CENTRIX™ & EVENTIX™
A-4: COMMANDS AND RESPONSES TABLE
COMMAND RESPONSE
COMMANDE RÉPONSE
SELECTION COMMANDS / COMMANDES DE SÉLECTION
MM MTRX
CC CH
CN CHN
cc ch
cn chn
G TAKE
ut TKEV
Z FRZ
z frz
INPUT COMMANDS / COMMANDES D'ENTRÉE
PC PCH
PE PEN
PL PLD
PR PRGB
PI PSTD
PP PPRC
OUTPUT COMMANDS / COMMANDES DE SORTIE
FM OFTM
fp oftp
FY OSYN
fy osyn
FS SCRM
fs scrp
pm PAT
pp pat
XR REFR
xr refr
NOTE: (M) = MAIN output (sortie MAIN).
(P) = PREVIEW output (sortie PREVIEW).
COMMAND DESCRIPTION
DESCRIPTION DE LA COMMANDE
Switching mode selection.
MAIN selected input.
• Background switching during a PIP
(in MIXER mode).
• Input pre-selection for OUTPUT 1
(in MATRIX mode).
PREVIEW selected input (read only).
• Input pre-selection & PIP switching
(in MIXER mode).
• Input pre-selection for OUTPUT 2
(in MATRIX mode).
TAKE (transition).
Transition availability.
FREEZE MAIN.
FREEZE PREVIEW.
Input selection for adjustment.
Input disabling (works with PC)
H sync load selection (works with PC). Rd/Wr
RGB input type selection (works with
PC command).
Input standard selection (works with
PC command).
VCR mode
Output formats selection (M).
Output formats selection (P).
Output sync selection (M).
Output sync selection (P).
Type of screen selection (M)
Type of screen selection (P)
Test pattern selection (M).
Test pattern selection (P).
Output rate selection (Mixer mode).
Output 1 rate selection (Matrix mode)
Output 2 rate selection (Matrix mode). Rd/Wr
www.liveline.be
A-4: TABLE DES COMMANDES ET RÉPONSES
TYPE
MIN MAX
Rd/Wr 0 1
Rd 0 8
Rd/Wr 0 8
0 8
Rd
Rd/Wr 0 8
Rd/Wr 0 1
Rd 0 1
Rd/Wr 0 1
Rd/Wr 0 1
Rd/Wr 0 8
Rd/Wr 0 1
0 1
Rd/Wr 0 10
Rd/Wr 0 4
Rd/Wr 0 1
Rd/Wr 0 20
Rd/Wr 0 20
Rd/Wr 0 2
Rd/Wr 0 2
Rd/Wr 0 1
Rd/Wr 0 1
Rd/Wr 0 7
Rd/Wr 0 7
Rd/Wr 0 8
0 8
Rd/Wr = Read and write command / Commande de lecture et d'écriture.
Rd = Read only command / Commande de lecture uniquement.
APPENDIX A / ANNEXE A
VALUE /VALEUR
DESCRIPTION
0 = mixer mode 1 = matrix mode
0 = black
1 = input #1
2 = input #2
3 = input #3
4 = input #4
5 = input #5
6 = input #6
7 = input #7
8 = input #8
1 = start the transition (automatic reset at the
end of the effect duration).
0 = stop the transition (for holding effect).
1 = New input ready to commute.
0 = inactive 1 = active.
0 = inactive 1 = active.
0 = all inputs. 1 = input #1.... 8 = input #8
0 = disable 1 = enable.
0 = Hi-Z load 1 = 75Ω load.
0 = composite 1 = S.VIDEO
2 = YUV 3 = RGBS (TTL)
4 = RGsB (SOG) 5 = RGBS (ana)
6 = SDI. 7 = computer (SOG)
8 = comp (HV or C.) 9 = comp DVI
10 = HDTV.
0 = NTSC/PAL/SECAM.
1 = NTSC. 2 = PAL.
3 = SECAM 4 = Black & White.
0 = OFF 1 = ON.
0 = SVGA 50Hz 1 = SVGA 60Hz
2 = SVGA 72Hz 3 = SVGA 75Hz
4 = XGA 50Hz 5 = XGA 60Hz
6 = XGA 72Hz 7 = XGA 75Hz
8 = SXGA 50Hz 9 = SXGA 60Hz
10 = SXGA 72Hz 11 = SXGA 75Hz
12 = SXGA+ 50Hz 13 = SXGA+ 60Hz
14 = SXGA+ 72Hz 15 = SXGA+ 75Hz
16 = D-ILA 4/3 75Hz 17 = D-ILA 16/9 75 Hz
18 = WVGA 16/9 60 19 = HDTV 720p 50Hz
20 = HDTV 720p 60Hz
0 = H &V sync. 1 = Composite sync.
2 = SOG
0 = 4/3 screen 1 = 16/9 screen
0 = 4/3 screen 1 = 16/9 screen
0 = no pattern 1 = centering 2 = color
3 = grey scale 4 = grid.
6 = multi-burst. 7 = H grey scale
0 = internal rate 1 = follow input #1
2 = follow input #2... 8 = follow input #8
5 = softedge
