GX1910 Prosilica GX1910C Mass (typical) 269 g Body dimensions (L × W × H) 107.2 × 53.3 × 33 mm Operating temperature 0 to +50 °C ambient temperature (without condensation) Storage temperature -10 to +70 °C ambient temperature (without condensation) Trigger latency 1.5 µs Trigger jitter... -
Page 38: Roi Frame Rate
Specifications ROI frame rate 8-bit output format Dual GigE - 8 bit Single GigE - 8 bit 1000 1100 Height [pixels] Figure 9: Frame rate as a function of ROI height (8-bit pixel format) Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 1080 1920... -
Page 39: 16-Bit Output Format
Specifications Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 1920 240.1 241.9 1920 247.2 247.2 1920 252.2 252.2 For maximum speed advantage ROIs are taken as center image, where attribute OffsetY = (full sensor height – ROI height)/2. Table 13: Frame rate as a function of ROI height (8-bit pixel format) (Continued) BinningVertical Height... - Page 40 Specifications Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 1080 1920 28.9 55.6 1024 1920 30.5 58.8 1000 1920 31.3 60.1 1920 34.7 66.8 1920 39.0 74.9 1920 44.5 85.3 1920 51.8 95.2 1920 57.5 101.6 1920 62.1...
-
Page 41: Prosilica Gx1920, Gx1920C
Specifications Prosilica GX1920, GX1920C Specification Feature Prosilica GX1920 Prosilica GX1920C Resolution 1936 (H) × 1456 (V) 2.8 MP Sensor Sony ICX674ALG with EXview HAD Sony ICX674AQG with EXview HAD II™ II™ microlens technology microlens technology Sensor type Interline CCD, Progressive Scan Shutter type Global Sensor size... -
Page 42: Absolute Qe
Specifications Specification Feature Prosilica GX1920 Prosilica GX1920C Mass (typical) 269 g Body dimensions (L × W × H) 108.1 × 53.3 × 33 mm Operating temperature 0 to +50 °C ambient temperature (without condensation) Storage temperature -10 to +70 °C ambient temperature (without condensation) Trigger latency 1.5 µs Trigger jitter... -
Page 43: Spectral Response
Specifications Spectral response Red Response Green Response Blue Response Monochrome Response 0.3000 Sony ICX674 spectral response 0.2000 0.1000 0.0000 1000 Wavelength [nm] Figure 12: Prosilica GX1920, GX1920C (Sony ICX674) spectral response ROI frame rate 8-bit output format Dual GigE - 8 bit Single GigE - 8 bit 1000 1250... - Page 44 Specifications Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 1456 1936 40.6 40.6 1200 1936 46.4 46.4 1080 1936 49.6 49.6 1936 55.5 55.5 1936 59.5 59.5 1936 62.5 62.5 1936 69.1 69.1 1936 75.3 75.3 1936 76.3...
-
Page 45: 16-Bit Output Format
Specifications 16-bit output format Dual GigE - 16 bit Single GigE - 16 bit 1000 1250 1500 Height [pixels] Figure 14: Frame rate as a function of ROI height (16-bit pixel format) Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 1456 1936... - Page 46 Specifications Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 1936 135.7 135.6 For maximum speed advantage ROIs are taken as center image, where attribute OffsetY = (full sensor height – ROI height)/2. Table 20: Frame rate as a function of ROI height (16-bit pixel format) (Continued) BinningVertical Height Width...
