MAC/PHY commands

The following AT commands are MAC/PHY commands.

ID (Network ID)

Sets or displays the network identifier for the module. To communicate with other modules in a
network, the modules must have matching network identifiers. If you are using OEM network
identifiers, set ID to FFFF to use the factory value.
During join via commissioner, ID determines the extended pan ID of the network to join.
Parameter range
0 - 0x7FFF
Default
0x7FFF

BR (RF Data Rate)

Sets or displays the rate at which RF data is transmitted for all operational modes. Devices within a
network do not need to have matching data transmission rates. The BR setting does not control the
rate at which RF modules receive data.
Range
An integer from 0 through 8:
Value
0
1
2
3
4
5
6
7
8
Default
Default is 4 which indicates a data transmission rate of 290.8 kb per second.

PL (Power Level)

Sets or reads the power level at which the device transmits conducted power. Power levels are
approximate.
XLR PRO Radio Frequency (RF) Modem User Guide
Description
9.38 kb/s
28.14 kb/s
65.66 kb/s
140.7 kb/s
290.8 kb/s
590.9 kb/s
1.191 Mb/s
2.392 Mb/s
3.189 Mb/s
MAC/PHY commands
