2012 Yamaha Boat
AR190
SX190
OWNER'S/OPERATOR'S MANUAL
U.S.A. Edition
LIT-18626-09-43
Read this manual carefully
before operating this boat.
F3A-F8199-10

Advertisement

Table of Contents
loading

Related Manuals for Yamaha AR190 2012

Summary of Contents for Yamaha AR190 2012

  • Page 1 2012 Yamaha Boat AR190 SX190 OWNER’S/OPERATOR’S MANUAL U.S.A. Edition LIT-18626-09-43 Read this manual carefully before operating this boat. F3A-F8199-10...
  • Page 2 Read this manual carefully before operating this boat. This manual should stay with the boat if it is sold.
  • Page 3 Important manual information To the owner Thank you for choosing a Yamaha boat. This Because Yamaha has a policy of continuing owner’s/operator’s manual contains informa- product improvement, this product may not be tion you will need for proper operation, main- exactly as described in this owner’s/opera-...

  • Page 4: Table Of Contents

    Table of contents General and important labels... 1 Control function operation ....29 Boat control functions ....29 Identification number records ... 1 Primary Identification (PRI-ID) Engine shut-off switch....29 number ........1 Main switch ......... 29 Hull Identification Number (HIN) ... 1 Remote control lever....
  • Page 5 Table of contents Equipment operation ...... 48 Operation and handling Seat..........48 requirements ........70 Driver’s seat ........ 48 Fuel requirement......70 Passenger’s seat (SX190) ..50 Fuel ..........70 Engine hood ........50 Engine oil requirement ....71 Storage compartments ....51 Engine oil ........
  • Page 6 Cleaning the boat ...... 103 Basic stain guide ....... 105 Consumer information....127 Battery care....... 106 Limited warranty......127 Long-term storage ......107 YAMAHA EXTENDED SERVICE Fuel system....... 107 (Y.E.S.) ........130 Lubrication......... 107 Sample float plan ......131 Grease points......107...

  • Page 7: General And Important Labels

    Hull Identification Number (HIN), and engine serial number in the spaces provided to assist you in ordering spare parts from your Yamaha Boat Dealer. Also record and keep these ID numbers in a separate place in case your boat is stolen.

  • Page 8: Emission Control Information

    U.S. EPA EXHAUST REGULATIONS FOR SI MARINE ENGINES. REFER TO THE OWNER'S MANUAL FOR MAINTENANCE SPECIFICATIONS AND ADJUSTMENTS. FELS(HC+NOx / CO): g/kW-hr MAX POWER: DISPLACEMENT: liters TROLLING SPEED: SPARK PLUG: SPARK PLUG GAP (mm): FUEL: UNLEADED REGULAR GASOLINE VALVE LASH (mm) IN: YAMAHA MOTOR CO.,LTD.

  • Page 9: Manufactured Date Label

    General and important labels Manufactured date label This label is attached to the engine unit. (See page 50 for engine hood opening and closing procedures and page 109 for engine cover re- moval and installation procedures.) Manufactured date label...

  • Page 10: Important Labels

    General and important labels Important labels Read the following labels before operating this boat. If you need any additional information, contact a Yamaha Boat Dealer.
  • Page 11 General and important labels...

  • Page 12: Warning Labels

    General and important labels Warning labels If any of these labels is damaged or missing, contact a Yamaha Boat Dealer for a replacement.
  • Page 13 General and important labels...
  • Page 14 General and important labels AR190...

  • Page 15: Other Labels

    DESIGN COMPLIANCE WITH NMMA REQUIREMENTS IS VERIFIED. MANUFACTURER RESPONSIBLE FOR PRODUCTION CONTROL. NATIONAL MARINE MANUFACTURERS ASSOCIATION All applicable electrical system components installed as original equipment meet appropriate U.S.C.G. requirements for ignition protection. (Ref. 33 CFR 183.410 and 183.440) YAMAHA 60E-83627-00...

  • Page 16: Safety Information

    The safe use and operation of this boat is operate the boat dependent upon the use of proper operat- Yamaha recommends a minimum operator ing techniques, as well as upon the com- age of 16 years old. mon sense, good judgment, and expertise Adults must supervise use by minors.

  • Page 17: Cruising Limitations

    Safety information Cruising limitations This is a high-performance boat—not a toy. Sharp turns or jumping wakes or waves can Scan constantly for people, objects, and increase the risk of back/spinal injury (pa- other watercraft. Be alert for conditions that ralysis), facial injuries, and broken legs, an- limit your visibility or block your vision of kles, and other bones.

  • Page 18: Operational Requirements

    Safety information Operational requirements Attach the engine shut-off cord (lanyard) to the PFD and keep it free from the steering All riders must wear a Coast Guard-ap- wheel or other controls so that the engine proved personal flotation device (PFD). stops if the operator accidentally leaves the helm.

  • Page 19: Required Equipment

    A mirror can also be used as an emergency Spare parts, such as fuses. signal. Contact your Yamaha Boat Dealer Navigation charts for the waters where you or the Coast Guard for more information. will be boating.