-
Page 47: Prosilica Gx2300, Gx2300C
Specifications Prosilica GX2300, GX2300C Specification Feature Prosilica GX2300 Prosilica GX2300C Resolution 2336 (H) × 1752 (V) 4.1 MP Sensor ON Semiconductor KAI-04050 TRUESENSE Sensor type Interline CCD, Progressive Scan Shutter type Global Sensor size Type 1 16.06 mm diagonal Cell size 5.5 µm ×... -
Page 48: Absolute Qe
Specifications Specification Feature Prosilica GX2300 Prosilica GX2300C Mass (typical) 269 g Body dimensions (L × W × H) 107.2 × 53.3 × 33 mm Operating temperature 0 to +50 °C ambient temperature (without condensation) Storage temperature -10 to +70 °C ambient temperature (without condensation) Trigger latency 1.5 µs Trigger jitter... -
Page 49: Roi Frame Rate
Specifications ROI frame rate 8-bit output format Dual GigE - 8 bit Single GigE - 8 bit 1000 1200 1400 1600 1800 Height [pixels] Figure 16: Frame rate as a function of ROI height (8-bit pixel format) Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 1752... -
Page 50: 16-Bit Output Format
Specifications Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 2336 116.8 116.8 2336 124.4 124.4 2336 125.9 125.9 For maximum speed advantage ROIs are taken as center image, where attribute OffsetY = (full sensor height – ROI height)/2. Table 23: Frame rate as a function of ROI height (8-bit pixel format) (Continued) BinningVertical Height... - Page 51 Specifications Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 1752 2336 14.7 28.3 1600 2336 16.1 31.0 1500 2336 17.2 33.1 1400 2336 18.4 35.4 1300 2336 19.8 38.1 1200 2336 21.4 41.2 1100 2336 23.4 44.7 1000...
-
Page 52: Prosilica Gx2750, Gx2750C
Specifications Prosilica GX2750, GX2750C Specification Feature Prosilica GX2750 Prosilica GX2750C Resolution 2750 (H) × 2200 (V) 6.1 MP Sensor Sony ICX694ALG with EXview HAD Sony ICX694AQG with EXview HAD CCD II™ technology CCD II™ technology Sensor type Interline CCD, Progressive Scan Shutter type Global Sensor size... -
Page 53: Absolute Qe
Specifications Specification Feature Prosilica GX2750 Prosilica GX2750C Mass (typical) 269 g Body dimensions (L × W × H) 108.1 × 53.3 × 33 mm Operating temperature 0 to +50 °C ambient temperature (without condensation) Storage temperature -10 to +70 °C ambient temperature (without condensation) Trigger latency 1.5 µs Trigger jitter... -
Page 54: Spectral Response
Specifications Spectral response Red Response Green Response Blue Response Monochrome Response 0.4000 Sony ICX694 spectral response 0.3000 0.2000 0.1000 0.0000 1000 Wavelength [nm] Figure 19: Prosilica GX2750, GX2750C (Sony ICX694) spectral response ROI frame rate 8-bit output format Dual GigE - 8 bit Single GigE - 8 bit 1000 1200 1400 1600 1800 2000 2200 Height [pixels]... - Page 55 Specifications Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 2200 2752 19.1 20.6 2000 2752 21.1 22.1 1800 2752 23.4 23.4 1600 2752 25.8 25.8 1400 2752 28.1 28.1 1200 2752 31.0 31.0 1000 2752 34.4 34.4 2752...
-
Page 56: 16-Bit Output Format
Specifications 16-bit output format Dual GigE - 16 bit Single GigE - 16 bit 1000 1200 1400 1600 1800 2000 2200 Height [pixels] Figure 21: Frame rate as a function of ROI height (16-bit pixel format) Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 2200 2752... - Page 57 Specifications Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 2752 1099 77.3 77.1 For maximum speed advantage ROIs are taken as center image, where attribute OffsetY = (full sensor height – ROI height)/2. Table 30: Frame rate as a function of ROI height (16-bit pixel format) (Continued) BinningVertical Height Width...
