DURATION:
•
DATE:
•
TASK STAT.: Task statistics available after pressing Enter
Task statistics are available only if a task was declared. If the task was modified during flight, the statistics
data will be based on the declared task and not on the real flown task and will be therefore be
After pressing Enter on TASK STAT, there will be delay of some seconds while the unit makes a
calculation before displaying:
•
Tsk.dist:
•
FINISHED: Confirms a correctly flown task with no missing points
•
V:
•
NoFINISH: Indicates that there is a problem with the task; some turn points or finish are missing
•
Vario:
•
Track d.:

4 Wiring and installation

As previously mentioned, the unit is very small is capable of being installed in many places in the glider. When
deciding on where to install it, one factor is whether or not the unit will be used in flight to display navigational
data. If so, then a position is required whereby it is easy to see the screen and manipulate the buttons during
flight. The unit is supplied with a dedicated mounting bracket that enables it to be easily removed when
required.

4.1 Wiring

All necessary cables and leads (other than a USB cable) are supplied with the unit.
•
Power supply cable (red +ve, blue -ve)
•
Power and data cable for connecting external devices such as a PDA or LX 7000...
•
PC cable with AC/DC power supply for PC communication
•
USB mini B to USB cable, if USB port will be used for PC communication (not delivery included)
The table below shows the cabling requirements for connection to other devices. When used with the LX
7000/LX 7007, LX 160si and LX 1600, the vario automatically powers the Colibri.
Colibri/LX20-2000
LX 160
LX 160 si
LX 1600
LX 5000
LX 7000
PDA
Duration of the flight, from take off until landing
Date of flight
Task distance
Average speed on task
Vario average and percentage of time spent climbing
Actual distance flown
P.and data cable
X
X
Note!
232 cross LXIPQ
adapter
X
X
20
www.lxnavigation.si
wrong.
Cable delivered
with LX unit
X
X
X
X
Dec 2006