  • Page 20: Hazard Information

    Practice turning in an open area without obstructions until you have a good feel for the maneuver. This Yamaha boat is water-jet propelled. The pump is directly connected to the en- gine. This means that the jet thrust will pro- duce some movement whenever the engine is running.

  • Page 21: Night Operation

    Safety information Keep away from the intake grate while the Night operation engine is on. Items such as long hair, loose When using your boat before dawn or after clothing, or PFD straps can become entan- dusk, you must have both bow and stern gled in moving parts, resulting in severe in- lights operating.

  • Page 22: Water-Skiing

    Safety information Water-skiing A second person should be on board as a spotter to watch the skier; in most states, it You can use the boat to tow a water-skier, us- is required by law. Let the skier direct the ing the ski tow hook provided.

  • Page 23: Rules Of The Road

    Rules of the road Give-way vessel The vessel which does not have the right-of- Your Yamaha boat is legally considered a way has the duty to take positive and timely powerboat. Operation of the boat must be action to stay out of the way of the stand-on in accordance with the rules and regula- vessel.
  • Page 24 Safety information In the following illustration, your boat is in the Crossing When two power-driven vessels are crossing center. You should give the right-of-way to each other’s path close enough to run the risk any vessels shown in the white area (you are of collision, the vessel which has the other on the give-way vessel).
  • Page 25 Safety information Other special situations bers, and lights to show which side of the There are three other rules you should be buoy a boater should pass on when navigat- aware of when operating your boat around ing in a particular direction. The markings on other vessels.
  • Page 26 Safety information This system uses buoys and signs with distinctive shapes and colors to show regulatory or ad- visory information. These markers are white with black letters and orange borders. They signify speed zones, restricted areas, danger areas, and general information. Remember, markings may vary by geographic location.

  • Page 27: To Get More Boating Safety Information

    The Online Boating Safety Course, available obey all laws. through the watercraft section of the yamaha- Remember that pollution can be harmful to motor.com website, is a free, 50-question the environment. Do not refuel or add oil learning course available to the public.

  • Page 28: Description

    Description Boat glossary TERM DEFINITION The front part of the boat. Deck The “floor” or upper structure which covers the hull. Give-way The vessel which must yield the right-of-way when two boats meet. Gunwale The meeting junction of the deck and hull; the upper edge around the boat.

  • Page 29: Location Of Main Components

    Description Location of main components Exterior components AR190 Cleat 14 Front port seat (page 48, 51) Handgrip 15 Glove compartment (page 53) Front starboard seat (page 48, 51) 16 Fuel tank filler cap (page 70) Windshield (page 56) Driver’s seat (page 48) Bimini top (page 62) Stern light (page 43, 57) Tow pylon...
  • Page 30 Description SX190 Cleat Handgrip Front starboard seat (page 48, 51) Windshield (page 56) Driver’s seat (page 48) Bimini top (page 67) Stern light (page 43, 57) Battery (page 82, 106, 117) Bow light (page 43) 10 Bow eye 11 Front center seat (page 48, 51) 12 Front port seat (page 48, 51) 13 Glove compartment (page 53) 14 Fuel tank filler cap (page 70)
  • Page 31 Description SX190 4 11 12 13 16 17 4 20 Swim platform (page 59) 17 Rear center seat (page 48, 50) Wet storage compartment (page 55) 18 Bilge pump outlet (page 75) Ski tow hook 19 Cooling water pilot outlet (page 85) Handgrip 20 Flush hose connector (page 102) Rear port seat (page 48, 53)

  • Page 32: Stern Components

    Description Stern components Ladder (page 59) Stern eye Hull drain plug (page 74) Shift gate (page 31) Jet thrust nozzle Speed sensor Intake grate...

  • Page 33: Helm Components

    Description Helm components 6 7 8 CTSY NAV/ANC BILGE BLOWER HORN LIGHTS Bilge pump switch (page 42) Blower switch (page 42) Main switch (page 29) Speedometer (page 33) Multi-function tachometer (page 33) Courtesy light switch (page 43) Navigation and anchor lights switch (page 43) Horn switch (page 43) No-wake mode/cruise assist switch (page 43) 10 Switch circuit breaker (page 46)

  • Page 34: Engine Components

    Description Engine components Fuse holder (page 125) Blower (page 83) Engine oil filler cap (page 71) Engine cover (page 109) Dipstick (page 71) Air filter case (page 113) Spark plug/Spark plug cap/Ignition coil...

  • Page 35: Control Function Operation

    Control function operation Boat control functions Engine shut-off switch WARNING Always attach the engine shut-off cord (lanyard) to your PFD before starting the engine. Failure to attach the cord could result in a runaway boat if the operator is ejected. Do not attach the cord to clothing that could tear loose.

  • Page 36: Remote Control Lever

    Control function operation START: The starter motor will turn to start the engine. (When the main switch key is released, it re- turns automatically to “ON”.) TIP: The engine will not start when the clip is re- moved from the engine shut-off switch. The starter motor will turn over without the cord at- tached.
  • Page 37 Control function operation Neutral The shift gate is dropped down part way over the jet thrust nozzle. Some jet thrust is to the rear and some jet thrust is redirected forward. This balance of thrust acts like “neutral” to keep the boat from moving. Shift gate Jet thrust nozzle Reverse...

