Zero Clearance Direct Vent Gas Fireplace
STYLE
Left Corner CC40LE-NG / CC40LE-LP
Right Corner CC40RE-NG / CC40RE-LP
Warning
Fire or explosion Hazard
failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach you gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
919-740a
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
City Series
MODEL
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
®
Owners &
Installation Manual
www.regency-fire.com
04.26.17
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Regency CC40LE-NG
Summary of Contents for Regency CC40LE-NG
- Page 1 Zero Clearance Direct Vent Gas Fireplace Installation Manual www.regency-fire.com STYLE MODEL Left Corner CC40LE-NG / CC40LE-LP Right Corner CC40RE-NG / CC40RE-LP Warning Fire or explosion Hazard failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- Page 2 To the New Owner: Congratulations! You are the owner of a state-of-the-art Gas Fireplace by REGENCY . The City Series are hand crafted appliances and ® have been designed to provide you with all the warmth and charm of a wood fireplace at the flick of a switch. The CC40LE /CC40RE City Series have been approved by Intertek for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow. Please take a moment now to acquaint yourself with these instructions and the many features of your Regency Fireplace. ® This appliance may be installed in an aftermarket, permanently lo- cated, manufactured home (USA only) or mobile home, where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the rating plate.
-
Page 3: Manufactured Mobile Home Requirements
MANUFACTURED MOBILE HOME REQUIREMENTS INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE This Regency product has been tested and listed by Intertek as a Direct Vent Wall Furnace to the following standards: VENTED GAS ® DECORATIVE FIREPLACE CAN/CGA-2.17-M91, and ANSI Z21.50-2014 • CSA 2.22-2014 and GAS-FIRED APPLIANCES FOR USE AT HIGH ALTITUDES CAN/CGA 2.17-M91. This Direct Vent System Appliance must be installed in accordance with the manufacturer's installation instructions and the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, or the current Standard of Fire Safety Criteria for Manufactured Home Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240-MH Mobile Home Standard in Canada. This appliance installation must comply with the manufacturer's installation instructions and local codes, if any. In the absence of local codes follow the current National Fuel Gas Code, ANSI Z223.1 and the current National Electrical Code ANSI/NFPA 70 in the U.S.A., and the current CAN/CGA B149 Gas Installation Code and the current Canadian Electrical Code CSA C22.1 in Canada. This Regency mobile/manufactured home listed appliance comes factory equipped with four 1/4" diameter holes located near each corner ® of the base. Fasten the fireplace in place using screw, inserted through the holes. This appliance comes equipped with a dedicated #8 Ground Lug for attachment of the ground wire to the steel chassis as applicable to local codes. See the "Wiring Diagram" section. The appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1. This appliance may only be installed in an aftermarket permanently located, manufactured home (U.S.A only) or mobile home, where not prohibited by local codes. This appliance can only be used with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases, unless a certified kit is used. Ensure that structural members are not cut or weakened during installation. City Series |... -
Page 4: Table Of Contents
table of contents Copy of Safety Decal .............5 Dura-Vent Vertical Termination ........41 4" x 6-5/8" venting ............41 Installation..............9-60 Vertical Termination 4" x 6-7/8" venting .....42 Important Message ............9 Vertical flue extension kit (part #946-756) ....43 Before You Start .............9 Ceiling Firestop / firestop spacer (part #946-757) ..43 General Safety Information ..........10 High Elevation ..............44 Installation Checklist ............10 Gas Line Installation ............44 Heatwave Duct System ..........10 Pilot Adjustment ............44 Locating Your Gas Fireplace ........11 Gas Pipe Pressure Testing ..........44 Unit Assembly Prior to Installation .......11 885 S.I.T. Valve Description .........44 Clearances CC40LE/CC40RE ........13 Wiring Diagrams ............45 Clearances CC40LE/CC40RE . -
Page 5: Copy Of Safety Decal
This is a copy of the label that accompanies Direct Vent Gas Fireplace. We have printed a copy of the contents here for your review. The safety label is located on the front inside base of the unit, visible when the outer front panel is removed. NOTE: Regency units are constantly being improved. Check ® the label on the unit and if there is a difference, the label on the unit is the correct one. Copy of Safety Decal For the State of Massachusetts, installation and repair must be done by a plumber or gasfitter licensed in the Commonwealth of Massachusetts. For the State of Massachusetts, flexible con- nectors shall not exceed 36 inches in length. For the State of Massachusetts, the appli- ances individual manual shut-off must be a t-handle type valve. The State of Massachusetts requires the installation of a carbon monoxide alarm in accordance with NFPA 720 and a CO alarm with battery back up in the same room where the gas appliance is installed. -
Page 6: For The State Of Massachusetts Only
requirements MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:... - Page 7 dimensions CC40LE (Left Corner) dimensions " 1203mm " " 616mm 587mm " 4" 171mm 102mm 48" " 1219mm 475mm " " 1108mm 448mm " " 375mm 1089mm Note: Height Dimension may vary depending on the height of the leveling legs. Dimensions will appear as (inches)" / (metric)mm throughout this manual. The inches are rounded to the nearest 1/16" when converted, when greater accuracy is required, use the metric dimensions. Note: These units are non-load bearing. ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY.
- Page 8 dimensions CC40RE (Right Corner) dimensions " 1203mm " " 587mm 616mm 4" " 102mm 171mm 48" 1219mm " 475mm " 17 5/8" 1108mm [448mm] " 375mm Note: Height Dimension may vary depending on the height of the leveling legs. Dimensions will appear as (inches)" / (metric)mm throughout this manual. The inches are rounded to the nearest 1/16" when converted, when greater accuracy is required, use the metric dimensions. Note: These units are non-load bearing. | City Series...
