VT-PTZ220HD
On Cue 2.0 MegaPixel HD-SDI
20x IP PTZ Camera
• 1/2.8" 2.0 Megapixel Sony® Exmor™ Progressive Scan CMOS Sensor
• Built-in X20 times Optical Power Zoom Camera. (4.7mm to 94mm)
• True Night Shot function with Exmor ICR Day/Night Function.
• 248 Programable Presets
• 8 Patterns record and play back user preference of surveillance path up to 480° sec.
• 16 Scans: 8 speed steps with smooth vector scan.
• 8 Tours: Each tour consists up to 42 Presets, Patterns, and Scans
• 8 Alarm inputs with 0~8 Priority / 2 Auxiliary outputs programmable NC & NO.
• 8 Privacy Zones: 4 Polygon / Video off or 4 masked Block /Video off / Mosaic
• 64 steps of variable speed from 0.1°/sec to 105°/sec.
• Max manual speed 420°/sec with Turbo key pressed, Preset speed is 420°/sec.
• Programmable user preferences of speed (Changeable 60°/sec to 105°/sec).
• Addressable up to 999 camera IDs (Extendable up to 399 in special mode).
• Built-in RS-485 receiver driver.
• On-site software upgrade and upload/download of programmed data into the KBD.
• Built-in power-line surge protection and lighting protection.
Advertisement
Table of Contents
Related Manuals for Vitek VT-PTZ220HD
Summary of Contents for Vitek VT-PTZ220HD
- Page 1 VT-PTZ220HD On Cue 2.0 MegaPixel HD-SDI 20x IP PTZ Camera • 1/2.8” 2.0 Megapixel Sony® Exmor™ Progressive Scan CMOS Sensor • Built-in X20 times Optical Power Zoom Camera. (4.7mm to 94mm) • True Night Shot function with Exmor ICR Day/Night Function.
-
Page 2: Content Verification
1. CONTENT VERIFICATION Before installing the controller, please make sure that the following items are included in the box: If any of these materials are missing, please contact the vendor help desk immediately. Item Quantity Appearance PTZ Dome Camera User’s Manual Mount Hardware 1set Alarm Cable... -
Page 3: Disclaimer
Vitek Industrial Video Products Inc. Vitek makes no warranties for damages resulting from corrupted or lost data due to a mistaken operation or malfunction of the Speed Dome Cameras, peripheral... -
Page 4: Warning And Caution
HD-SDI CAMERA 3. WARNING AND CAUTION WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMENT. CAUTION EXPLANATION OF GRAPHICAL SYMBOLS The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to... -
Page 5: Ce Compliance Statement
HD-SDI CAMERA 4. FCC COMPLIANCE STATEMENT FCC INFORMATION: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. -
Page 6: Important Safeguards
HD-SDI CAMERA 6. IMPORTANT SAFEGUARDS Read these instructions. Heed all warnings. Follow all instructions. Do not use this equipment near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other equipment (including amplifiers) that produce heat. -
Page 7: Table Of Contents
HD-SDI CAMERA TABLE OF CONTENTS 1. CONTENT VERIFICATION ............0 2. DISCLAIMER ................1 5. CE COMPLIANCE STATEMENT ............. 3 6. IMPORTANT SAFEGUARDS ............4 7. FEATURES ................7 8. INSTALLATION AND CONFIGURATION ......... 8 8.1 T ..............8 YPICAL YSTEM ONFIGURATION 8.2 B... - Page 8 HD-SDI CAMERA 10.3 Screen .................... 38 10.3.1 Language ....................... 38 10.3.2 Privacy Zone ......................38 10.3.3 North Direction ...................... 40 10.3.4 Zone Title ....................... 40 10.3.5 CAMERA TITLE ....................... 41 10.3.6 OSD DISPLAY ......................42 10.4 CAMERA SETUP ................43 10.4.1 AE Control (Automatic Exposure) .................
