3.9.2 Push handles with push bar

On all of our wheelchairs a push bar can be attached
to the long handles.
The wheelchair stays foldable. Additionally, the push
bar stabilizes the back and creates a similar use as a
stabilizing bar.
(1) To remove the push bar loosen the star knob
screw (A) and swing it down.
To close, guide the push bar under the open star
knob screw until it stops and tighten the screw.
ATTENTION
Please regard the warning instructions stated in
3.9!

3.10. Side guards

3.10.1 Standard side guards

All side guards, except the ones that can swing off
(desk or long side guard), are adjusted to your needs
and tightly attached by your rehab technician.
ATTENTION
Between side guard/wheel cover and rear wheels
is an INJURY RISK. Do not grab between the side
guard and the rear wheels.

3.10.2 Desk side guards/side guards long

The desk and the long side guards can be folded
away swung inward and completely removed.
(1) In order to open or swing backward and remove
these side guards press the lever (A) and put it into
the desired position (2-4).
After locking, make sure that the lever (A) from the
side guards has snapped back into the lock (B).

3.11 Armrests

All height fixated armrests are tightly screwed on by
your rehab technician.
(5) The height adjustable armrests can be operated
as follows: unlock the armrest with the locking lever
(A) on the bottom of the arm cushion and pull the
cushion in the desired position. Let go of the lever
and let the armrest snap into place.
(1)
(A)
(1)
(A)
(5)
(A)
user manual for sport and DLS frame
(B)
29