-
Page 9: Installation
installation Important Message WE RECOMMEND REMOVING THE CHILDREN AND ADULTS SHOULD BE SAVE THESE INSTRUCTIONS GLASS WITH THE GLASS VACUUM ALERTED TO THE HAZARDS OF HIGH HOLDERS SUPPLIED BY THE MANU- SURFACE TEMPERATURES, ESPE- City Series Direct Vent Fireplaces must be FACTURER. -
Page 10: General Safety Information
installation General Safety Information Installation Checklist This includes: 1. The appliance installation must conform with 1. Locate appliance. Refer to the following sections: a) Locating Your Fireplace 1. Clocking the appliance to ensure the correct local codes or, in the absence of local codes, b) Clearances firing rate (rate noted on label 28,500 Btu/h NG/ with the current Canadian or National Gas c) Combustible Mantel Clearances LP) after burning appliance for 15 minutes. -
Page 11: Locating Your Gas Fireplace
installation Locating Your Unit Assembly Prior to Installation Gas Fireplace Before you start 1. When selecting a location for your fireplace, The CC40LE/CC40RE has 4 standoffs, 2 on one side and 2 at the back that need assembly before ensure that the clearances are met. installation. 2. The appliance must be installed on a flat, solid, continuous surface For example a wood, metal Side and back standoff assembly CC40LE/CC40RE or concrete floor or in a raised (on the wall) ap- The standoffs are shipped in a flat position and must be folded into shape and attached. plication. The appliance must be installed on a metal or wood panel extending the full width Take each standoff off the unit by removing one screw and bend into the correct shape. Slot the 2 tabs and depth of the appliance. of the stand off into the slots in the unit and attach the other end with one screw. 3. The CC40LE/CC40RE Direct Vent Gas Fire- place can be installed in a recessed position or framed out into the room as in A and B. See... -
Page 12: Levelling Bolts
tooltip installation Nailing strips CC40LE/CC40RE Nailing strips are shipped folded flat against the unit. Fold nailing strips out 90º before installing unit. Secure nailing strips to framing using wood or metal screws. Side nailing strip CC40RE tooltip Side nailing strip CC40LE Top nailing strip Top Nailing strip CC40LE/CC40RE Nailing strip is shipped with the appliance and will need to be attached. Note that the nailing strips are not required if using the optional chase or extended framing kit and may be recycled. Top nailing strip 1. S ecure nailing strip to appliance with 2 screws. 2. S ecure nailing strips to framing using wood or metal screws. -
Page 13: Clearances Cc40Le/Cc40Re
installation Clearances CC40LE/CC40RE The clearances listed below are Minimum distances unless otherwise stated: A major cause of chimney related fires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance that this fireplace and vent system be installed only in accordance with these instructions. Note: CC40LE shown in illustration. Clearances will be the same for the CC40RE. Flue Clearances to Combustibles Clearance: single sided Dimension Measured From: Horizontal - Top 3" A: Mantel Height (min.) Top of Fireplace Opening Horizontal - Side 2" B: Opening Height 15-1/16" (382mm) Bottom/Top of Fireplace Opening Horizontal - Bottom 2"... -
Page 14: Clearances Cc40Le/Cc40Re
installation Clearances CC40LE/CC40RE Lo w framing with vents Low framing with vents in front/sides or top CC40LE shown Floor to ceiling with top op Floor to ceiling with top opening CC40LE shown | City Series... -
Page 15: Clearances Cc40Le/Cc40Re
installation Clearances CC40LE/CC40RE Chase enclosed CC40LE shown Full framing with low vents in front or sides CC40LE shown Full framing with vents in front or sides City Series |... -
Page 16: Mantel Clearances Cc40Le/Cc40Re
installation Mantel Clearances CC40LE/CC40RE Combustible mantel clearances from top of front facing are shown in the diagram on the right. Drywall, wood, wood panel, etc. Combustible Material Wood Stud (On Edge) 12" (305mm) Standoff 9” 2” Top of Bottom Fireplace Fireplace Opening 15-1/16” | City Series... -
Page 17: Framing Dimensions Cc40Le (Left Corner)
installation Framing Dimensions CC40LE (Left Corner) NOTE: Framing may be constructed of combustible material (ie. 2 x 4)and does not require steel studs. Note: A combined minimum of Framing 120 square inches of open area Description CC40LE Dimensions is required for the convection air outlet to cool the enclosure. En- Framing Height 37-3/8” (949mm) sure clearances for Convection Air Framing Width 48-1/4" (1226mm) Outlets are met. -
Page 18: Framing Dimensions Cc40Re (Right Corner)
installation Framing Dimensions CC40RE (Right corner) NOTE: Framing may be constructed of combustible material (ie. 2 x 4)and does not require steel studs. Framing Description CC40RE Dimensions Framing Height 37-3/8” (949mm) Framing Width 48-1/4" (1226mm) Framing Depth 19" (483mm) Note: A combined minimum of 120 square inches of open area Unit Base to Top Enclosure (Min.) 63"(1600mm) is required for the convection air Vent Centerline Height 56-1/4" (1429mm) outlet to cool the enclosure. En- sure clearances for Convection Air Outlets are met. -
Page 19: Wall Board/Drywall Installation Cc40Le/Cc40Re
installation Wall Board/Drywall Installation CC40LE/CC40RE WARNING! Risk of Fire! Comply with all minimum clearances to combustibles as specified. Finishing Instructions It is important to follow the framing and finishing instructions to ensure proper placement of fireplace into the surrounding framing/finishing materials. Wall board materials 1/2 in. thick are specified in this installation manual to properly align with the optional finishing methods offered with this appliance. The CC40LE/CC40RE may be finished to the appliance opening with 1/2 inch thick drywall. • Ensure that the back and side clearances are maintained. WARNING! Risk of Fire! Maintain specified air space clearances to combustibles. Inadequate air space could cause overheating and fire. DO NOT use screws more than 3/4 inch in length on the lower access cover panel. Longer screws may penetrate gas line or damage valve or electrical components. Note: It is acceptable to use a high temperature silicone sealant to adhere drywall to lower access cover panel. The appliance is designed to be used with 1/2 in. wall sheathing materials such as drywall, plywood, wood composites, or non-combustible materials. Thicker materials may be used. Refer to facing and finishing details in this manual. Facing Material • Facing and/or finishing materials must never overhang into the glass opening. • Facing materials may be combustible or non-combustible WARNING! Risk of Fire! DO NOT apply combustible materials beyond the minimum clearances. Comply with all minimum clearances to combustibles as specified in this manual. Overlapping materials could ignite and will interfere with proper operation. PAINTING If desired finishing includes a painted wall, 100% acrylic latex, oil-based or standard acrylic paints may be used. Follow paint manufacturer’s instructions for paint and primer application. City Series |... -