-
Page 9: Features
HD-SDI CAMERA 7. Features The PTZ Dome Camera features a high resolution Sony Exmor CMOS image ® sensor, That supports FULL HD (high definition) to produce high-quality images. User friendly, on-screen pull-down menus and short-cuts make it easy to setup and program functions. -
Page 10: Installation And Configuration
HD-SDI CAMERA 8. INSTALLATION AND CONFIGURATION 8.1 TYPICAL SYSTEM CONFIGURATION Additional Speed Dome joystick controllers and a variety of external switching devices such as HD-SDI multiplexers (MUXs) and HD-SDI Digital Video Recorders (DVRs) may be incorporated to accommodate the needs from a small to a large surveillance/security system. -
Page 11: Basic Configuration Of Speed Dome Camera System
HD-SDI CAMERA 8.2 BASIC CONFIGURATION OF SPEED DOME CAMERA SYSTEM POWER AC 24V STP AWG # 22 J-BOX BACK J-BOX FRONT DOME1 SLAVE KBD DC 12V DATA2 DATA1 ALARM/PC BNC MONITOR DATA2 DATA1 REAR KEYBOARD CONTROLLER 4 ALARM INPUT 1 AUX OUTPUT RS-485 HALF DUPLEX MODE CONTROLLER... -
Page 12: Layout Of Switches
HD-SDI CAMERA 8.3 LAYOUT OF SWITCHES Figure 3 – HD-SDI Layout of Switches... - Page 13 HD-SDI CAMERA Figure 4 – HD-SDI Sub Connector...
-
Page 14: Principle Of Termination
HD-SDI CAMERA 8.4 PRINCIPLE OF TERMINATION Every device that is connected at the end of the communication data line must be terminated by either the DIP switch setting or an appropriate device such as a termination jumper to prevent potential control signal errors. See Figure 6 for termination switch settings and Figure 7 for examples of devices requiring termination. - Page 15 HD-SDI CAMERA Figure 6 - Termination Diagram...
-
Page 16: Dome Camera Address (Id)
HD-SDI CAMERA 8.5 DOME CAMERA ADDRESS (ID) Each dome camera must have a unique address (ID). Identical IDs on the same line may damage the control circuit caused by an electrical short. When installing multiple dome cameras or a DVR, it is recommended that the dome camera ID’s be identical to the camera port of the DVR. -
Page 17: System Setup
HD-SDI CAMERA 8.6 SYSTEM SETUP The PTZ Dome Camera support several High Definition video standards such as 1080i 60Hz, 1080i 50Hz,1080p 30Hz, 1080p 25Hz, 720p 60 Hz or 720p 50Hz, 720p 30 Hz or 720p 25Hz. (1080p 30Hz = 1080p 30 fps) See Figure 9 (S4) for the appropriate protocol switch settings. -
Page 18: Connections
HD-SDI CAMERA 8.7 CONNECTIONS 8.7.1 How to Connect RS-485 The dome camera has a built-in RS-485 receiver so that it can be controlled remotely by an external control device such as a joystick controller or a DVR. RS-485: Connect the Tx(D)+and Tx(D)- of the RS485 control devices (KBD, DVR…) to RX+, RX- of the dome camera. -
Page 19: Connecting Alarms
HD-SDI CAMERA If the distance between the camera and the monitor exceeds the recommended maximum, please use an auxiliary HD-SDI Repeater. Figure 10 – HD-SDI Video Cable 8.7.5 Connecting Alarms Alarm In (AL1 to 8) Magnetic, PIR or other external sensor devices can be used to signal the dome camera to react to an event. -
Page 20: Power Supply (Ac/Dc)
HD-SDI CAMERA Alarm out (NO,NC,COM) activation J1: Alarm1(part A) J2: Alarm2 (part B) Black Alarm1 Black Alarm5 Brown Alarm3 Brown Alarm6 Alarm3 Alarm7 Orange Alarm4 Orange Alarm8 Yellow A1 GND Yellow A2 GND Green COM A Green COM B Blue NC A Blue NC B... -
Page 21: Mounting The Dome Camera
HD-SDI CAMERA 8.8 MOUNTING THE DOME CAMERA Once all DIP switches are set properly and all external connections are made, the dome camera can be mounted. The Speed Dome camera is designed to mount on a structural body supporting loads up to 5 Kg. (See Figure 12). Figure 12 - Example of a ceiling mounted installation... - Page 22 HD-SDI CAMERA Figure 13 - Example of a Surface mounted installation...
