- Page 1 PAC 2300 X OPERATING MANUAL LOCAL AIR CONDITIONER...
-
Page 2: Table Of Contents
Information marked with this symbol helps you to carry out your tasks quickly and safely. Follow the manual Information marked with this symbol indicates that the operating manual must be observed. Operating manual – local air conditioner PAC 2300 X... -
Page 3: Safety
Avoid electrical overload. • Before carrying out maintenance, care or repair work on the device, remove the mains plug from the mains socket. Hold onto the mains plug while doing so. Operating manual – local air conditioner PAC 2300 X... - Page 4 • have read and understood the operating manual, especially the Safety chapter. Maintenance tasks which require the housing to be opened must only be carried out by specialist companies for cooling and air-conditioning or by Trotec. Operating manual – local air conditioner PAC 2300 X...
-
Page 5: Information About The Device
Condensate outlet with sealing cap and rubber stopper Air inlet Exhaust air hose connection Hose connector with sealing cap and rubber stopper Air inlet with air filter Air outlet with ventilation flaps Operating manual – local air conditioner PAC 2300 X... -
Page 6: Transport And Storage
• with a cover to protect it from invasive dust if necessary • Place no further devices or objects on top of the device to prevent it from being damaged. • Remote batteries from the remote control. Operating manual – local air conditioner PAC 2300 X... - Page 7 • Keep air inlets and outlets as well as the exhaust air hose connection free. • Make sure that no curtains or other objects interfere with the air flow. Prior to initial start-up, insert the batteries in the remote control. Operating manual – local air conditioner PAC 2300 X...
- Page 8 3. Shove the hose adapter with exhaust air hose sideways into (optional). the air conditioner's exhaust air hose connection. • Install the exhaust air hose inclined with the air direction. Example with exhaust air hose: Operating manual – local air conditioner PAC 2300 X...
- Page 9 • The dimensions of the exhaust air hose were especially made to fit the device. Do not replace or extend the hose, for it could cause a malfunction. Operating manual – local air conditioner PAC 2300 X...
- Page 10 4. Screw the end of the exhaust air hose into the wall adapter. Connecting the power cable • Insert the mains plug into a properly secured mains socket. 5. When not in use, shut the opening by means of the cover plate. Operating manual – local air conditioner PAC 2300 X...
-
Page 11: Operation
3. Press the Power button (17). ð The device switches on. 4. Select the desired operating mode. The device switches off automatically when the condensation tank is full. P1 is displayed in the segment display (15). Operating manual – local air conditioner PAC 2300 X... - Page 12 ð The displayed temperature is converted to the other unit. Alternatively, this adjustment can be made via the remote control. 1. Press the arrow button (26) for 3 s. ð The displayed temperature is converted to the other unit. Operating manual – local air conditioner PAC 2300 X...
-
Page 13: Timer On Timer Off
FAN indication Indicates the fan stage. Operating mode Indicates the selected operating mode. indication SHORT ON/OFF Transmitter Displayed during communication between device indication and remote control. TIMER MODE TEMP TIMER SLEEP Operating manual – local air conditioner PAC 2300 X... - Page 14 3. In order to switch the night mode off, press the SLEEP button (24) once again. ð The night mode indication (32) disappears. ð The automatic stage remains unaffected. Operating manual – local air conditioner PAC 2300 X...
- Page 15 Upon reaching the preselected target temperature compressor and fan will be switched off automatically in order to reduce the power consumption. Once the preselected target temperature is exceeded, compressor and fan switch back on. Operating manual – local air conditioner PAC 2300 X...
-
Page 16: Errors And Faults
(in cooling mode). The compressor will not switch on unless the respective temperature is reached. • The compressor may start up with a delay of 3 min, as it is provided with an internal protection against direct restart. Operating manual – local air conditioner PAC 2300 X... -
Page 17: Maintenance
12. Date: ......Signature: ......Signature: ......Signature: ......Signature: ......13. Date: ......14. Date: ......15. Date: ......16. Date: ......Signature: ......Signature: ......Signature: ......Signature: ......Operating manual – local air conditioner PAC 2300 X... - Page 18 3. Allow the filter to dry completely. Do not insert a wet filter into the device! 4. Reinsert the air filter into the device. Operating manual – local air conditioner PAC 2300 X...
- Page 19 • Reconnect the device to the mains. If you do not intend to use the device for a considerable time: • Store the device according to the Storage chapter. 3. Drain the condensate. Operating manual – local air conditioner PAC 2300 X...
-
Page 20: Technical Annex
Weight 23.5 kg Wiring diagram PAC 2300 X BLACK(OR BROWN) WHITE(OR BLUE) POWER OPTIONAL GREEN(OR Y/G) POWER BOARD P03P04 P01P02 DISPLAY BOARD CN10 BLUE MOTOR COMPRESSOR BLUE BLACK BROWN BLUE BLACK Operating manual – local air conditioner PAC 2300 X... - Page 21 Capillary Assembly Packing cushion subassembly Single-phase Asynchronous Motor Evaporator assembly Gas valve assembly carton box Cover of air exhause volute shell upper packing foam Fan Shell Parts of compressor return pipe Operating manual – local air conditioner PAC 2300 X...
-
Page 22: Disposal
Directive 2006/66/EC of the European Parliament and of the Council of 6 September 2006 on batteries and accumulators. Please dispose of batteries and accumulators according to the relevant legal requirements. Operating manual – local air conditioner PAC 2300 X... - Page 24 Trotec GmbH & Co. KG Grebbener Str. 7 D-52525 Heinsberg +49 2452 962-400 +49 2452 962-200 info@trotec.com www.trotec.com...
