- Page 1 F615 HOLD / DOWN ATTACHMENT KIT OWNERS MANUAL Model No. F615 Recreation Supply, Inc. 7699 Green Meadows Dr. BODYCRAFT Lewis Center, OH 43035 a division of Recreation Supply Inc.
- Page 2 STEP 1 ASSEMBLE HOLD DOWN TUBE 1. Insert two Foam Roller Holders (203) into the Hold Down Tube (202) and slide Foam Pad Cover (205), Plastic Washer (211), Aluminum Cap (212) onto each end of the Foam Roller Holder (203) by using four 5/16" X 1-1/4" Screws (215).
- Page 3 STEP 2 ASSEMBLE ATTACHMENT HOLDER NOTE: Your bench may differ in appearance. The assembly instructions will be the same. 1. Please remove Handle Bar (5) on the Main Frame (1). As shown in view A1 below. 2. Attach Attachment Holder (201) to the Main Frame (1) using two 1/2"...
-
Page 4: Exploded View
EXPLODED VIEW... - Page 5 COMPLETE PARTS CHART NO. DESCRIPTION QTY. ATTACHMENT HOLDER HOLD DOWN TUBE FOAM ROLLER HOLDER FOAM PAD FOAM PAD COVER RUBBER (Pre-Assembled) 45 X 75mm END PLUG 45 X 45mm END PLUG SPACER CAP QUICK RELEASE PLASTIC WASHER ALUMINUM CAP 5/16" NUT (Pre-Assembled) 1/2"...