Page 20: Framing And Finishing Inset Installations Cc40Le/Cc40Re
installation Framing and Finishing Inset Installations CC40LE/CC40RE 1. Frame in the enclosure for the unit with framing material Note: When constructing the framed opening ensure there is sufficient access to install the gas lines,electrical. Also the wiring harness must be wall mounted using the receptacle provided with the appliance. The wiring harness will be located on the right hand side of the appliance if facing the unit from the front. This must be done prior to any finishing. 2. F or exterior walls, insulate the enclosure to the same degree as the rest of the house, apply vapour barrier and drywall, as per local installation codes. (Do not insulate the fireplace itself.) WARNING: Failure to insulate and add vapor barriers to the inside of the exterior wall will result in operational and performance problems including, but not limited to: excessive condensation on glass doors, poor flame package, carbon, blue flames etc. These are not product related issues. 3. T he unit does not have to be completely enclosed in a chase. You must maintain clearances from the vent to combustible materials: See "Clear- ances" section. Combustible materials can be laid against the side and back standoffs and the stove base. 4. C ombustible material (drywall,wood,wood panels, etc.) may be brought up to this appliance (top,bottom and sides) 5. E nsure that the material being used does not encroach anywhere in the Note: an offset screwdriver is provided with the appliance for ease of removal/... -
Page 21: Optional Framing Kit Installation Cc40Le/Cc40Re
CITY SERIES installation Optional Framing Kit Installation CC40LE/CC40RE CC40LE/CC40RE FRAMING KIT INSTALLATION This framing kit is for the CC40LE/CC40RE. The parts are adaptable so 1. This framing kit requires the installation of two studs at locations shown the same kit can be installed on either the right or left side units. below. - Page 22 CITY SERIES installation 3. Install B to the side of the unit, use the holes corresponding with the 5. Slide unit against wall and line up part C's with studs in the wall. appropriate shape (diamond or square depending on which unit you Attach both part C's to studs with at least two screws each;...
- Page 23 CITY SERIES installation 12. Identify J (diagonal support) and attach to back corners C and front 9. Identify F and attach to both E and D with 2 screws on each side. corner F with 2 screws on each side. 10.
-
Page 24: Building Additional Framing Off Of The Framing Kit
installation CITY SERIES Building additional framing off of the framing kit BUILDING FRAMING OFF OF THE KIT Potential Wood Framing installs This framing kit is designed as a base in which to build additional framing. Studs can be affi xed to all outer faces using the holes identifi... -
Page 25: Guidelines For Installing A Tv / Artwork |Above The Unit 2
installation Guidelines for installing a TV / ARTWORK above the unit TV recessed into wall Note: All wiring should stay free and clear of the vent system to avoid damage due to heat. We recommend using a metal receptacle box and BX cable (120 The TV may be recessed into a wall as shown below. volt wire protected by metal sheathing) if located directly in front of the vent This can only recess into the chase opening a maximum of 3-1/2 inches system. Ensure wiring is secured without any sag. and must be a minimum of 12 inches from the fireplace lip to the first stud. To achieve a maximum of 3-1/2" recess, the wall must be of a maximum of ZERO CLEARANCE TO TV: While most consumers prefer to centrally locate 2" as shown. a wall mounted TV, the “Cool-Touch Wall Technology” means that the bottom Sample Install 1 Sample Install 2 edge of the TV can be installed flush with the bottom edge of the ventilated fireplace chase opening. Air ow Zone Do not The TV cannot be obstruct... -
Page 26: Exterior Vent Termination Locations
installation Exterior Vent Termination Locations Minimum Clearance Requirements Canada Clearance above grade, veranda, porch, deck, or balcony 12"(30cm) 12"(30cm) Clearance to window or door that may be opened 12"(30cm) 9" (23cm) Clearance to permanently closed window Vertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2 feet (61cm) 18"(46cm) 18"(46cm) from the center line of the terminal (check with the local code) Clearance to unventilated soffit 20"(51cm) 20"(51cm) Clearance to outside corner: with AstroCap Termination Cap. 6"(15cm) 6"(15cm) Clearance to outside corner: with all other approved Termination Caps. 14"(36cm) 14"(36cm) Clearance to inside corner: with AstroCap Termination Cap 6"(15cm) 6"(12cm) Clearance to inside corner: with all other approved Termination Caps. 12"(30cm) 12"(30cm) 13"(33cm) Clearance to each side of center line extended above meter/regulator assembly 36"(90cm) Clearance to service regulator vent outlet 36"(90cm) Clearance to non-mechanical air supply inlet to building or the combustion air inlet to any other appliance 12"(30cm) 9" (23cm) -
Page 27: 4" X 6-5/8" Rigid Pipe Cross Reference Chart
” RIGID PIPE CROSS REFERENCE CHART * Olympia Ventis DV applicable for the following units only: B36XTE, B36XTCE, B41XTE, B41XTCE, P36, P36E Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Note: The listed manufacturers may have other lengths not shown on this chart, which would also be approved. - Page 28 installation Description Selkirk American Metal Security ICC Excel Olympia Simpson Metal-Fab™ Ventis DV* Direct Temp™ Products® Secure- Vent® Direct Direct Vent Pro ® Sure Seal Amerivent Direct Attic Insulation Shield 12” 46DVA-IS 4DAIS12 SV4RSA VDV-AIS04 N/A@ FPI Attic Insulation Shield 4DAIS12 TM-4AS - Cold Climates 36”...