  • Page 38: Steering

    Control function operation Steering Tilt lever Your boat can be steered by turning the steer- WARNING ing wheel the same direction you wish to trav- Never touch the tilt lever during opera- el, to the right or left. When the steering wheel tion, otherwise the steering wheel could is turned, the angle of the jet thrust nozzle at suddenly change position, which may...

  • Page 39: Instrument Operation

    Instrument operation Speedometer Multi-function tachometer The speedometer shows the boat speed The multi-function tachometer is equipped against water. with an analog tachometer and an LCD. The speedometer starts operating when the The tachometer starts operating when the en- engine is started. The speedometer needle gine is started.

  • Page 40: Lcd

    Instrument operation To change the item displayed in the LCD: The LCD can display 2 of the following 11 (1) When the normal display of the LCD is items on the upper and lower display lines. shown, push the M button once to select the display line.
  • Page 41 Instrument operation Boat speed Battery voltage This display shows the boat speed against This display shows the battery voltage of the water in miles per hour or kilometers per hour. main battery. 1300 RPM 1300 RPM 0 mph 12.3 VDC Boat speed Battery voltage Engine speed...

  • Page 42: System Menu (Lcd)

    Instrument operation Fuel consumption per hour System menu (LCD) This display shows the current fuel consump- The system menu contains the following 7 tion in gallons per hour or liters per hour. items for making settings and confirming in- formation. 1300 RPM 1-Set Units 2-Contrast...
  • Page 43 Instrument operation 1-Set Units 2-Contrast The display units of the LCD can be set to The contrast of the LCD can be adjusted. “ENGLISH” or “METRIC”. To adjust the contrast: When “ENGLISH” is selected as the display (1) Push the M button to decrease the con- units of the LCD, values are shown in trast or push the T button to increase the feet/miles/gallons/degrees Fahrenheit.
  • Page 44 Instrument operation 3-Backlighting To display an item: The brightness level of the LCD can be ad- (1) Push the M button to scroll down through justed. the items or push the T button to scroll up. To adjust the brightness: (1) Push the M button to decrease the bright- ness or push the T button to increase the brightness.
  • Page 45 Instrument operation (2) Check that the display of LCD is normal, 6-Eng. Diag The Yamaha trouble code and item name can and then wait approximately 8 seconds to be displayed alternately in the LCD if there is return to the “Instr. Diag” display.

  • Page 46: Warnings

    Instrument operation 7-Large Font Warnings The font size of the LCD can be set to “Nor- Warnings are audible and visual indicators of mal” or “Large”. a fault condition. A warning will be displayed When “Normal” is selected, the normal dis- on the LCD.

  • Page 47: Engine Overheat Warning System

    Instrument operation Engine overheat warning system If water is not circulating, something may be This model is equipped with an engine over- clogging the intake grate. Refer to “Jet pump heat warning system. If the engine starts to clean-out procedure” on page 123. overheat, “Engine Over Temp”...

  • Page 48: Engine Oil Pressure Low Warning

    If an engine sensor malfunction or a short cir- cuit is detected, “Check Engine” will appear on the LCD and the buzzer will sound intermit- tently. If this occurs, reduce the engine speed, return to shore, and have a Yamaha Boat CTSY NAV/ANC Dealer check the engine.

  • Page 49: Courtesy Light Switch

    Instrument operation Courtesy light switch Push this switch to turn on the courtesy light inside the boat. Stern light Horn switch Push this switch to activate the horn. The horn Courtesy light can be used to signal other boats as required Navigation and anchor lights switch by the “Rules of the road”.
  • Page 50 Instrument operation No-wake mode TIP: The no-wake mode is useful for operating the The no-wake mode can be set to 3 engine boat at a steady speed with a minimal wake. speeds. To adjust the engine speed while the This is especially convenient when traveling no-wake mode is activated, push the plus side in harbors, channels, or other areas posted or minus side of the no-wake mode/cruise as-...
  • Page 51 Instrument operation Once “Cruise” is displayed in the LCD, To deactivate the cruise assist: the cruise assist is activated. Operate the remote control lever to decrease the engine speed to 3000 rpm or less. The LCD will return to the normal display and the cruise assist will be deactivated.

  • Page 52: Switch Circuit Breakers

    If the button under a switch pops out, push it back in with your fin- 5000 RPM ger. If it pops out again, ask a Yamaha Boat Dealer to inspect the electrical system. Cruise TIP:...

  • Page 53: Accessory Outlet

    Instrument operation Accessory outlet Stereo system There is a 12V DC outlet with a circuit breaker A stereo receiver is standard. The stereo sys- located in the glove compartment. tem consists of the receiver/CD player, speakers, and auxiliary input jack. Refer to NOTICE the stereo system Operation Manual included Do not use an automotive cigarette lighter...

