  • Page 1 Wide-Dynamic Range Real Day/Night Camera Instructions Manual ZEIM-0050692G 290. A.7 CONTENTS PRECAUTION ..............IMPORTANT SAFTY INSTRUCTIONS........NOTES OF USE..............SETUP PROCEDURES ............• ..........MAIN CAMERA SETUP MENU1 • ..........MAIN CAMERA SETUP MENU2 SPECIFICATIONS.............. Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.
  • Page 2 PRECAUTIONS NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part The lightening fl ash with arrowh- 15 of the FCC Rules. These ead symbol, within an equilateral limits are designed to provide triangle, is intended to alert the reasonable protection against...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions Power-Supply cords should be routed All the safety and operating instruct- so that they are not likely to be walk- ions should be read before the prod- ed on or pinched by items placed upon or against them.

  • Page 4: Notes Of Use

    NOTES OF USE •PARTs’ NAMES AND LOCATIONS (1) Lens mount (5) Left button This camera uses CS mount to conn- Use this button to move the cursor to ect the lens, if you are using a C mount the left or to exit the selected item in the lens, you can fi...
  • Page 5 NOTES OF USE (9) Tripod mounting holes (13) DC12V/AC24V power connector Use this holes to connect to a Connect this connector to the respe- bracket or to a housing according to your ctive power.(DC12V/AC24V model only) applications. WARNING: This apparatus must be EARTHED. (10) RJ45 port (14) AC90V~260V External devices can use RS485 prot-...

  • Page 6: Privacy Zone Setup

    SETUP PROCEDURES •OSD SETUP MENU (Default settings) MAIN MENU 1 ALC/ELC SETUP D / N M O D E A U T O A L C / E L C MENU D / N L E V E L H I G H A L C / E L C A L C D / N...

  • Page 7: Remote Control

    SETUP PROCEDURES This camera offers an user friendly on-screen setup menu. All setups except When satisfi ed all the settings, move auto iris control type are set up here. the cursor to the 'EXIT" item and press the enter button to exit the OSD setup menu. •...

  • Page 8: Day/Night Switch Mode

    SETUP PROCEDURES (1) Address setup Press the Enter button then select Move the cursor to the setting to the the BAUD RATE setting to be either 1200, right of "ADDRESS" by pressing the Up or 2400, 4800, 9600. the Down button. NOTE: Camera controller must have the same protocol and baud rate with the camera before it can control the camera.
  • Page 9 SETUP PROCEDURES Press the Enter button then select the When satisfi ed all the settings, move D/N mode setting to be color, mono, auto the cursor to other items or to the 'EXIT" or B.C.G.. item and press the enter button to exit AUTO:The camera will switch between OSD setup menu.
  • Page 10 SETUP PROCEDURES When satisfi ed all the settings, move an incredible 128X dynamic range wider the cursor to the 'EXIT" item and press than conventional camera. You can see the enter button to exit to the previous both bright objects and dark objects OSD setup menu.

  • Page 11: Shutter Speed Setup

    SETUP PROCEDURES (D)Level setup(Brightness) Shutter Settings Move the cursor to the "level" set WD OFF WD ON up by pressing the UP and the DOWN button. AUTO MANUAL Press the Right or Left button to (1/60s~1/120Ks) move the "light" indicator between the remark: A: active, NA: not active ten levels.
  • Page 12 SETUP PROCEDURES (6)Sens up (Slow shutter setup) SENS SHUTTER SPEED AUTO (Shutter speed range) Move the cursor to the setting to the N*:1/60s~1/30s right of "SENS UP" by pressing the Up or P*: 1/50s~1/25s the Down button. N: 1/60s~1/15s P: 1/50s~1/13s N: 1/60s~1/10s Press the Enter button then select P: 1/50s~1/8s...

  • Page 13: Sync Setup

    SETUP PROCEDURES (7)GAIN setup When satisfi ed all the settings, move Move the cursor to the setting to the the cursor to other items or to the 'EXIT" right of "GAIN" by pressing the Up or the item and press the enter button to exit Down button.

  • Page 14: White Balance Setup

    SETUP PROCEDURES BLC3: You can see the active area of (10)White balance setup BLC3 function. It covers lower half size of the monitor. Move the cursor to the setting to the right of "WHITE BAL" by pressing the Up or the Down button. BLC3 BLC4: You can see the active area of Press the Enter button the select...

  • Page 15: Enter The Menu

    SETUP PROCEDURES •MAIN CAMERA SETUP MENU2 These items let you setup camera Press the Enter button then select gamma value, aperture, electric-zoom, the gamma value to 0.45 or 1. privacy zone, camera ID and use blemish 0.45: The camera's gamma value is set auto recovery function.
  • Page 16 SETUP PROCEDURES (6)Privacy zone setup (4)P-T-Z setup Move the cursor to the setting to the Move the cursor to the setting to the right of "PRIVACY ZONE" by pressing the right of "E-ZOOM" by pressing the Up or Up or the Down button. Then press the the down button.

  • Page 17: Camera Id Setup

    SETUP PROCEDURES (7)Camera ID setup (B)Masking area setup Move the cursor to the setting to Move the cursor to the setting to the the right of "ID" by pressing the Up or right of "BLOCK" by pressing the Up or the Down button.

  • Page 18: Camera Id Setting

    SETUP PROCEDURES (8)Camera ID setting Press the Enter button, the <DET> Move the cursor to the setting to the item will become <WAIT> and the right of "ID" by pressing the Up or the camera will start operating an auto- Down button.

  • Page 19: Remote Control Via Computer

    SETUP PROCEDURES REMOTE CONTROL VIA Remark: Please ask your camera provider COMPUTER for the remote controller software. (a)Camera and computer settings, install the remote controller software. RS232 RS485 RS485 to RS232 convert (b)Connect computer camera. As connect the computer and camera together, the following three items need to be set as the same setting: 1.ADDRESS:The address on the software...

  • Page 20: Specifications

    SPECIFICATIONS Signal system Image system Imaging area 4.9mm x 3.7mm 1/3"-type vertical double density interline CCD Image pickup device Effective pixels(HxV) Electric Scanning system Internal / linelock Sync system 540/600 TV lines (day/night mode) Horizontal resolution 52dB Dynamic range CS with backfocus Lens mount Digital zoom Digital pan, tilt...