-
Page 29: Wall Mount On / Off Switch And Battery Holder Installation
installation Wall Mount On / Off Switch and Battery Holder Installation Required for all installations IMPORTANT INSTALLATION NOTE: The Battery Holder must be placed inside the supplied (Low Voltage) junction type wall box and installed into the wall only. DO NOT INSTALL WITHIN THE CONFINES OF THE FIREPLACE SWITCH MUST BE ACCESSIBLE Battery Holder Installation 1. -
Page 30: Vent Restrictor Position
installation Vent Restrictor Position Vent restriction is required for certain venting installations, see the diagrams in the "Venting Arrangements" section to determine if they are required for your installation. The Vent Restrictor plate is packed in the instruction manual package. To set the vent restriction as indicated in the venting arrangements diagrams, refer to the following instructions; 1. Remove the safety glass and firebox glass - see instructions in this manual. 2. Remove the screws that hold the vent restrictor plate in place (see Diagram 1) 3. Adjust the vent restrictor plate to the required vent restrictor position as per the diagrams shown. 4. Once the vent restrictor plate is in the required position, secure with screws. Vent restrictor positions: Set 0 (Full open) Factory set Screw locations Vent restrictor location - inside top of firebox Diagram 1 Set 1 (Vent restrictor at 2”) Set 2 (Vent restrictor at 1.75”) Set 3 (Vent restrictor at 1.5”) | City Series... -
Page 31: Horizontal Terminations
S.S. screws #8 x 1-1/2” drill point Notes: 1. Liner sections should be continuous without any joints or seams. 2. Only Flex pipe purchased from Regency may be ® used for Flex installations 3. Horizontal vent must be supported every 3 feet. Vent Guard - if required* 4. -
Page 32: Venting Introduction
NOTE: A minimum of 1' (305mm) vertical off the top of the unit is required before any horizontal runs can start. Note: For horizontal terminations the Regency Direct Vent Flex System may be used for installations with a maximum continuous vent length of up to 10 feet. -
Page 33: Horizontal Terminations
installation Horizontal Terminations " Rigid Pipe 4" x 6-5/8 The minimum components required for a basic horizontal termination are: 1 Horizontal Termination Cap 1 Rigid Pipe Adaptor (510-994) 1 Wall Thimble 1 Length of pipe to suit wall thickness (see chart) Wall thickness is measured from the back standoffs to the inside mounting surface of termination cap. For siding other than vinyl Horizontal furring strips may be used instead of the vinyl siding standoff, to Termination Cap create a level surface to mount the vent terminal. The Terminal must not be recessed into siding. Measure the wall thickness Vinyl Siding including furring strips. -
Page 34: Horizontal Terminations
installation Horizontal Terminations " Rigid Pipe 4" x 6-5/8 The diagrams below show examples of horizontal termination arrangements using one, two, or three 90 elbows (two 45 elbows equal one 90 elbow) 1. A maximum of three 90 elbows are permitted. 2. Minimum distance between elbows is 1 ft. (305mm). • Maintain clearances to combustibles as listed in the "Clearances" section. •... -
Page 35: Rigid Pipe 4" X 6-5/8
installation Vertical terminations " Rigid Pipe 4" x 6-5/8 The minimum components required for a basic vertical termination are: 1 Vertical Termination Cap 1 Rigid Pipe Adaptor (510-994) 1 Ceiling Firestop 1 Flashing 1 Storm Collar 1 Length of pipe to suit wall thickness (see chart) Galvanized pipe is desirable above the roofline due to its higher corrosion resistance. Continue to add pipe sections through the flashing until the height of the vent cap meets the minimum height requirements specified in diagram 2 or local codes. Note that for... -
Page 36: Venting Arrangement For Vertical Terminations
installation Venting Arrangement for Vertical Terminations Vertical Venting with straight Vertical venting and or with a max. of two (2) 90 Elbows (1 - 90 2 - 45 The shaded area in the diagram shows all allowable combinations Horizontal (Feet) of straight vertical and offset to vertical terminations, using two elbows, with Rigid Pipe Venting Systems. Two 45 elbows equal to one 90 elbow. • Vent must be supported at offsets. • Minimum distance between elbows is 1 ft. (305mm). -
Page 37: Vertical Terminations Rigid Pipe 4" X 6-5/8
installation Vertical Terminations " Rigid Pipe 4" x 6-5/8 • Two 45 elbows equal to one 90 elbow. Maximum of six 45 elbows allowed. • Vent must be supported at offsets. • Minimum distance between elbows is 1 ft. (305mm). • Maintain clearances to combustibles as listed in the "Clearances" section. • Horizontal vent must be supported every 3 feet. • Firestops are required at each floor level and whenever passing through a wall. • Must use optional rigid pipe adaptor (Part# 510-994) when using rigid pipe vent systems. Vertical Venting with Three (3) 90 Elbows One 90 elbow = Two 45 elbows. Option H + H1 V + V1... -
Page 38: Unit Installation With Horizontal Termination
installation Unit Installation with Horizontal 5. Assemble the desired combination of pipe and 7. Ensure that the pipe clearances to combustible elbows to the appliance adaptor and twist-lock materials are maintained (Diagram 3). Install Termination for a solid connection. the termination cap. 4" x 6-5/8" venting (Rigid Vent Systems) Note: For best results and optimum Note: If installing termination on a vinyl performance with each approved siding covered wall, a vinyl siding Minimum Vent Clearances v e n t i n g s y s t e m , i t i s h i g h l y standoff or furring strips must be... -