-
Page 23: Power On And Boot-Up Sequence
HD-SDI CAMERA 8.9 POWER ON AND BOOT-UP SEQUENCE When the power is applied to the PTZ dome camera, it will start the boot-up sequence. When boot-up is done, the following information is displayed on the monitor screen. The boot-up sequence displays information of the PTZ dome camera for service or trouble shooting purposes. -
Page 24: Normal Display (Osd)
HD-SDI CAMERA 8.10 NORMAL DISPLAY (OSD) After a successful boot-up sequence the following information can be displayed on the monitor screen. 00/00/0000 00:00:AM (Function Title) AF AE Message ALARM:123 20.0X 270.0,090.0 "N DOME ID:0001 On Screen Display in normal control mode 00/00/0000 00:00:00 AM Date and time (Function Title) -
Page 25: Program & Operation
HD-SDI CAMERA 9. PROGRAM & OPERATION 9.1 DOME CAMERA KEY BOARD CONTROLLER Prior to programming or operating a dome camera, please make sure that both the camera and the joystick controller are communicating. In order for changes to take effect for a camera, particular camera’s ID must be selected on the controller. -
Page 26: Functions
HD-SDI CAMERA 10. FUNCTIONS 10.1 MAIN MENU By pressing the MENU button on the keyboard controller, the following On- screen Main Menu will be shown on the monitor screen. Main Menu Function Action Screen Camera Date/Time Data Setup Exit 10.1.1 Home Function After Home item has been selected, follow the directions below to set Home function. -
Page 27: Preset
HD-SDI CAMERA # Number : - - - # Waiting Time : 10~240 Seconds # Operation : Enable/ Disable The Home function applies to the predefined functions such as Preset, Tour, Pattern, or Scan function after the keyboard controller has been idle for a programmed time. -
Page 28: Edit Title
HD-SDI CAMERA 1. Edit the title of the Position Preset (see section 10.1.2.1.Edit Title). 2. Edit the camera position (see section 10.1.2.2. Edit Position). 3. Edit the camera AE settings (see section 10.4.1. AE Control). 4. Edit the camera WB settings (see section 10.4.2. WB Control). 5. -
Page 29: Pattern
HD-SDI CAMERA PRESET POSITION SETUP CONTROL Press IRIS-OPEN to Save 123.0,100.0 10.0X 123.0,100.0 Angles of PAN,TILT 10.X X Zoom magnification 1. Edit the position (joystick up/down/left/right) and the zoom factor (TELE/WIDE) Press the IRIS-OPEN button to save the settings 10.1.3 Pattern A pattern records a user-defined series of pan, tilt, zoom and focus movements. - Page 30 HD-SDI CAMERA number. 2. Move the cursor position with Joystick (up/down) 3. Select the column number(01) 4. Control the Joystick(tele/wide) to Open the PATTERN AREA SETUP menu The recording starts. PATTERN AREA SETUP CONTROL :000 SEC Total :000 SEC Press IRIS-OPEN to save 320.0 000.9 1.3X Scan the relevant area.