-
Page 58: Prosilica Gx3300, Gx3300C
Specifications Prosilica GX3300, GX3300C Specification Feature Prosilica GX3300 Prosilica GX3300C Resolution 3296 (H) × 2472 (V) 8.1 MP Sensor ON Semiconductor KAI-08050 TRUESENSE Sensor type Interline CCD, Progressive Scan Shutter type Global Sensor size Type 4/3 22.66 mm diagonal Cell size 5.5 µm ×... -
Page 59: Absolute Qe
Specifications Specification Feature Prosilica GX3300 Prosilica GX3300C Mass (typical) 365 g Body dimensions (L × W × H) 136.7 × 59.7 × 59.7 mm Operating temperature 0 to +50 °C ambient temperature (without condensation) Storage temperature -10 to +70 °C ambient temperature (without condensation) Trigger latency 1.5 µs Trigger jitter... -
Page 60: Roi Frame Rate
Specifications ROI frame rate 8-bit output format Dual GigE - 8 bit Single GigE - 8 bit 1000 1500 2000 2500 Height [pixels] Figure 23: Frame rate as a function of ROI height (8-bit pixel format) Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 2472 3296... -
Page 61: 16-Bit Output Format
Specifications Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 3296 1186 61.1 61.1 3296 1211 64.7 64.7 3296 1235 68.4 68.4 For maximum speed advantage ROIs are taken as center image, where attribute OffsetY = (full sensor height – ROI height)/ Table 33: Frame rate as a function of ROI height (8-bit pixel format) (Continued) BinningVertical Height... - Page 62 Specifications Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 2472 3296 14.2 2300 3296 15.3 2100 3296 16.8 1900 3296 18.5 1700 3296 10.7 20.7 1500 3296 12.2 23.5 1236 3296 14.8 27.3 1100 3296 16.6 29.2 1000...
-
Page 63: Prosilica Gx6600, Gx6600C
Specifications Prosilica GX6600, GX6600C Specification Feature Prosilica GX6600 Prosilica GX6600C Resolution 6576 (H) × 4384 (V) 28.8 MP Sensor ON Semiconductor KAI-29050 TRUESENSE Sensor type Interline CCD, Progressive Scan Shutter type Global Sensor size Type 35 mm 43.47 mm diagonal Cell size 5.5 µm ×... -
Page 64: Absolute Qe
Specifications Specification Feature Prosilica GX6600 Prosilica GX6600C Mass (typical) 510 g Body dimensions (L × W × H) 136.6 × 59.7 × 59.7 mm Operating temperature 0 to +50 °C ambient temperature (without condensation) Storage temperature -10 to +70 °C ambient temperature (without condensation) Trigger latency 2.5 µs Trigger jitter... -
Page 65: Roi Frame Rate
Specifications ROI frame rate 8-bit output format Dual GigE - 8 bit Single GigE - 8 bit 1000 1500 2000 2500 3000 3500 4000 4500 Height [pixels] Figure 26: Frame rate as a function of ROI height (8-bit pixel format) Height Width OffsetY... -
Page 66: 16-Bit Output Format
Specifications Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 6576 2187 17.1 17.1 6576 2191 17.2 17.2 6576 2191 17.2 17.2 For maximum speed advantage ROIs are taken as center image, where attribute OffsetY = (full sensor height – ROI height)/2. Table 38: Frame rate as a function of ROI height (8-bit pixel format) (Continued) BinningVertical Height... - Page 67 Specifications Height Width OffsetY Single GigE mode frame rate Dual GigE mode frame rate 4384 6576 4000 6576 3500 6576 3000 6576 2500 6576 2000 6576 1192 1500 6576 1442 1200 6576 1592 1000 6576 1692 6576 1792 10.8 10.8 6576 1892 11.9...