  • Page 54: Equipment Operation

    Equipment operation Seat SX190 This boat is equipped with the following seats. Driver’s seat Passenger’s seat Front center seat Rear starboard seat Front port seat Rear center seat Front starboard seat Rear port seat AR190 Driver’s seat The driver’s seat can slide forward and rear- ward, and the seat can swivel.
  • Page 55 Equipment operation (2) Rotate the lever to port (left). (3) Swivel the seat to the desired position. If it is too easy or too difficult to rotate the seat, adjust the swivel friction by turning the swivel friction knob in or out. (3) Move the seat to the desired position, and then release the lever.

  • Page 56: Passenger's Seat (Sx190)

    Equipment operation Passenger’s seat (SX190) Engine hood The passenger’s seat can be adjusted in the The engine hood can be opened to access same ways as the driver’s seat. the engine. See “Driver’s seat” for instructions on adjust- The engine hood latch is located under the ing the seat.

  • Page 57: Storage Compartments

    Equipment operation Storage compartments This boat is equipped with the following con- venient on-board storage compartments. Make sure that the storage compartments are securely closed before getting underway. Anchor storage compartment The anchor storage compartment is located under the front center seat. To open the anchor storage compartment, pull the front center seat up.

  • Page 58: Rear Underseat Storage Compartment (Starboard)

    Equipment operation Rear underseat storage compartment (starboard) The rear underseat storage compartment (starboard) is located under the rear star- board seat. To open the rear underseat storage compart- ment (starboard), pull the rear starboard seat Ski locker To close the ski locker: (1) Close the ski locker lid.

  • Page 59: Rear Underseat Storage Compartment (Port)

    Equipment operation Rear underseat storage compartment Glove compartment (port) The glove compartment is located on the port The rear underseat storage compartment console. (port) is located under the rear port seat. To open the glove compartment: (1) Turn the glove compartment knob 90 ° to WARNING the right, and then open the glove com- Do not carry any flammable substances in...

  • Page 60: Port Console Storage Compartment

    Equipment operation To close the glove compartment: Port console storage compartment (1) Lift the glove compartment lid slightly to The port console storage compartment is a release the support spring lock, and then large storage compartment that is located in lower the lid.

  • Page 61: Wet Storage Compartment

    Equipment operation Wet storage compartment Walk-through The wet storage compartment is located un- Front walk-through der the swim platform. This boat has a large bow area where two To open the wet storage compartment: adults can sit comfortably with their legs out- (1) Pull the lock handles up.

  • Page 62: Windshield

    Equipment operation Windshield To open the windshield: (1) Turn the windshield latches to the unlock The windshield can be opened and closed. position, and then open the windshield. WARNING (2) Unsnap the retaining strap from the strap To avoid injury, the windshield must be se- base, and then snap it onto the wind- cured when the boat is in motion.

  • Page 63: Stern Light

    Equipment operation Stern light (2) Remove the stern light from the stern light holder. The boat is equipped with a removable stern AR190 light. The storage location for the stern light is dif- ferent depending on the model. AR190: Rear underseat storage compartment (starboard) SX190: Ski locker To set up the stern light:...
  • Page 64 Equipment operation (3) Slide stern light stoppers A and B apart to (5) Open the cap of the stern light socket, fit disconnect them. the protrusion on the stern light into the slot in the socket, and then install the light into the socket.

  • Page 65: Swim Platform And Ladder

    Equipment operation To store the stern light: Swim platform and ladder (1) Pull stern light stopper B upward, remove WARNING the stern light, and then close the cap of Stay away from the swim platform area the stern light socket. while the engine is running.

  • Page 66: Wakeboard Tower (Ar190)

    Equipment operation To use the ladder: Wakeboard tower (AR190) (1) Unhook the ladder strap. The wakeboard tower is provided as an ele- vated tow point suitable for wakeboards and similar towable recreational equipment. The tow pylon can be used to attach a standard ski rope or other tow-rope.

  • Page 67: Collapsing And Setting Up The Wakeboard Tower

    Equipment operation To collapse the wakeboard tower: NOTICE (1) Loosen the lower support knob on both Do not modify the wakeboard tower to tow sides of each support pole. from any other point or to carry accesso- ries not designed for it. The wakeboard tower could be damaged.

  • Page 68: Bimini Top (Ar190)

    Equipment operation (3) Lower the wakeboard tower, and then in- Bimini top (AR190) stall the short tower storage supports. Setting up the bimini top To set up the bimini top: (1) Unfasten the buckles and pull the bimini top toward the bow. Wakeboard tower Buckle (2) While supporting the bimini top, unhook...
  • Page 69 Equipment operation (3) Push the snap button and extend each (5) Remove the storage cover, and then un- forward support pole until it is locked in wrap the bimini top. place. Storage cover Snap button (6) Unzip the flaps, and then zip the flaps Forward support pole around the wakeboard tower.

  • Page 70: Storing The Bimini Top

    Equipment operation (7) While pulling the front pole down, push Storing the bimini top the snap button and shorten each for- To store the bimini top: ward support pole until it is locked in (1) While pulling the front pole down slightly, place to tighten the bimini top.
  • Page 71 Equipment operation (3) Wrap the bimini top around the front pole, (4) While supporting the front pole, remove and then install the storage cover. each forward support pole from the wake- board tower by removing the lock pin. Bimini top Forward support pole Forward support pole mounting bracket Lock pin...