Page 39: Unit Installation With Horizontal Termination
installation Unit Installation with Horizontal NOTE: Horizontal sections must be sup- ASTROCAP ported at intervals not exceeding Termination DIMENSIONS (946-523/P) 3 feet (0.9 meter). (Flame picture 4" X 6-5/8" VENTING and performance will be affected (Flex Vent Systems) by sags in the liner). Minimum Vent Clearances 4. Separate the 2 halves of the wall thimble and to Combustibles... -
Page 40: Horizontal Terminations
installation Dura-Vent b) Horizontal runs of vent must be supported every three feet. W all straps are available Horizontal terminations for this purpose. Install the vent system according to the manufacturer's instructions included with 5) Mark the wall for a 10" x 10" square hole. T he the components. center of the square hole should line up with the centerline of the horizontal pipe. Cut and 1) Set the unit in its desired location. Check to frame the 10 inch square hole in the exterior determine if wall studs or roof rafters are in wall where the vent will be terminated. If the the way when the venting system is attached. wall being penetrated is constructed of non- If this is the case, you may want to adjust the combustible material, i.e. masonry block or location of the unit. Rough in the gas preferably concrete, a 7"(178mm) dia. (7-1/2"(191mm) on the right side of the unit and the electrical dia. for flex) hole is acceptable. -
Page 41: Dura-Vent Vertical Termination
installation Dura-Vent Vertical Termination 4. Assemble the desired lengths of pipe and elbows. Ensure that all pipes and elbow con- 4" x 6-5/8" venting nections are in the fully twist-locked position (Rigid Vent Systems) and sealed. 1. Maintain the 1-1/2" clearances (air spaces) to combustibles when passing through ceilings, walls, roofs, enclosures, attic rafter, or other nearby combustible surfaces. Do not pack Diagram 4 air spaces with insulation. Check "Venting" Sections for the maximum vertical rise of the venting system and the maximum horizontal offset limitations. -
Page 42: Vertical Termination 4" X 6-7/8" Venting
installation VERTICAL TERMINATION Vertical Termination 4" x 6-7/8" venting 4" X 6-7/8" VENTING - VERTICAL FLEX VENT KIT (946-755) 1. Maintain the 1-½” clearance (air space) to combustibles when passing 11. Secure inner fl ex pipe to pipe adaptor by using Mill-Pac over the adaptor. through ceilings, walls, fl... -
Page 43: Vertical Flue Extension Kit (Part #946-756)
installation Vertical flue extension kit (part #946-756) VERTICAL FLUE EXTENSION KIT (PART # 946-756) 20 foot Flex pipe Extension (Used in conjunction with the 946-755 Vertical Flex kit and 948-367/P flex 4" (100mm) inner pipe to flex adaptor). CEILING FIRESTOP/FIRESTOP SPACER 20ft. -
Page 44: High Elevation
LP SYSTEM DATA Min. Supply Pressure 11" WC (2.73 kpa) Note: If you have an incorrect flame Manifold Pressure 10.5" WC (2.62 kpa) pattern, contact your Regency ® dealer for further instructions. Orifice Size #53 DMS Maximum Input 28,500 Btu/h Incorrect flame pattern will have small, probably (8.35 kW) -
Page 45: Wiring Diagrams
installation Wiring Diagrams No electrical power supply is required for the gas (Do not cut the ground terminal off under any Caution: Ensure that the wires do not control to operate. 120 Volt AC power is needed circumstances.) touch any hot surfaces and are away from for the lights. A receptacle box, receptacle and sharp edges. cover are provided and located on the left hand side of the unit, under the outer base panel. -
Page 46: Inner Glass Panel (Firebox Glass) Installation / Removal
installation Inner glass panel (firebox glass) Installation / removal Note: glass panels must be installed to operate fireplace Push side glass WARNING: GLASS HANDLING panel firmly to back wall We recommend using the glass vacuum holders supplied by the manufac- until springs are turer. Lower the glass to rest in a safe place, this is to prevent damage to the compressed— glass edges. Extra care must be taken when removing/installing the glass. then close Breakage or damage to the edge of the glass which occurs as a result of clamps. careless handling will not be covered under warranty. • W e recommend handling the glass with supplied vacuum clamps •... - Page 47 installation 5. E nsure all 7 front clamps are in the open position to allow clearance for Note: Ensure that the front glass is centered and evenly spaced with side glass tooltip the glass. (3 sided unit) - open to release glass clamps to remove from surface of glass. Open clamps prior to placing front glass panel Open clamps to CC40LE shown release pressure on the springs 6. L ift up the front panel using the supplied vacuum clamps and position into the lower front channel–ensure the front panel is accurately centered—with the front panel in position—secure in place by closing the 3 lower clamps 7. Return to the side panel(s), and release the upper and lower clamps. The and 4 upper clamps. springs will release and push the glass side panel forward slightly—this will create a seal between the front and side panels. When the junction between Press glass vacuum clamps in open position firmly onto surface of glass. Bring the front and side glass panels is sealed, close the clamps to secure the handles together to close. side panel(s) in place.
