OBTAINING THE TEST REPORTS

The Raptor system is equipped with the capacity to save the results of tests for subsequent
review or for printing the test reports through the RaptorSync programme (for a PC).

Concept of Report and Test.

A test encompasses all the testing performed, including: the measurements that may be
configured for display on screen, the measured time, the injected level and, in general,
all adjustments and alarms.
The report is a grouping of the tests under a common name and comment.

How to use the Reports and Tests.

indicates that no Report is already open.
description to facilitate subsequent identification.
From the Reports screen, you can also open a report for review by tapping on View, or
you can delete it by tapping on Delete. When a report is deleted, the tests contained in
the same are also deleted.
With a report open, you can save the Tests simply by tapping on the Save button of the
main screen.
reverse order. Be careful when using this last button, given that it will not ask you for
confirmation.
To activate the capacity to save the results of a test, you must
have previously a report open. You can know if you already have
a report open by the status of the Save button. If it is disabled, it
To open a report:
Tap on Menu and then browse to the Reports icon, either using
the arrows and tapping on the icon or using the dial and then
pressing it.
If the Close button is active, it means that a
report is already open, whose name will be
displayed at the bottom. To create a new
one or open an existing one, you must first
close the current one. The report is kept
open even if the system is turned off.
If you decide to create a new one by
tapping on the New button, you will be
asked to enter the name and a brief
In the submenu, you can save the results of a test without
specifying anything else by using the Save test button, or you can
specify a comment using the Save test with comments button.
You also have a button available for deleting saved tests in