  • Page 72: Trailering With The Bimini Top

    Bimini top when it is being trailered. When the boat is Lock pin trailered with a genuine Yamaha boat cover, Installing the bimini top simply store the bimini top in the fully col- lapsed position and install the storage cover.

  • Page 73: Bimini Top (Sx190)

    Equipment operation Bimini top (SX190) (3) Remove the storage cover, unfold the bimini top, and pull it toward the bow. Setting up the bimini top To set up the bimini top: (1) Raise the bimini top, and then unhook the rear support poles from the main pole.

  • Page 74: Storing The Bimini Top In The Upright Position

    Equipment operation (5) Tighten the front straps so that the top is To store the bimini top in the upright position: snug and wrinkle free. (1) Loosen each front strap, and then un- hook the latch from the strap eye. NOTICE Front strap Do not exceed 72 km/h (45 mph) with the...

  • Page 75: Storing The Bimini Top In The Fully Collapsed Position

    To store the bimini top in the fully collapsed when it is being trailered. When the boat is position: trailered with a genuine Yamaha boat cover, (1) Follow the above steps for “Storing the simply store the bimini top in the fully col- bimini top in the upright position”.

  • Page 76: Operation And Handling Requirements

    To avoid fires and mance problems. explosions and to reduce the risk of in- Yamaha does not recommend gasohol con- jury when refueling, follow these in- taining methanol because it can cause fuel structions.

  • Page 77: Engine Oil Requirement

    While many additives available may reduce deposits, Yamaha recommends the use of Ring Free Fuel Additive, available from a Yamaha Boat Dealer. Ring Free Fuel Additive has repeatedly proven its ability to clean com- bustion deposits from inside the engine, nota- bly in the critical piston-ring-land area, and fuel system components.
  • Page 78 (5) If the engine oil level is significantly above (3) Remove the dipstick and wipe it clean. the maximum level mark, consult a Yamaha Boat Dealer. If the engine oil lev- el is below the minimum level mark, add engine oil.

  • Page 79: Draining The Bilge Water

    Operation and handling requirements Draining the bilge water (1) Remove the floor mat. NOTICE Do not run the engine at full throttle when bilge water remains in the engine compartment. The bilge water can splash into the engine, which can result in severe damage.
  • Page 80 Operation and handling requirements (8) Turn the lock handles, and make sure Draining the bilge water from the hull Remove the hull drain plugs at the stern to that the fuel tank compartment cover is drain the water, and then securely install the securely closed.

  • Page 81: Draining The Bilge Water On Water

    Operation and handling requirements Draining the bilge water on water This model is equipped with a self-draining deck and bilge pump to drain the bilge water on water. BILGE BLOWER Self-draining deck Most water which enters the deck area drains automatically out the stern through the large drain hole in the deck.

  • Page 82: First-Time Operation

    First-time operation Engine break-in NOTICE Failure to perform the engine break-in could result in reduced engine life or even severe engine damage. The engine break-in period is essential to al- low the various components of the engine to wear and polish themselves to the correct op- erating clearances.

  • Page 83: Pre-Operation Checks

    Do not operate the boat if you find any problem. If a problem cannot be corrected by the procedures provided in this manual, have the boat inspected by a Yamaha Boat Dealer. Pre-operation checklist Before operating this boat, perform the checks in the following checklist. Always follow the inspec- tion and maintenance procedures and schedules described in this owner’s/operator’s manual.

  • Page 84: Pre-Operation Check Points

    Pre-operation checks Pre-operation check points Remote control lever checks Pre-launch checks WARNING Perform the pre-launch checks in the pre-op- Do not touch the shift gate while the re- eration checklist while the boat is on land. mote control lever is being operated, oth- erwise you could be pinched.

  • Page 85: Fire Extinguisher Check

    A fire extinguisher is not standard equipment with this boat. If you do not have a fire extin- guisher, contact your local Yamaha Boat Dealer or fire extinguisher dealer for one meeting the proper specifications.

  • Page 86: Access Port Cap Check

    Pre-operation checks A FIRE-PORT™ is mounted below the rear center seat. Use this port to spray the con- tents of a fire extinguisher into the engine compartment if a fire breaks out in the engine area. WARNING! If there is a fire in the en- gine compartment, opening the hatch will add more oxygen to the fire, increasing the risk of a larger fire or an explosion.

  • Page 87: Jet Intake Checks

    Pre-operation checks then remove the engine shut-off cord (lan- yard) from the engine shut-off switch. Fuel system checks Refer to “Checking the fuel system” on page 112 for the correct procedure. Engine oil level check Make sure that the engine oil level is between the minimum level mark and maximum level mark on the dipstick.

  • Page 88: Battery Check

    Pre-operation checks Battery check Drain plug check Make sure that the battery terminals are not Loosen the drain plugs and remove them, and damaged and that the battery leads are con- then make sure that the plugs are not dam- nected properly.

  • Page 89: Blower Switch Check

    Engine compartment drain plug loose electrical connections. Contact a Yamaha Boat Dealer if there is a problem you cannot locate or correct. Make sure that the blower operates properly when the blower switch is pushed.