-
Page 31: Scan
HD-SDI CAMERA main DOME MENU. 10.1.4 Scan The scan function enables the PTZ dome camera to move automatically between two user-defined positions at different speeds. This is very helpful if monitoring certain areas frequently. Scans can be called directly, assigned to actions or applied as “home” position. SCAN SETUP Number Title... -
Page 32: Tour
HD-SDI CAMERA 7. Set the swap option. 8. Set the dwell time. 9. Execute Save and Exit. To run a stored scan directly from the dome menu, go to Run Function in the main DOME MENU. 10.1.5 Tour Tours can be called directly, assigned to actions or applied as “home” position. 8 programmable tours are available Each tour can consist of up to 42 functions (preset, pattern, scan or other tour). -
Page 33: Run Function
HD-SDI CAMERA TOUR MENU 01/06 TOUR No :01 Title:TOUR1 FUNC NO DW TITLE ---- -- -- ---------------- ---- -- -- ---------------- ---- -- -- ---------------- ---- -- -- ---------------- ---- -- -- ---------------- ---- -- -- ---------------- ---- -- -- ---------------- Previous Next Save and Exit... -
Page 34: Actions
HD-SDI CAMERA RUN FUNCTION Function : ------------- Number : ---- Action : --- Exit Function : Preset/Pattern/Scan/Tour/Home/ Auto Pan/Alarm out Number : Function Number Action : ON, OFF (ALARM OUT only) Follow the steps below to program the Run Function: 1. -
Page 35: Alarm List
HD-SDI CAMERA ALARM ACTION SETUP FCT FCT No OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF Save and Exit Alarm input number Function Type: PRESET, PATTERN, TOUR, SCAN, HOME FCT No Number of Function NO (Normally Open) NC (Normally Closed) OFF: Ignore... -
Page 36: Clear Alarm List
HD-SDI CAMERA # TIME : displays in 24 Hour format only. # The alarm list displays the date and time, and alarm input number up to 80 alarms. # Push the Joystick right or left at the “Previous Next” to see the next numbers. # A001 :means the alarm occurs at alarm input 1. - Page 37 HD-SDI CAMERA Action Title Up to 12 characters (see section 10.1.2.1 Edit Title) Action Day : H(Holiday) S(Sunday) M(Monday) T(Tuesday) W(Wednesday) T(Thursday) F(Friday) S(Saturday) OMIT : O(Holiday) (see section 10.5 Date/Time) Start Time hh:mm, AM/PM Add Action To List Add the current action to the list. Delete Action Delete the current action from the list.
- Page 38 HD-SDI CAMERA Delete Action Are you sure ? > 1. Select YES to delete the action from the list. Note: That a scheduled action has no duration. Therefore, you should set a second action to end the previous action. For example, suppose you want to operate the camera in black and white mode after 10:00pm and in Day/Night auto mode from 06:00am every day: First, program an action with the settings D/N:BW at 10:00 PM every day.
- Page 39 HD-SDI CAMERA Edit Day EDIT DAY HOLIDAY Sunday Monday Tuesday Wednesday :ON Thursday Friday Saturday All on ALL off Save and Exit HOLIDAY: OMIT : The action will not occur on a day of the week for which it is set If that date is in the list of holidays (see section 10.5 Date/Time) : The action will occur on a day of the week for which it is set if that date is in the list of holidays.
-
Page 40: Schedule Action List
HD-SDI CAMERA 10.2.5 Schedule Action List LIST ACTION :ALL > 01: ACTION ACTIVE HSMTWTFS 00:01 AM PRESET Previous Next Exit LIST ACTION ALL, PRESET, SCAN, PATTERN, TOUR, AUTOPAN, ALARM OUT, ALARM IN, D/N:BW, D/N:COLOR, D/N:AUTO 1. Select the LIST ACTION type to sort the action list. Ø 2. - Page 41 HD-SDI CAMERA ZONE SETUP allows you to hide (mask) up to 8 user-definable areas in the camera. PRIVACY ZONE SETUP TITLE METHOD COLOR ZT None None None None None None None Save and Exit TITLE Up to 16 characters METHOD No.
-
Page 42: North Direction
HD-SDI CAMERA 1. Select the TITLE of the privacy zone. 2. Control the joystick(tele/wide) to edit the privacy zone title (see section 10.1.2.1 Edit Title). 3. Select the METHOD for the privacy zone masking. If the selected METHOD is BLOCK, select the required color for the privacy zone masking. -
Page 43: Camera Title
HD-SDI CAMERA Zone TITLE SETUP 01/03 Title Start ----- ----- ----- ----- ----- ----- ----- ----- ----- ----- ----- ----- ----- ----- ----- ----- Previous Next Save and Exit 1. Select an Area Title item. 2. Select the Start angle field. 3. -
Page 44: Osd Display
HD-SDI CAMERA EDIT TITLE DOME 123456790 Space ABCDEFGHIJ Backspace KLMNOPQRST Insert UVWXYZ()-/ Delete Abcdefghij Delete All Klmnopqrst Exit uvwxyz*,.: Save and Exit Blinking cursor (D) Digit position Yellow cursor (D) Current cursor position 10.3.6 OSD DISPLAY DISPLAY SETUP DOME ID DOME Title Position Area Title... -
Page 45: Camera Setup
HD-SDI CAMERA 10.4 CAMERA SETUP CAMERA SETUP AE Control WB Control Focus Control Night Shot Digital Zoom : OFF Gamma : STADNDARD Noise Filter : OFF Camera Default Save and Exit 10.4.1 AE Control (Automatic Exposure) AE CONTROL Mode :AUTO Iris :F2.8 Gain... - Page 46 HD-SDI CAMERA used in countries with a 50 Hz power supply frequency. - 1/120s for PAL models used in countries with a 60 Hz power supply frequency. IRIS: Iris priority mode Variable Iris (F1.6 to Close, 18 steps), Auto Gain and Shutter speed. BRIGHT: Variable Iris and Gain (Close to F1.6, 17 steps at 0dB:F1.6, 15 steps from 0 to 28 dB) according to the brightness level.
