Assembly Instructions
Mounting Rower Seat and Upper Mainframe
To install the rower seat, spread
the Left/Right Side Rails[2] slightly
and drop the Rower Seat[3] into
the track.
Note Seat indentation must face
rearward.
Note: Clean wheels and tracks weekly with a soft dry cloth in order to decrease the rate
of wear on both wheels and track.
Rower Seat
Bolt Assembly Close Up
M8x45mm Bolt
M8 Washer
M8 Standard Nut
M8 Nylock Nut
10
Seat Indentation
Next, install the Mainframe[1] onto
the Side Rail Assembly as shown.
You will need 8x M8x45mm Bolts
[11], 16x M8 Washers[7], 8x M8
Standard Nuts[8] and 8x M8
Nylock Nuts[9].
Secure the front Lower Bracket
first, then the Footboard but DO
NOT TIGHTEN. You may find that
the Lower Bracket Bolts can be
difficult to access. You can tighten
these bolts completely once the
Rower is standing in the vertical
position so for the moment, simply
align and loosely thread lower bolts/
.
nuts
Nylock Nuts must be
outside the standard nut
Nylock
and washer to properly
Nuts
secure assembly.
Nylock
Nuts