  • Page 90: Navigation And Anchor Lights Switch Check

    Pre-operation checks Push the blower switch to operate the blower (3) Push the bottom of the navigation and and ventilate the engine compartment for at anchor lights switch and check that only least 4 minutes. the stern light comes on. (4) Put the navigation and anchor lights Navigation and anchor lights switch switch in the middle position and check...

  • Page 91: Post-Launch Checks

    Pre-operation checks Cooling water pilot outlet check Check that water comes out from the pilot out- let while the engine is running in the water. If water is not circulating, something may be clogging the intake grate. Refer to “Jet pump clean-out procedure”...

  • Page 92: Fuel Level Check

    Pre-operation checks Fuel level check Select the fuel level display of the multi-func- tion tachometer. (See page 35 for information on selecting the fuel level display.) 1300 RPM Fuel level Add fuel if necessary. (See page 70 for infor- mation on filling the fuel tank.)

  • Page 93: Operation

    Before operating your boat, become fa- 526 kg (1160 lb) miliar with all controls. Consult a Yamaha Boat Dealer about any control Learning to operate your boat or function you do not fully understand. Before boating, always perform the pre-oper- Failure to understand how the controls ation checks listed on page 77.
  • Page 94 Contact a Yamaha Boat Dealer if there is a problem you cannot locate or correct. Attach the engine shut-off cord (lanyard) to your PFD before operating.

  • Page 95: Stopping The Engine

    Operation off, allowing the boat to continue to NOTICE run and cause an accident. Never turn the main switch to the start position while the engine is running. The starter mechanism could be damaged. If the starter motor is engaged continu- ously for more than 5 seconds, the bat- tery will become quickly discharged and it will be impossible to start the engine.

  • Page 96: Leaving A Dock

    Operation Turning the boat WARNING Do not pull the remote control lever back to idle when trying to steer away from BILGE BLOWER objects — you need throttle to steer. Be sure passengers are holding on be- fore making turns. An unprepared pas- senger could lose balance and fall.
  • Page 97 Operation B. Less throttle produces low thrust, so the D. If the boat is moving and the remote con- boat will turn more gradually. trol lever is in neutral position, or if there is no thrust because the engine is stopped, the boat will go straight even though the steering wheel is turned.

  • Page 98: Boating With Passengers

    Operation Boating with passengers You will lose steering control if you completely pull the throttle back to idle. WARNING You need throttle to steer. When passengers are on board, make Do not use the reverse function to slow sure they are seated and holding onto the down or stop the boat from planing handgrips before you start to accelerate.

  • Page 99: Boarding From The Water

    Operation Boarding from the water Boarding from a dock or landing jetty (1) Board the boat from the side. One person WARNING should board at a time by stepping into To avoid severe injury or death, do not the boat. Never jump in. Avoid stepping board from the rear, use swim platform, or on slick gelcoat surfaces on the boat’s swim behind boat if engine is running.

  • Page 100: Beaching

    Operation Wind or current pushing boat away from Beaching dock: NOTICE Slowly approach the dock at about a 45° an- Small pebbles, sand, seaweed, and oth- gle. Secure the bow to the dock, and then use er debris can be sucked into the jet in- engine thrust or a boat hook to gently move take and impair or damage the impeller.

  • Page 101: Anchoring

    There will be swells and wakes from other type anchor is suitable for most applications; boats, etc. your Yamaha Boat Dealer can help you The best way to cross wakes and swells is choose an anchor. with the least jolt to you and the boat. Small...

  • Page 102: Post-Operation Checks

    Operation To cross a wake or swell, change your speed Post-operation checks and choose the angle at which you cross the These post-operation procedures are devel- wake or swell. Usually, a slower speed and oped to help preserve the long-term appear- “quartering”...
  • Page 103 Operation (3) Stop the engine. (9) Spray a rust inhibitor, such as Yamaha (4) Wash down the hull, helm, and jet drive Silicone Protectant and Lubricant, on me- unit with fresh water. tallic parts to minimize corrosion. (5) Open the rear platform hatch and remove the access port cap to let any water drain that has pooled on it.

  • Page 104: Trailering

    Trailering Trailering the boat dentally comes loose from the hitch ball. Crisscross the chains under the trailer tongue WARNING so the tongue will not hit the road surface if it Avoid accident and injury from improper falls loose. Rig the chains as tightly as possi- trailering: ble while allowing just enough slack to permit The trailer must be matched for the...

  • Page 105: Backing Your Trailer

    Trailering Secure the bow of the boat to the trailer with turns more sharply around the corner than the winch line and also with the chain. Se- the towing vehicle. cure the stern eyes to the trailer with tie- downs. Backing your trailer It takes practice to back a trailer successfully.

  • Page 106: Loading

    Trailering server while standing to the side of the trailer. Stop when the tops of the trailer’s fenders are about 3 inches above the wa- terline. (3) With the boat moving at the slowest idle speed, guide the boat onto the support rails.