-
Page 68: Prosilica Gx Model Comparison
Specifications Prosilica GX model comparison Single GigE interface (8-bit) operation GX1050 GX1660 GX1910 GX1920 GX2300 GX2750 GX3300 GX6600 1000 1000 1500 2000 2500 3000 3500 4000 4500 Height [pixels] Figure 28: Maximum frame rate vs. height for all Prosilica GX cameras using single Ethernet interface (8-bit pixel format) Prosilica GX Technical Manual V2.3.1... -
Page 69: Dual Gige Lag (8-Bit) Operation
Specifications Dual GigE LAG (8-bit) operation GX1050 GX1660 GX1910 GX1920 GX2300 GX2750 GX3300 GX6600 1000 1000 1500 2000 2500 3000 3500 4000 4500 Height [pixels] Figure 29: Maximum frame rate vs. height for all Prosilica GX cameras using two Ethernet ports (8-bit pixel format) Prosilica GX Technical Manual V2.3.1... -
Page 70: Single Gige Interface (16-Bit) Operation
Specifications Single GigE interface (16-bit) operation GX1050 GX1660 GX1910 GX1920 GX2300 GX2750 GX3300 GX6600 1000 1000 1500 2000 2500 3000 3500 4000 4500 Height [pixels] Figure 30: Maximum frame rate vs. height for all Prosilica GX cameras using single Ethernet interface (16-bit pixel format) Prosilica GX Technical Manual V2.3.1... -
Page 71: Dual Gige Lag (16-Bit) Operation
Specifications Dual GigE LAG (16-bit) operation GX1050 GX1660 GX1910 GX1920 GX2300 GX2750 GX3300 GX6600 1000 1000 1500 2000 2500 3000 3500 4000 4500 Height [pixels] Figure 31: Maximum frame rate as a function of height for all Prosilica GX cameras using two Ethernet ports (16-bit pixel format) Prosilica GX Technical Manual V2.3.1... -
Page 72: Mechanical Dimensions
Mechanical dimensions This chapter includes: • Mechanical drawings and dimensions of standard, extended, and large format housing models, and tripod adapters • Sensor position accuracy • Maximum protrusion distance and filter diameter for C-Mount and F-Mount Prosilica GX Technical Manual V2.3.1... -
Page 73: Prosilica Gx Standard Format Housing
Prosilica GX large format Prosilica GX cameras are available with different lens mount options. For more information, see the Modular Concept document at: https://www.alliedvision.com/en/support/technical-documentation.html Prosilica GX standard format housing Models: Prosilica GX1050, GX1660, GX1910, GX2300 Mount: C-Mount (default) 12.5 M3X4 (2x) 107.2... - Page 74 Mechanical dimensions Models: Prosilica GX2300, GX3300 Mount: F-Mount (default for Prosilica GX3300) 41.6 M3x4 (2x) 136.3 Adjustable Nikon F-Mount 27.8 M2x3 (4x) 22.1 20.8 90.9 59.7 39.1* *Nominal adjustable 53.3 M3x4 (4x) 85.9 41.6 Figure 33: F-Mount standard housing dimensions C-Mount or F-Mount Prosilica GX cameras are shipped with an adjustable C-Mount or F-Mount.
-
Page 75: Prosilica Gx Extended Format Housing
Mechanical dimensions Prosilica GX extended format housing Models: Prosilica GX1920, GX2750 Mount: C-Mount (default) 13.4 M3X4 (2X) 108.1 Adjustable C-Mount M2X3 (4X) 27.8 31.6 16 26 33 26.7 22.1 20.8 92.2 M3X4 (8X) 53.3 M3X4 (4X) 85.9 13.4 Figure 34: C-Mount extended format housing dimensions Prosilica GX1920 and GX2750 Prosilica GX1920 and GX2750 are 1.3 mm longer than the remaining Prosilica GX C-Mount models. -
Page 76: Prosilica Gx Large Format Housing
Mechanical dimensions Prosilica GX large format housing Model: Prosilica GX6600 Mount: F-Mount (default) 88.9 38.9 M3x4 (4x) 136.6 Adjustable Nikon F-Mount 27.8 M2x3 (4x) 53.3 24.6 23.3 59.7 93.9 36.3* 53.3 *Nominal adjustable M3x4 (4x) 88.9 38.6 Figure 35: F-Mount large format housing dimensions Prosilica GX6600 Prosilica GX6600 is taller than the other Prosilica GX models. -
Page 77: Tripod Adapter
A Prosilica GX camera can be mounted on a camera tripod by using the Prosilica GX tripod adapter. Models: Prosilica GX1050, GX1660, GX1910, GX1920, GX2300, GX3300 Prosilica GX tripod adapter Contact the Allied Vision Sales team to purchase the Prosilica GX tripod adapter (order code 02-5030A). SECTION A-A 0.5x 45° TYP... - Page 78 A Prosilica GX camera can be mounted on a camera tripod by using the Prosilica GX6600 tripod adapter. Prosilica GX6600 tripod adapter Contact the Allied Vision Sales team to purchase the Prosilica GX6600 tripod adapter (order code 02-5034A). SECTION A-A 0.5 X 45°...
