7. Installation

The monitor can be fixed using either the 4 threaded holes on the reverse side (M3, size 75 x 75mm) or using the
threaded holes on the sides (M3 - remove plate first if required). Ensure that the side screws are not too long.

8. Connection

1 D-SUB IN
2 BNC IN
3
12VDC IN
Screws
Connecting a PC via the normal D-SUB socket
Connection via video connection cable (BNC)
Power supply/mains adapter connection
3
Connection for PC (SUB-D)
PC (not included