  • Page 107: Lifting

    Trailering Lifting NOTICE Do not attach lifting cables to the bow eye, cleats, stern eyes, ski tow hook, or hand- grips. Serious damage to the boat can oc- cur. Use only a sling designed specifically for lifting boats. If you need to remove the boat from the water without a trailer, use these guidelines: Stern eye Use a sling-type lifting mechanism de-...

  • Page 108: Care And Storage

    Care and storage Post-operation care (4) Make sure that the area around the boat is clear, and then start the engine. Imme- Flushing the cooling system diately after the engine starts, fully turn Cooling system flushing is essential to pre- the water supply on so that water flows vent the cooling system from clogging up with out continually from the jet thrust nozzle...

  • Page 109: Cleaning The Boat

    ® Quality Yamaclean , Yamashield™, and oth- er Yamalube care products are available from your Yamaha Boat Dealer. (1) Remove the fuel tank compartment drain plug to drain the water. (See page 73 for fuel tank compartment drain plug removal and installation procedures.) Reinstall the...
  • Page 110 Con- tance, temporarily reinstall the cap and sult a Yamaha Boat Dealer if you want close the hatch until you get home. Open product other than Yamaclean Vinyl Protectant.

  • Page 111: Basic Stain Guide

    Care and storage Basic stain guide Here are basic steps to remove common stains from boat upholstery. Consult a Yamaha Boat Dealer or upholstery-cleaning professional for difficult stains. TYPE OF STAIN STEPS (rinse with clean, warm water and then dry after application) General care/Dirt —...

  • Page 112: Battery Care

    Care and storage Battery care (3) If the battery will be stored for a longer If the boat will not be used for more than a period, check the specific gravity of the month, remove the battery and store it in a battery at least once a month and re- cool, dark place.

  • Page 113: Long-Term Storage

    Consult a Yamaha Boat Dealer or other qualified mechanic if the fuel system is to be drained instead. Lubrication It is advisable to take the boat to a Yamaha Boat Dealer to have the engine fogged for long-term storage. Grease points...
  • Page 114 The first service should be done after 10 hours or 1 month by a Yamaha Boat Dealer. Fill the bearing housing with water-resistant grease through the grease nipple.

  • Page 115: Maintenance

    If you are not familiar with ma- chine servicing, this work should be done by a Yamaha Boat Dealer or other qualified mechanic. Maintenance, replacement, or repair of the emission control devices and system may be...
  • Page 116 Maintenance (3) Lift up the engine cover and remove it. Engine cover To install the engine cover: (1) Place the engine cover in its original posi- tion, and then push it down. (2) Install the engine cover screws, and then tighten them to the specified torque.

  • Page 117: Periodic Maintenance Chart

    Frequency of maintenance operations may be adjusted according to the operating conditions, but the following table gives general guidelines. G: Indicates the checkups which you may do yourself. I: Indicates work to be done by a Yamaha Boat Dealer. Thereafter Page...

  • Page 118: Checking The Fuel System

    (2) Open the engine hood, and then check Check the fuel system for leaks, cracks, and the fuel filler hose. malfunctions. If any problem is found, consult a Yamaha Boat Dealer. Checking points: Fuel tank for leakage Fuel hose joints for leakage...

  • Page 119: Checking The Air Filter

    (3) Loosen the clamp screw, and then dis- water is found in the fuel system, take the boat connect the air intake pipe from the throt- to a Yamaha Boat Dealer for service. tle body. Checking the air filter The air filter must be checked at the intervals specified in the periodic maintenance chart.

  • Page 120: Engine Oil And Oil Filter

    Maintenance (4) Unfasten the hooks. (6) Remove the screws, and then remove the air filter element. Air filter case Hook Screw Air filter element TIP: (7) Check that there is no dirt or oil on the air There are a total of 8 hooks on the top, bot- filter element.

  • Page 121: Checking The Steering Cable

    (2) Operate the remote control lever several times to make sure that operation is It is recommended to have a Yamaha Boat smooth throughout the whole range. Dealer change the engine oil and oil filter. However, if you choose to change the oil filter...

  • Page 122: Checking The Shift Gate Mechanism

    If the shift gate does not operate correctly, ask ver is moved farther forward. your authorized Yamaha Boat Dealer for ser- vice. Shift gate Fully open position...

  • Page 123: Checking The Sacrificial Anode

    Galvanic corro- Ask a Yamaha Boat Dealer for this service or sion can damage metal surfaces below the you can do it yourself if you have a torque waterline on any boat, particularly in salt wa- wrench of the proper type.
  • Page 124 Maintenance These general guidelines apply to many com- Recharging monly used battery types (but not, for exam- WARNING ple, to maintenance-free batteries). Consult When charging the battery, keep it well the battery manufacturer’s instructions before away from sparks and open flames, as it performing battery maintenance.