-
Page 48: Outer Safety Glass Panel (Barrier Glass) Installation / Removal
installation Outer safety glass panel (barrier glass) Installation / removal Note: safety glass panels must be installed to operate fireplace 3. T ilt the top of the glass panel inward and lift up and underneath the upper front panel of the outside frame. Hook the glass panel WARNING: GLASS HANDLING onto the pins and also onto the two angle adjustment brackets lo- cated on the frame in two locations as shown in the diagram below. -
Page 49: Outer Safety Glass Panel (Barrier Glass) Installation / Removal
installation Outer safety glass panel (barrier glass) Installation / removal Note: safety glass panels must be installed to operate fireplace. Note: A fter the side panel has been adjusted so it is installed at 90º to the 4. F or 3 sided and corner units only: unit and not flaring in or out, check to ensure there is no gap between With front panel installed, proceed to install the side panel(s). the front and side panel. If there is a gap as shown below, slide the side I dentify the left and right side panels before installing. Facing the front of panel to adjust the position and close the gap. the unit, the right panel will show an arrow pointing to the front of the unit as shown in the diagram below. Direction arrow on side panel bracket, should point toward front of unit 5. Lift up the side panel with the supplied glass clamps (see procedure on previous page). Tilt the side of the glass panel inward and lift up and under-... -
Page 50: Lp Conversion Instructions
CITY SERIES installation CONVERSION FROM NG TO LP LP Conversion Instructions CV40E/ CB40E using SIT 885 NOVA Gas Valve THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION! 6. If unable to access this Cable - undo 2 screws securing the IFC Board WARNING and slide out of unit to access cable. - Page 51 CITY SERIES installation 11. Loosen 4 screws in locations shown below (2 at front and 2 at rear)—slide burner to the left away from the orifi ce and lift out. front screw locations 14. Unscrew the pilot orifi ce with the allen key; then replace with the LPG pilot orifi...
-
Page 52: Cc40Le/Cc40Re Painted Panel Installation
Note: Install inner safety glass prior to installation of outer panels-see instructions in manual 1. Attach Regency logo to the right hand side of outer front panel. The magnets will be positioned under the outer front base panel to secure 2. -
Page 53: Cc40Le/Cc40Re Glass Panel Installation
CITY SERIES installation CC40LE/CC40RE glass panel installation CC40LE/CC40RE GLASS PANEL INSTALLATION 1. Turn off unit and allow to cool to room temperature. Remove the outer safety 4. Slide the supplied bottom corner bracket behind the small panel (1) and the glass and inner ceramic fi... - Page 54 CITY SERIES installation 6. Carefully manoeuver the Side Glass Panel (3) into the side of the fi re- 9. Install outer side base panel (5) — panel 5 rests on the tab of panel 4. box. Position the bottom of the panel into the Bottom Corner Bracket and secure the top using the Top Side Bracket as shown.
-
Page 55: Cc40Le/Cc40Re Enamel Panel Installation
CITY LINE maintenance CC40LE/CC40RE enamel panel installation CC40RE/CC40LE ENAMEL PANEL INSTALLATION Black Enamel Panels — Handling Instructions • Black Enamel panels must be inspected for scratches and dimples prior to installation. All claims to be recorded at this time. Claims for damage after installation will not receive consideration. •... - Page 56 Note: Install inner safety glass prior to installation of outer panels-see instructions in manual 1. Attach Regency logo to the right hand side of outer front panel. The magnets will be positioned under the outer front base panel to secure the logo.
-
Page 57: Burner And Firebox Media Options
installation Burner and Firebox media options Spread the media evenly over the burner. Ensure the glass/stones do not overlap excessively as this will affect the flame pattern. IMPORTANT NOTE: Only the supplied approved media are to be used with these fireplaces. Use of any other type of glass or stones can alter the unit's performance. Any damage caused by the use of any unapproved glass or stones will not be covered under warranty. When using Ceramic Spa/Volcanic Stones ensure required glass crystals/beads are used as a base. DO NOT overstack Ceramic Spa Stones or Volcanic Stones on burner or in the pilot area. Media must be installed on and around burner only in amounts noted below. CC40LE/CC40RE Approved Media* Where Used Quantity Fireglass (starfire, copper or black) On burner 1.5 lbs Glowing embers/sea wool (supplied with unit) On burner 1 bag Natural Stones Around burner 1 box = 15lbs Ivory Natural Stones Around burner 1 box = 15lbs 3/4" Crushed black glass Around burner 3.5lbs Crushed Iceburg chips Around burner 3.5lbs Firebeads Around burner 3.5lbs Spa stones Around burner... -
Page 58: Optional Driftwood Log Set Installation
installation CITY LINE Optional driftwood Log set Installation CITY LINE - LOG INSTALLATION Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation. Improper positioning of the logs may create carbon build-up and can alter the unit's performance which is not covered under warranty. - Page 59 CITY LINE installation 8. Place the split end of Log 3 to the right front corner of the burner—angle Rest the other end of Log 4 on the indent in Log 2 as shown below. the log so that the other end is sitting approximately 1/2" (13mm) from the edge of the burner tray.
