QLXD1
Mic Offset Range
0 to 21 dB (in 3 dB steps)
Battery Type
Shure SB900 Rechargeable Li-Ion or AA batteries 1.5 V
Battery Runtime
Shure SB900
alkaline
See Battery Runtime Chart
Dimensions
86 mm x 66 mm x 23 mm (3.4 in. x 2.6 in. x 0.9 in.) H x W x D
Weight
142 g (5.0 oz.), without batteries
Housing
Cast aluminum

Audio Input

Connector
4-Pin male mini connector (TA4M), See drawing for details
Configuration
Unbalanced
Impedance
1 MΩ, See drawing for details
Maximum Input Level
1 kHz at 1% THD
Preamplifier Equivalent Input Noise (EIN)
System Gain Setting ≥ +20
-120 dBV, A-weighted, typical
RF Output
Connector
SMA
Antenna Type
1/4 wave
Impedance
50 Ω
Occupied Bandwidth
<200 kHz
Modulation Type
Shure proprietary digital
Power
1 mW or 10 mW

Frequency Bands and Transmitter RF Power

Band
Frequency Range
(MHz)
G50
470 - 534
G51
470 - 534
G52
479 - 534
H50
534 - 598
H51
534 - 598
H52
534 - 565
H53
534 - 598
J50
572 - 636
J51
572 - 636
JB
806 - 810
K51
606 - 670
22
>10 hours
up to 9 hours
RF Power (mW)
1 or 10
1 or 10
1 or 10
1 or 10
1 or 10
1 or 10
1 or 10
1 or 10
1 or 10
1 or 10
1 or 10
Do Not Duplicate or Redistribute
QLXD2
Mic Offset Range
0 to 21 dB (in 3 dB steps)
Battery Type
Shure SB900 Rechargeable Li-Ion or AA batteries 1.5 V
Battery Runtime
Shure SB900
alkaline
See Battery Runtime Chart
Dimensions
256 mm x 51 mm (10.1 in. x 2.0 in.) L x Dia.
Weight
340 g (12.0 oz.), without batteries
Housing
Machined aluminum
Audio Input
Configuration
Unbalanced
Maximum Input Level
1 kHz at 1% THD
145 dB SPL (SM58), typical
Note: Dependent on microphone type
RF Output
Antenna Type
Integrated Single Band Helical
Occupied Bandwidth
<200 kHz
Modulation Type
Shure proprietary digital
Power
1 mW or 10 mW
Band
Frequency Range
(MHz)
K52
606 - 670
L50
632 - 696
L51
632 - 696
L52
632 - 694
L53
632 - 714
P51
710 - 782
P52
710 - 782
Q51
794 - 806
S50
(823 - 832) (863
- 865)
X51
925 -937.5
>10 hours
up to 9 hours hours
RF Power (mW)
1 or 10
1 or 10
1 or 10
1 or 10
1 or 10
1 or 10
1 or 10
1 or 10
1 or 10
1 or 10
