Axxess AX-ADBOX1 series Installation Instructions

AX-ADBOX1
AX-ADBOX Series main interface control box
Note: This is a general list for the AX-ADBOX1 lineup. Please see the individual
harnesses for exact features available.
• Provides accessory (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Used in amplified, non-amplified systems
• Retains chimes (GM)
• Turn signal click (GM)
• Provides NAV outputs (parking brake, reverse, mute, and V.S.S.)
• Pre-wired ASWC-1 harness included (ASWC-1 sold separately)
• Retains OnStar/OE Bluetooth
• Adjustable gain control for overall volume (on amplified systems)
• Adjustable gain control for chimes and OnStar (GM)
• Retains SYNC in Ford (if equipped)
• Adjustable gain control for SYNC (Ford)
• Retains Blind spot detection system in Chrysler/Dodge/Jeep (if equipped)
• High level speaker input
• Micro "B" USB updatable
• Retains balance and fade
• Retains digital fade (excluding Ford and VW vehicles)
Axxess Integrate
Installation instructions for AX-ADBOX1
axxessinterfaces.com
See application list inside
• AX-ADBOX1 interface
• 16-pin harness with stripped leads
• Cutting tool • Crimping tool • Tape • Connectors
(example: butt-connectors, bell caps, etc.)
CAUTION!
tery terminal before beginning any installation, unless the vehicle
manufacturer recommends against so. Please check with your local
Dealership for more information. All accessories, switches, climate
controls panels, and especially air bag indicator lights must be con-
nected before reconnecting the battery or cycling the ignition. Also,
do not remove the factory radio with the key in the on position, or the
vehicle running. It would be best to remove the key from the ignition
and then wait a few seconds before removing the factory radio.
•