  • Page 125: Specifications

    Specifications Specifications ITEM Specification Boat capacity Maximum people on board 8 person Maximum load capacity 562 kg (1240 lb) Dimensions Length 5800 mm (228.3 in) Beam 2400 mm (94.5 in) Height AR190 2600 mm (102.4 in) SX190 1700 mm (66.9 in) Draft (Light) 390 mm (15.4 in) Draft (Heavy)
  • Page 126 Specifications ITEM Specification Drive unit Propulsion system Jet pump Jet pump type Axial flow, single stage Impeller rotation Counterclockwise Impeller pitch angle 13.8° Transmission Direct drive from engine Jet thrust nozzle angle 23.0+23.0° Jet thrust nozzle trim angle 3° Fuel and oil Recommended fuel Regular unleaded gasoline Minimum octane rating (PON)

  • Page 127: Trouble Recovery

    If you have any trouble with your boat, use this section to check for the possible cause. If you cannot find the cause or if the procedure for replacement or repair is not described in this own- er’s/operator’s manual, ask your Yamaha Boat Dealer or a qualified mechanic for the proper service.
  • Page 128 POSSIBLE CAUSE REMEDY PAGE Engine runs Fuel Empty Refill as soon as possible irregularly or Stale or contaminat- Have serviced by Yamaha — stalls Boat Dealer Fuel filter Water or dust collect- Have serviced by Yamaha — Boat Dealer Fuel tank...

  • Page 129: Emergency Procedures

    Trouble recovery Emergency procedures Jet pump clean-out procedure WARNING Severe injury or death may result if you ig- nore any of the following: Turn off and remove the main switch key, remove the clip from the engine shut-off switch, and wait for all move- ment to stop before removing the ac- cess port cap.

  • Page 130: Jump-Starting

    Trouble recovery jet thrust nozzle. If you cannot remove (9) Close the rear platform hatch. (See page the debris, consult a Yamaha Boat Deal- 55.) NOTICE (6) To reinstall the access port cap, first Be sure the access port cap is locked clean off any sand or other foreign matter securely in place.

  • Page 131: Fuse Replacement

    Trouble recovery (3) Connect the other end of the negative (–) Fuse replacement jumper cable to an engine hanger. WARNING NOTICE: Be sure all connections are Do not use fuses of a higher amperage secure and correct before attempting than recommended. Substitution with a to start the engine.

  • Page 132: Towing The Boat

    Trouble recovery Towing the boat WARNING The operator of the towing boat must keep speed to a minimum and avoid traf- fic or obstacles which could be a hazard to either boat. The towing line should be long enough so the towed boat will not collide with the towing boat when slowing down.

  • Page 133: Consumer Information

    Owner’s Manual. The owner of the boat shall give notice to an authorized Yamaha Boat dealer of any and all appar- ent defects within ten (10) days of discovery and make the boat available at that time for inspection and repairs at the dealer’s place of business.
  • Page 134 SPECIFIC PARTS EXCLUDED FROM WARRANTY; Parts replaced due to normal wear or routine maintenance such as oil, spark plugs, fuel filters, impeller and liner, and anodes are not covered by warranty. Charges for transporting the boat to and from an authorized Yamaha Boat dealer are excluded from warranty coverage.
  • Page 135 2. Explain the operation, maintenance, and warranty requirements to your satisfaction at the time of sale, and upon your request at any later date. In addition, each Yamaha Boat dealer is held responsible for his setup, service and warranty repair work.

  • Page 136: Yamaha Extended Service (Y.e.s.)

    5-year standard protection on available to Yamaha owners like you, and only the hull. while your Yamaha is still within the first year • of the Yamaha Limited Warranty period. So Y.E.S. is designed and administered by the...

  • Page 137: Sample Float Plan

    Sample float plan Leave a float plan with a responsible person on shore before boating. The example below can be copied and used. FLOAT PLAN VESSEL INFORMATION BOAT MAKE: Yamaha MOTOR TYPE: MODEL: LENGTH: REGISTRATION NO: DECK COLOR: HULL COLOR:...
  • Page 138 INDEX Access port cap check ......80 Check engine warning......42 Accessory outlet........47 Cleaning the boat ........103 Additional equipment Cooling water pilot outlet check ....85 recommendations ......... 13 Courtesy light switch ........ 43 Air filter, checking........113 Crossing wakes and swells ......
  • Page 139 INDEX Getting to know your boat ......87 Navigation and anchor lights switch ..43 Glossary, boat .......... 22 Navigation and anchor lights switch Glove compartment........53 check ............ 84 Grease points......... 107 Night operation ......... 15 No-wake mode ......... 43 No-wake mode/cruise assist switch ..
  • Page 140 Turning the boat ........90 Wakeboard tower (AR190)....... 60 Wakeboard tower, collapsing and setting up ..........61 Walk-through..........55 Warning definition table......40 Warnings ..........40 Water-skiing ..........16 Wet storage compartment......55 Windshield..........56 YAMAHA EXTENDED SERVICE (Y.E.S.) ..........130...
  • Page 141 Genuine Yamaha Accessories – Yamaha only offers accessories that meet our high standards for quality and performance. Buy with confidence, knowing your Genuine Yamaha Accessories will fit right and perform right – right out of the box. Yamalube – Take care of your Yamaha with legendary Yamalube oils, lubricants, and care products.
  • Page 142 Printed in USA November 2011–0.9 × 1 CR...

This manual is also suitable for:

Sx190 2012

Table of Contents