- Page 79 Sensor position accuracy Camera body Camera body Pixel area Pixel area Sensor case Sensor case Figure 38: Allied Vision sensor position accuracy The following table defines the manufacturing accuracy of fitting sensors into Prosilica GX cameras. Criteria Subject Properties Reference Point Sensor...
-
Page 80: Flange Focal Distance
When the locking ring is loose, unthread the ring a few turns from the camera face. Locking wrench Contact the Allied Vision Sales team to purchase the hexagonal lens adjustment wrench for Prosilica GX cameras with C/CS locking ring (order code E9020001). Adjusting the lens to infinity Precondition: Use a C-Mount compatible lens that allows an infinity focus. - Page 81 Avoid damage from unsuitable lenses To protect camera and lens, use lenses only up to the allowed maximum protrusion, as listed in the following tables. Model Lens protrusion [mm] Model Lens protrusion [mm] Prosilica GX1050 13.64 Prosilica GX2300 13.64 Prosilica GX1050C 8.49 Prosilica GX2300C 9.01...
-
Page 82: F-Mount
Mechanical dimensions F-Mount Flange focal distance is the optical distance from the mounting flange to image sensor. Prosilica GX F-Mount cameras are optically calibrated to a standard 46.5 mm optical flange focal distance. Adjustment of F-Mount The F-Mount is adjusted at the factory and should not require adjusting. If for some reason, the lens mount requires adjustment, use the following method. -
Page 83: Camera Attributes And Filter
Camera attributes and filter This chapter includes information on: • Camera attributes • IR cut filters Prosilica GX Technical Manual V2.3.1... -
Page 84: Camera Attribute Highlights
Camera attributes and filter Camera attribute highlights Allied Vision cameras support a number of standard and extended features. The table below identifies a selection of interesting capabilities of the Prosilica GX camera family. Camera feature reference A complete description of individual features can be found online: •... -
Page 85: Ir Cut Filter
Camera attributes and filter IR cut filter All Prosilica GX color models are equipped with an infrared cut filter (IR filter). This filter is employed to prevent infrared wavelength photons from passing to the sensor. In the absence of IR filter, images are dominated by red and incapable of being properly color balanced. -
Page 86: Camera Interfaces
Camera interfaces This chapter includes: • A general description of the inputs and outputs (including trigger features) • I/O connector pin assignments • I/O block diagrams • A general description of trigger rules such as timing diagram and definitions Prosilica GX Technical Manual V2.3.1... -
Page 87: Back Panel
This chapter provides information on Gigabit Ethernet interfaces, inputs and outputs, and trigger features. Accessories Please contact Allied Vision Sales representative or your local Allied Vision distributor for information on accessories, go to: https://www.alliedvision.com/en/about-us/where-we-are.html Figure 43: Interfaces, ports, and LEDs... -
Page 88: Status Leds
Gigabit Ethernet interface The Gigabit Ethernet interface conforms to the IEEE 802.3 1000BASE-T standard for Gigabit Ethernet. Allied Vision recommends using Category 6 or higher compatible cabling and connectors for best performance. The Prosilica GX offers two Gigabit Ethernet interfaces. This interface is enabled using Link aggregation. -
Page 89: Camera I/O Connector Pin Assignment
Inc. for a perfect fit. Visit the CEI product configurator to customize the cable according to your needs. Hardware Selection See Hardware Selection for Allied Vision GigE Cameras application note for a list of recommended GigE host controller cards: https://www.alliedvision.com/en/support/technical-papers-knowledge- base.html GigE host controllers A standard PCI GigE host controller card is available for purchase from Allied Vision. - Page 90 Table 46: Camera I/O connector pin assignment and Prosilica GX trigger cable color coding Cable color and pin out For cable color and pin out information, see the Allied Vision I/O cable data sheet: https://www.alliedvision.com/en/support/technical-documentation/accessories- data-sheets.html Prosilica GX Technical Manual V2.3.1...
