SUPPLIED ACCESSORIES
For the mounting bracket
Mounting bracket
Knob bolts
Screws (5×20 mm) Spring washers (M5)
Microphone
Sponges
DC power cable (OPC-891A)*
Microphone hanger
and screws (3×16 mm)
The following items are sold by the set with the GM600.
PS-310
Screws (5×20 mm)
Spare fuse (FGB 15 A)
DC power cable
(OPC-2352)
Flat washers (M5)
Accessory connectors
6 pin 8 pin
* Use for the
operation check.
(12 V DC only)
Flat washers (M5)
Spring washers (M5)
Ferrite EMI filter
+ Tie wrap

TABLE OF CONTENTS

IMPORTANT ...................................................................................... i
EXPLICIT DEFINITIONS ................................................................... i
DISPOSAL ......................................................................................... i
IN CASE OF EMERGENCY ............................................................. ii
INSTALLATION NOTE ..................................................................... ii
PRECAUTIONS ................................................................................iii
SUPPLIED ACCESSORIES ............................................................ iv
1 OPERATING RULES .................................................................. 1
2 PANEL DESCRIPTION ........................................................... 2-5
■ Front panel ..............................................................................2
■ Function display (Main screen) ............................................... 3
■ Software key function .............................................................. 5
■ Speaker Microphone ............................................................... 5
3 PREPARATION ...........................................................................6
■ Entering the MMSI code ......................................................... 6
4 BASIC OPERATION ............................................................. 7-12
■ Transmitting and receiving ...................................................... 7
■ DSC Task mode ...................................................................... 8
■ Sending a Distress call ......................................................... 10
■ Sending an Individual call ..................................................... 11
5 MENU SCREEN ..................................................................13-14
■ Construction ..........................................................................13
■ Selecting a Menu item .......................................................... 14
6 CONNECTIONS ..................................................................15-17
■ Connections ..........................................................................15
■ Power supply connections .................................................... 17
7 SPECIFICATIONS AND OPTIONS ........................................... 18
■ Specifications ........................................................................18
■ Options ..................................................................................18
8 COUNTRY CODE LIST ............................................................. 19
