Accessories and Part Numbers, cont'd

Cables

BNC-4 Mini HR cable is used for RGBS, and BNC-5 Mini HR
cable is used for RGBHV. Either type can also be used for RGsB,
component video, S-video, or composite video. All Extron BNC
cables have male gender connectors on both ends. A plenum
version of the BNC-5 Mini HR cable is also available.
BNC-5 Mini HR Cable
BNC-5-25'HR (25 feet/7.6 meters)
BNC-5-50'HR (50 feet/15.2 meters)
BNC-5-75'HR (75 feet/22.9 meters)
BNC-5-100'HR (100 feet/30.5 meters)
BNC-5-150'HR (150 feet/45.0 meters)
BNC-5-200'HR (200 feet/60.0 meters)
BNC-5-250'HR (250 feet/75.0 meters)
BNC-4 Mini HR Cable
BNC-4-25'HR (25 feet/7.6 meters)
BNC-4-50'HR (50 feet/15.2 meters)
BNC-4-75'HR (75 feet/22.9 meters)
BNC-4-100'HR (100 feet/30.5 meters)
BNC-4-150'HR (150 feet/45.0 meters)
BNC-4-200'HR (200 feet/60.0 meters)
BNC-4-250'HR (250 feet/75.0 meters)
S-video Cable
SVHS 6' (6 feet/1.8 meters)
SVHS 12' (12 feet/3.7 meters)
SVHS 20' (20 feet/6.1 meters)
SVHS 30' (30 feet/9.1 meters)
SVHS 50' (50 feet/15.2 meters)
SVHS 75' (75 feet/22.9 meters)
SVHS 100' (100 feet/30.4 meters)
Composite Video Cable
SHR 1-3' (3 feet/0.9 meters)
SHR 1-6' (6 feet/1.8 meters)
CD 900 Decoder • Accessories and Part Numbers
A-4
Part number
26-260-03
26-260-04
26-260-16
26-260-05
26-260-12
26-260-06
26-260-18
Part number
26-210-04
26-210-05
26-210-06
26-210-07
26-210-08
26-210-09
26-210-54
Part number
26-316-02
26-316-03
26-316-01
26-316-04
26-316-05
26-316-06
26-316-07
Part number
26-383-01
26-383-12
SHR 1-12' (12 feet/3.7 meters)
SHR 1-25' (25 feet/7.6 meters)
SHR 1-50' (50 feet/15.2 meters)
SHR 1-75' (75 feet/22.9 meters)
SHR 1-100' (100 feet/30.5 meters)
CD 900 Decoder • Accessories and Part Numbers
26-383-07
26-383-04
26-383-05
26-383-06
26-383-03
A-5