-
Page 91: I/O Definition
Camera interfaces BLUE PINK GREY YELLOW GREEN BROWN WHITE BLACK ORANGE WHITE/BLACK WHITE/BROWN TRANSPARENT SHIELD Hirose HR10A Open End Figure 44: Prosilica GX cable color coding The general purpose I/O interface uses a Hirose HR10A-10R-12PB connector on the camera side. The mating cable connector is Hirose HR10A-10P-12S. Hirose connector The cable side Hirose 12-pin female connector is available for purchase from Allied Vision. -
Page 92: Isolated Io Gnd
Camera interfaces Isolated IO GND This connection provides the user ground reference and return path for the In 2, Out 3, and Out 4. It is also recommended that the ground wiring be physically close to the used In/Out to prevent parasitic coupling. For example, a good cable design would connect the required signal on one conductor of a twisted pair and the Isolated IO GND on the second conductor of the same twisted pair. -
Page 93: Output Signals
Camera interfaces The camera can also be programmed to capture an image at some programmable delay time after the trigger event. These signals can be driven from 5 V to 24 V with a minimum current source of 5 mA. CAMERA INTERNAL EXTERNAL VDD+3.3 180 R... - Page 94 Camera interfaces Out (1 to 4) These signals are optically isolated and require the user to provide a high voltage level (Isolated out power) and signal common (Isolated IO GND). Isolated out power can be from 5 V to 24 V. An example of the functional circuit is indicated in the diagram below.
-
Page 95: Lens Control Port
Camera interfaces Isolated Out R Power Power R Load V Load Dissipation 24 V 9.5 mA 2.4 KΩ 23.2 V 217 mW 1.5 μs 22 μs 2 μs 37 μs 24 V 5 mA 4.8 KΩ 23.8 V 120 mW 1.5 μs 12 μs 17 μs... -
Page 96: Auto Iris Video-Type Connection
Camera interfaces Hirose connector This cable side Hirose connector is available to purchase from Allied Vision. Order code 02-7004A. Auto iris video-type connection Prosilica GX cameras provide built-in auto iris controls for controlling video-type auto-iris lenses. These lenses are available from many popular security lens companies including Pentax, Fujinon, Tamron, Schneider and others. -
Page 97: Motorized Lens Connection
Camera interfaces Motorized lens connection ZOOM+ IRIS+ IRIS- ZOOM- FOCUS+ FOCUS- FOCUS+ ZOOM+ TV ZOOM LENS FOCUS ZOOM- BIPOLAR TYPE IRIS+ COMMON IRIS- COMMON HIROSE 3240-8P-C(50) IRIS ZOOM COMMON FOCUS FOCUS COMMON TV ZOOM LENS IRIS ZOOM UNIPOLAR TYPE COMMON COMMON COMMON HIROSE 3240-8P-C(50) -
Page 98: Trigger Timing Diagram
Camera interfaces Trigger timing diagram Readout me Trigger latency Registered Exposure start delay exposure me User trigger Note: Ji er at the Logic trigger beginning of an exposure has no e ect on the Exposure length of exposure. N+ 1 Trigger ji er Readout... -
Page 99: Notes On Triggering
Camera interfaces Notes on triggering Term Definition User trigger Trigger signal applied by the user (hardware trigger, software trigger) Logic trigger Trigger signal seen by the camera internal logic (not visible to the user) Propagation delay (t Propagation delay between the user trigger and the logic trigger Exposure High when the camera image sensor is integrating light Readout... - Page 100 Camera interfaces Triggering during the Readout State For applications requiring the fastest triggering cycle time whereby the camera image sensor is exposing and reading out simultaneously, apply the User Trigger signal as soon as a valid Trigger Ready is detected. In this case, Trigger Latency and Trigger Jitter can be up to 1 row time since Exposure must always begin on an Interline boundary.