- Page 47 HD-SDI CAMERA Back Light Compensation Back light compensation: ON / OFF Compensates for the silhouetting effect of backlit objects (e.g. in front of windows, glass doors or other sources of light). When the background of the subject is too bright, or when the subject is too dark due to shooting in the AE mode, back light compensation will make the subject appear clearer.
-
Page 48: Wb Control (White Balance)
HD-SDI CAMERA 10.4.2 WB Control (White Balance) WB CONTROL Mode :AUTO R Gain :208 B Gain :160 Execute One Push Save and Exit Mode AUTO: Automatically and permanently computes the white balance value output using color information from the entire screen (based on a range of values from 3000 to 7500K). -
Page 49: Focus Control
HD-SDI CAMERA Adjustable in MANUAL mode only. 10.4.3 Focus Control FOCUS CONTROL Mode :AUTO Focus Limit :30cm AF Sensitivity :Low IR Compensation :OFF Exit Mode AUTO: Automatically adjusts the focus position (passive auto focus). Sufficient illumination and subject contrast for central measurement area are required. -
Page 50: Night Shot
HD-SDI CAMERA use as approximate values. The Infinity mode overrides automatic focusing and positions the focus to infinity (∞). This ensures a sharp and clearly reproduction of very distant objects CAUTION: Please avoid continuous, 24-hour use of the auto focus under heavy movement condition. -
Page 51: Noise Filter
HD-SDI CAMERA 10.4.7 Noise Filter The NR (Noise Reduction) function removes noise (both random and non-random) to provide clearer images. This function has Five steps: levels 1 to 4, plus off. The NR effect is applied in levels based on the gain, and this setting value determines the limit of the effect. - Page 52 HD-SDI CAMERA MM/DD/YYYY YYYY/MM/DD Daylight Saving ON / OFF Edit Daylight Saving The start and end date of the daylight saving time can be set RELATIVE or FIXED. RELATIVE: The daylight saving time occurs on a different date each year. DAYLIGHT SAVING Type :RELATIVE...
- Page 53 HD-SDI CAMERA The holiday occurs on a different date each year, such as the fourth Thursday in November. EDIT HOLIDAY Number :NEW Type :RELATIVE Month :NOV Week :4th :THE Add Holiday Delete Holiday Exit FIXED: The holiday occurs on the same date each year. EDIT HOLIDAY Number Type...
- Page 54 HD-SDI CAMERA 5. Select YES and control the joystick (right) To edit / overwrite a holiday, proceed as follows: 1. Select the Number of the holiday you want to edit. 2. Edit the selected holiday as described above. 3. Select Add Holiday and control the joystick (right) To delete a holiday, proceed as follows: Select the Number you want to delete.