-
Page 60: Cc40Le/Cc40Re - Removable Drywall Guides
installation CC40LE/CC40RE - Removable drywall guides (when using 1/2" drywall) An optional finishing trim is available to finish the edges of the installation on 5. R everse steps to reinstall drywall guides (if applicable). If discarding, please the CC40RE/CC40LE unit. Installation is as follows: recycle. 1. R emove the outer safety glass and outer front and side panels - see in- structions in manual. 2. L oosen 3 screws inside the lower front edge of the unit to release existing lower drywall guide and remove guide. Note : an offset screwdriver is provided with the appliance for ease of removal/ installation of the lip and finishing trim. Lower drywall guides Loosen and tighten screws on drywall guide from inside front panel 3. L oosen 2 screws from inside the firebox to release the existing side drywall ooltip guide, remove guide and recycle. -
Page 61: Operating Instructions
operating instructions First Fire Normal Operating Sounds of Aeration Adjustment Gas Appliances The burner aeration is factory set but may need The FIRST FIRE in your fireplace is part of the adjusting due to either the local gas supply or paint curing process. To ensure the paint is prop- It is possible that you will hear some sounds from altitude. Open the air shutter for a blue flame or erly cured, it is recommended you burn your your gas appliance. This is perfectly normal due to close for a more yellow flame. fireplace for at least four (4) hours the first time. the fact that there are various gauges and types of steel used within your appliance. Listed below Remove outer safety glass and inner glass panels... -
Page 62: Lighting Procedure
operating instructions Lighting Procedure IMPORTANT: The remote control system supplied with this appliance has Note: The first try for ignition will last approximately 60 seconds. If there is no several options for starting/operating the appliance using the battery holder flame ignition (rectification) the board will stop sparking for approximately and ON/OFF key on the hand held transmitter. 35 seconds. After wait time , the board will start second try for ignition by Prior to operating this appliance, please read the remote control operating sparking for approximately 60 seconds . If there is still no positive ignition instructions (packaged with remote control) to understand how to operate the board will go into lock out. this remote control system. The system will need to be reset as follows: 1. Ensure the battery holder switch is in the Remote position and / or wall mounted battery holder (if equipped) is in the <REMOTE> position. a) Turn the system off by pressing the ON/OFF button on the remote. 2. Press and release the ON/OFF button on the remote handheld transmitter b) Wait 5 minutes then repeat from step 2. (see Diagram 1). An audible beep should be heard from the receiver. If not using the remote, the unit can also be turned on by sliding the battery Shutdown Procedure holder switch to the <ON> position (if equipped). 1. Press the ON/OFF button on the remote 2. If service is to be performed, you must disconnect power and shut off gas to the unit. ON/OFF Button Diagram 1... -
Page 63: Copy Of The Lighting Plate Instructions
operating instructions Copy of the Lighting Plate Instructions FOR YOUR SAFETY READ BEFORE LIGHTING POUR VOTRE SÉCURITÉ – À LIRE AVANT LA MISE EN MARCHE This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1. -
Page 64: Maintenance
If the glass gasket requires replacement use a the flow of combustion and ventilation air is not tadpole glass gasket (Part # 936-220). obstructed. Note: Never operate the appliance without Glass the glass properly secured in place. Your Regency fireplace is supplied with high ® 6. Do not use this appliance if any part has been temperature 5mm-Tempered outer glass & 5mm- under water. Immediately call a qualified service Ceramic inner glass. If your glass requires cleaning, technician to inspect the appliance and to... -
Page 65: Bulb Replacement
Bulb Replacement 1. T urn off unit and allow to cool to room temperature. 4. Loosen 2 screws on each side of individual inner light cover and remove. 2. R emove outer safety glass panels and inner panels (firebox glass)–see 5. R emove glass cover by using a flat head screwdriver to pry the tab securing instructions in this manual. the glass assembly in place. 3. L oosen 2 outer screws on each side to remove outer light cover — located 6. Replace bulb and reverse steps to complete procedure. in the upper inside front of the firebox and remove. NOTE: D o not handle bulb with bare hands. Use packaging or a tissue to hold new bulb when replacing. Regency Part# 911-208 Oven Lamp Assembly G9 120V/25W Regency Part# 911-072 Replacement Bulb G9 120 Volt/25 watt City Series |... -
