3 About Power System Configuration

1 - System Status options

Configuration changes are not allowed at System Status level. To make changes you have
to access the System Configuration options, the Alarm Configuration options or similar.
This logical group presents the important system parameters, which indicate the status of
the power system, such as number of battery banks, voltage, current, temperatures, fuse
status, inputs and outputs status, and many similar parameters.
The presented parameters are organized in system-oriented groups: Power System, Mains,
Generator, Rectifier, etc.
Refer to these topics (Mains, Rectifiers, etc.) for more information about the System Status
parameters.

2 - System Configuration options

The options in this logical group let you change all the relevant system parameters, values
and characteristics, such as temperature scales, system polarity (as represented on the
display), language, system voltages, rectifiers and battery related values, and many similar
parameters.
Configuration changes are allowed at this level, using a Pin-Code.
The parameters are organized in system-oriented groups: Power System, Mains, Generator,
Rectifier, etc.
Refer to these topics (Power System, Mains, Rectifiers, etc.) for more information about
the System Configuration parameters.

3 - Alarm Configuration options

All the power system's alarms are fully configurable, and are implemented using Alarm
Monitors (software modules). These software modules monitor input signals and logical
states, and raise alarms when the signals reach certain limits or values.
Read more about "Alarm
The options in this logical group (the Alarm Configuration options) let you configure all
the limits, values, etc. for the system's Alarm Monitors.
Configuration changes are allowed at this level, using a Pin-Code.
The available Alarm Monitors are organized in system-oriented groups: Mains, Generator,
Rectifier, Load, etc.
Refer to these topics (Mains, Rectifiers, etc.) for more information about the available
Alarm Monitors parameters.
Read also the topic "Typical Parameters for Alarm
16
NOTICE:
The default Service Access Level password or Pin-Code is
<0003>, which may be changed for security reasons.
Monitors" on page 23.
NOTICE:
The default Service Access Level password or Pin-Code is
<0003>, which may be changed for security reasons.
User's Guide Smartpack2 Master Controller
Monitors" on page 26.
350020.013, Issue 2.0, 2014 Jan