-
Page 55: Data
HD-SDI CAMERA 10.6 Data DATA SETUP Factory Default Erase programmed Data Exit Factory Default The Factory Default function returns programmed data to initial state except the following: 1. Time and date Factory Default Are you sure ? > Erase Programmed Data This function erases programmed data from the MEMORY of the selected PTZ dome camera. -
Page 56: Setup
HD-SDI CAMERA Enabled for erasure. OFF Data will not be affected. 1. Execute Erase. ERASE PROGRAMMED DATA Are you sure ? > 2. Select YES and control the joystick (right). 10.7 Setup SETUP MENU Preset Freeze :OFF Speed :FAST Response Dome Angle Calibration Password Setup... -
Page 57: Dome Angle
HD-SDI CAMERA COMMUNICATOIN MODE Communication Type :RS-485 Response. Save and Exit 10.7.4 Dome Angle VIEW ANGLE SETUP Flip Tilt Limit :-05 Left Pan Limit :000.0 Right Pan Limit :000.0 Enable Pan Limit :OFF Apply Auto Pan Save and Exit Flip ON : The PTZ dome camera moves up to 180°... -
Page 58: Calibration
HD-SDI CAMERA When you enter the pan limit mode, the PTZ dome camera moves to 90° vertically automatically if the PTZ dome camera is positioned over 90° vertically 10.7.5 CALIBRATION Calibration Origin Offset : 000.0,000.0 Origin Enable : Disable Auto Calibration :On Exit Reset Origin : Calibrate the ORIGIN point. -
Page 59: Installation
HD-SDI CAMERA Repeat the above-mentioned procedure with the same numbers. If both passwords match, the password editing is completed and the message “Password match” is displayed. If the passwords don’t match, the message “Password do not match” is displayed. If so, try it again. Select the Save and Exit. - Page 60 HD-SDI CAMERA H/W Ver. Hardware version S/W Ver. Software version Camera Type of camera module Con. Type Type of connection board ID of PTZ dome camera Baud rate Set baud rate Protocol Set protocol type...
-
Page 61: Appendix
HD-SDI CAMERA 11. APPENDIX 11.1 SPECIFICATION CAMERA Camera(FCB-EH6300) Exmor CMOS sensor(Sony) Image Sensor 1/2.8" Picture elements 3270K Pixels 1080i/60/50, 1080p30/25 Video Standards 720p/60/50 20x optical zoom with auto focus Lens 12x digital zoom(240x with optical zoom) F1.6 to F3.5, f=4.7mm to 94mm View angle Approx. - Page 62 HD-SDI CAMERA Pan Angle 360° continuous rotation Repeatability 0.2° Flip Rotate 180° at bottom of tilt Normal Dome Speed. 0.1~105°/sec , PAN Speed Turbo Dome Speed. 0.1~420°/sec , PAN Speed Preset Dome Speed. 420°/sec recall Preset Speed Auto scan 16 auto scan include vector scan/1 Auto Pan Preset Position 248 positions with camera status (16-character title) Tour...
-
Page 63: Dimension
HD-SDI CAMERA 11.2 DIMENSION Figure 14 – HD-SDI Dimension... -
Page 64: Trouble Shooting
HD-SDI CAMERA 11.3 TROUBLE SHOOTING If problems occur, verify the installation of the camera with the instructions in this manual. Isolate the problem from the equipments in the system and refer to the equipment manual for further information. Problem Solution 1.Check that the power cord and line connection between the camera and monitor are properly connected. -
Page 65: Glossary
HD-SDI CAMERA 3. When a BNC cable adaptor is used to combine two or more BNC cables for distributed HD-SDI video transfer, make sure the impedance of the adaptor is 75Ω. Otherwise, it may cause shorter transfer distance or broken video transfer. RS-485 communication is not Check RS-485 communication settings available. - Page 66 HD-SDI CAMERA light situations. This setting does not effect camera operation in normal lighting situations. See also Automatic Gain Control (AGC). FLIP/ DIGITAL FLIP It allows the dome to turn 180 degrees when the camera tilts to its lower limit. When the dome flips (rotates), the camera starts moving upward as long as the tilt control is kept in the down position.
- Page 67 HD-SDI CAMERA to 8 patterns may be programmed for the dome camera. PRESET Programmed video scene, based on a specific pan, tilt, zoom, and focus settings. Up to 240 presets may be programmed for the dome camera. PRIVACY ZONES Privacy zones are areas that are masked. These masks prevent operators of the surveillance system from viewing these designated zones.
- Page 68 VITEK warrants to the purchaser that products manufactured by VITEK are free of any rightful claim of infringement or the like, and when used in the manner intended, will be free of defects in materials and workmanship for a period of three (3) years, or as otherwise stated above, from the date of purchase by the end user.
- Page 69 28492 Constellation Road ValenCia, Ca 91355 WWW.ViteKCCtV.CoM | 888-ViteK-70...