Page 66: Valve Replacement
maintenance Valve Replacement Important: Always shut off gas supply/120 volt power prior to servicing the 7. L ift valve tray by out partially and disconnect flexible gas connection on the gas valve. valve inlet side, remove valve tray- replace with new valve tray. tooltip 1. T urn off unit and allow to cool to room temperature. 2. R emove outer enamel or steel panels—see instructions in the panel removal section in this manual 3. R emove outer safety glass panels and inner panels (firebox glass)–see instructions in this manual. 4. Remove all media and logs (if installed) — set aside. 5. L oosen 4 screws in locations shown below (2 at front and 2 at rear)—slide burner to the left away from the orifice and lift out. front screw locations 8. Reverse steps 6-1 to complete. back screw locations 6. Remove 16 screws in locations shown below. -
Page 67: Parts List
Receptacle Cover Duplex Metal 940-486/P Outer Barrier Tempered Glass Assembly - Large 904-687 Connector Clamp 3/8 CI-804 940-436/P Flush Inner Ceramic Glass - Large 948-078 Glass Suction Cup (Each) 656-062 Outer Base Cover Black 904-790 Magnet Round 1/2 inch (Each) 940-439/P Outer Safety Glass Side - Tempered Small 904-970 Magnet Cup 1/2 inch (Each) 940-437/P Flush Inner Ceramic Glass Small 948-223 Logo Plate Plastic Regency/Flame Silver 656-574/P Valve Assembly - NG 656-131 Logo Mounting Bracket 656-576/P Valve Assembly - LP 656-017F Restrictor Plate 656-033F Bottom Cover Access Plate 656-018 Pressure Relief Base 656-034 Bottom Cover Access Gasket 656-023 Pressure Relief Base Gasket 656-309 Removable Drywall Finishing 656-019... - Page 68 parts list 656-059 Inner Top Panel Clip (Used on the 656-928) 946-776 Fireglass Copper 1/4 in. 5Lb Pkg 656-930/P Driftwood Log Set 946-777 Fireglass Starfire 1/4 in. 5Lb Pkg 656-969 Conversion Kit - LP 946-780 Crushed Glass Coal Black 3/4in. 3.5 Lbs 656-991 Chase Vent Front Black 946-781 Crushed Glass Iceberg Chips 3/4in. 3.5 Lbs 656-995 Adaptor Heat Wave 946-735 Firebeads Black 1 Lb Pkg 946-556 Heatwave Kit 946-736 Firebeads Sangria Luster 1 Lb Pkg 946-672 Stones - River Pebbles 946-737 Firebeads Glacier Ice 1 Lb Pkg 946-674 Stones - Ceramic Spa (70 stones) 946-738 Firebeads Caramel Luster 1 Lb Pkg 946-675 Fireglass Black Reflective 1/4in.1Lb Pkg 946-739 Firebeads Black 5 Lb Pkg 946-676 Fireglass Copper 1/4 in. 1Lb Pkg 946-740 Firebeads Sangria Luster 5 Lb Pkg 946-677...
-
Page 69: Cc40Re Main Assembly
Receptacle Cover Duplex Metal 940-436/P Flush Inner Ceramic Glass - Large 904-687 Connector Clamp 3/8 CI-804 656-062 Outer Base Cover Black 948-078 Glass Suction Cup (Each) 940-438/P Outer Safety Glass Side - Tempered Small 904-790 Magnet Round 1/2 inch (Each) 940-437/P Flush Inner Ceramic Glass Small 904-970 Magnet Cup 1/2 inch (Each) 936-219 Gasket 5/8 (09) Sewn Rope Graphite 3/4 PSA 10 948-223 Logo Plate Plastic Regency/Flame Silver (Sold per Foot 10 Feet Required) 656-131 Logo Mounting Bracket 936-220 Gasket Tape 2" Wide Graphite Wrap 656-017F Restrictor Plate 656-018 Pressure Relief Base 656-574/P Valve Assembly - NG 656-023 Pressure Relief Base Gasket 656-576/P Valve Assembly - LP 656-019 Pressure Relief Bracket Right 656-033F Bottom Cover Access Plate... - Page 70 parts list 656-969 Conversion Kit - LP 946-780 Crushed Glass Coal Black 3/4in. 3.5 Lbs 656-991 Chase Vent Front Black 946-781 Crushed Glass Iceberg Chips 3/4in. 3.5 Lbs 656-995 Adaptor Heat Wave 946-735 Firebeads Black 1 Lb Pkg 946-556 Heatwave Kit 946-736 Firebeads Sangria Luster 1 Lb Pkg 946-672 Stones - River Pebbles 946-737 Firebeads Glacier Ice 1 Lb Pkg 946-674 Stones - Ceramic Spa (70 stones) 946-738 Firebeads Caramel Luster 1 Lb Pkg 946-675 Fireglass Black Reflective 1/4in.1Lb Pkg 946-739 Firebeads Black 5 Lb Pkg 946-676 Fireglass Copper 1/4 in. 1Lb Pkg 946-740 Firebeads Sangria Luster 5 Lb Pkg 946-677 Fireglass Starfire 1/4 in. 1Lb Pkg 946-741 Firebeads Glacier Ice 5 Lb Pkg 946-775 Fireglass Black Reflective 1/4in.5Lb Pkg 946-742 Firebeads Caramel Luster 5 Lb Pkg 946-776...
- Page 71 notes City Series |...
-
Page 72: Warranty
FPI is not responsible for results or costs of workmanship of unauthorized FPI dealers or agents in the negligence of their service work. Revision Date: December 2016 Regency Gas Products Warranty | City Series... - Page 73 Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Revision Date: December 2016 Regency Gas Products Warranty City Series |...
- Page 74 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
- Page 75 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 76 | City Series...
- Page 77 notes City Series |...
- Page 78 notes | City Series...
- Page 80 Installer: Please complete the following information Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ © Copyright 2017, FPI Fireplace Products International Ltd. All rights reserved.
