Summary of Contents for Trotec PAC 2010 S
- Page 1 PAC 2010 S OPERATING MANUAL LOCAL AIR CONDITIONER...
-
Page 2: Table Of Contents
No liability is accepted for damages resulting from improper use. In such a case, any warranty claims will be voided also. Operating manual – local air conditioner PAC 2010 S... -
Page 3: Safety
Avoid electrical overload. • Before carrying out maintenance, care or repair work on the device, remove the mains plug from the mains socket. Hold onto the mains plug while doing so. Operating manual – local air conditioner PAC 2010 S... -
Page 4: Information About The Device
Switch the device off and disconnect the power cable from the mains socket. Hold onto the mains plug while doing so. 2. Do not reconnect a defective device to the mains. Operating manual – local air conditioner PAC 2010 S... - Page 5 Device depiction Designation Control panel Air inlet Handle Wheels Air inlet with air filter Exhaust air hose connection Condensate outlet with rubber stopper Remote control Air outlet with ventilation flaps Operating manual – local air conditioner PAC 2010 S...
-
Page 6: Transport And Storage
• with a cover to protect it from invasive dust if necessary • Place no further devices or objects on top of the device to prevent it from being damaged. • Remote batteries from the remote control. Operating manual – local air conditioner PAC 2010 S... - Page 7 • Keep air inlets and outlets as well as the exhaust air hose connection free. • Make sure that no curtains or other objects interfere with the air flow. Prior to initial start-up, insert the batteries in the remote control. Operating manual – local air conditioner PAC 2010 S...
- Page 8 • Install the exhaust air hose inclined with the air direction. Example with exhaust air hose: 3. Shove the hose adapter with exhaust air hose sideways into the air conditioner's exhaust air hose connection. Operating manual – local air conditioner PAC 2010 S...
- Page 9 • The dimensions of the exhaust air hose were especially made to fit the device. Do not replace or extend the hose, for it could cause a malfunction. Operating manual – local air conditioner PAC 2010 S...
-
Page 10: Operation
Automatic switch-off timer function in increments of 1 hour (1 h to 24 h) Sleeping button Switching night mode on and off Info An acoustic signal is emitted each time a setting is activated. Operating manual – local air conditioner PAC 2010 S... - Page 11 ð The Dehumidifying LED (12) will be illuminated to indicate dehumidification mode. Info If the device is operated in a very humid environment, the accumulating condensate must be discharged at regular intervals (see chapter Condensate discharge). Operating manual – local air conditioner PAC 2010 S...
- Page 12 • The target temperature is preset to a fixed value of 24 °C • If you select 0 hours, the timer will be off. and cannot be changed manually. Operating manual – local air conditioner PAC 2010 S...
- Page 13 • Hold onto the mains plug while pulling the power cable out of the mains socket. • Empty the condensation tank, if need be. • Clean the device according to the Maintenance chapter. • Store the device according to the Storage chapter. Operating manual – local air conditioner PAC 2010 S...
-
Page 14: Errors And Faults
Condensation tank full Empty the condensation tank (see chapter Maintenance, Condensate mains and let it cool down for approx. 10 minutes before discharge (manual draining)). Should reconnecting it. the error still be displayed, please contact the customer service. Operating manual – local air conditioner PAC 2010 S... -
Page 15: Maintenance
12. Date: ......Signature: ......Signature: ......Signature: ......Signature: ......13. Date: ......14. Date: ......15. Date: ......16. Date: ......Signature: ......Signature: ......Signature: ......Signature: ......Operating manual – local air conditioner PAC 2010 S... - Page 16 3. Allow the filters to dry completely. Do not put any wet filters into the device! Operating manual – local air conditioner PAC 2010 S...
- Page 17 Refrigerant circuit • The entire refrigerant circuit is a maintenance-free, hermetically sealed system and may only be maintained or repaired by specialist companies for cooling and air- conditioning or by Trotec. Operating manual – local air conditioner PAC 2010 S...
-
Page 18: Technical Annex
310 x 310 x 640 (mm) Minimum distance to walls and other objects: top (A): 50 cm rear (B): 50 cm sides (C): 50 cm front (D): 50 cm Weight 21 kg Operating manual – local air conditioner PAC 2010 S... - Page 19 Spare parts drawing and list Note! The position numbers of the spare parts differ from those PAC 2010 S describing the positions of other parts mentioned in this operating manual. Operating manual – local air conditioner PAC 2010 S...
- Page 20 Out Centrifugal Fan Bolt of Compressor Inner Air Duct (up) Out Duct (Down) Front Cover wind channel Discharge tube Back Bracket Display Board Capillary Connect Tube remote control receiver capillary tube Operating manual – local air conditioner PAC 2010 S...
-
Page 21: Disposal
Directive 2006/66/EC of the European Parliament and of the Council of 6 September 2006 on batteries and accumulators. Please dispose of batteries and accumulators according to the relevant legal requirements. Operating manual – local air conditioner PAC 2010 S... - Page 22 Trotec GmbH & Co. KG Grebbener Str. 7 D-52525 Heinsberg +49 2452 962-400 +49 2452 962-200 info@trotec.com www.trotec.com...