-
Page 101: Image Data Flow
Image data flow This chapter presents diagrams that illustrate data flow and bit resolution of the image data. Prosilica GX Technical Manual V2.3.1... -
Page 102: Prosilica Gx Monochrome Cameras
Image data flow The following diagrams illustrate the data flow and the bit resolution of image data. Camera feature reference A complete description of individual features can be found online: • Vimba and third-party users: GigE Features Reference • PvAPI users: GigE Camera and Driver Attributes document Prosilica GX monochrome cameras ‡... -
Page 103: Prosilica Gx Color Cameras
Image data flow Prosilica GX color cameras Vertical ‡ Gain Offset Sensor Vertical ROI Binning* Analog Analog Analog Analog Horizontal Horizontal ROI White balance Defect Mask § Binning* 14 bit 14 bit 14 bit 14 bit Bayer Frame Memory GigE Interface †... -
Page 104: Cleaning Optical Components
Cleaning optical components This chapter describes safety instructions and cautions for cleaning lenses, optical filters, or sensors. Prosilica GX Technical Manual V2.3.1... -
Page 105: Warranty
Cleaning optical components Read these instructions before you contact Allied Vision or your Allied Vision distribution partner for assistance. Contact Allied Vision or your Allied Vision distribution partner if you are not familiar with the procedures described below. Warranty For details about camera warranty duration and sensor warranty terms, go to: https://www.alliedvision.com/en/support/warranty... -
Page 106: Identifying Impurities
IR cut filter/protection glass, it is probably on the sensor. Removing IR cut filter A pin spanner wrench (Allied Vision order code: E9020001) suitable for IR filter removal is available for purchase from Allied Vision for all Prosilica GX cameras with C-Mount or CS-Mount. -
Page 107: Materials For Cleaning Optical Components
Cleaning optical components Materials for cleaning optical components Use only these cleaning materials for optical components • Optic approved lens cotton, cloth, or tissue that is chemically pure and free from silicones and other additives. • Optic approved low residue cleaning liquid. Never use these cleaning materials for optical components •... -
Page 108: Cleaning With Compressed Air
Allied Vision distribution partner. Cleaning with compressed air Allied Vision does not recommend cleaning Prosilica GX cameras with compressed air. • Compressed air at high pressure and/or shorter operating distances may push dust into the camera/lens and physically damage the camera, sensor, or optical components. -
Page 109: Firmware Update
Firmware update This chapter includes instructions on updating the firmware on your Allied Vision Prosilica GX camera. Prosilica GX Technical Manual V2.3.1... - Page 110 Firmware update Download the latest GigE firmware loader from the Allied Vision website: https://www.alliedvision.com/en/support/firmware Saved camera user sets If new firmware contains a new feature/control, saved camera UserSets/ ConfigFiles will be invalidated and erased! Before loading new firmware, backup your current camera settings.
- Page 111 Firmware update Click Next. The Firmware Loader displays a list of firmware included in the package. Click Next. Select your camera model on this page. Recovery Mode Select the Use recovery mode check box if the connected GigE camera is not found by the firmware loader, or if the GigE camera is listed as unavailable.
- Page 112 Firmware update Click Next. Click Upload to start the update. The existing firmware will be erased and the new firmware will be updated to the camera. Prosilica GX Technical Manual V2.3.1...
- Page 113 Firmware update The Firmware Loader displays a success status upon completion. Click Quit to exit the loader. Power cycle after upgrade or downgrade You should always power cycle the camera after a firmware upgrade or downgrade. Prosilica GX Technical Manual V2.3.1...
-
Page 114: Index
Index Index Update..........110 Flange focal distance C-Mount..........80 Adjustment F-Mount ..........82 C-Mount..........80 F-Mount ..........82 Auto iris Video type ........95 GenICam ..........2 Gigabit Ethernet interface ......2 GigE host controller........89 Bandwidth limiting......23 GigE Vision ..........2 Block diagram GND for ext. - Page 115 RoHS..........15 Latency ..........99 WEEE ..........15 Logic trigger ........99 ROI frame rates Propagation delay .......99 Prosilica GX1050 16-bit output format ..29 Readout ..........99 Prosilica GX1050 8-bit output format ..28 Readout data........99 Prosilica GX1660 16-bit output format ..34 Rules..........99 Prosilica GX1660 8-bit output format ..33 Time delay .........99...
