Lyngdorf Audio SDA-2400 Owner's Manual

Digital stereo power amplifier
Hide thumbs Also See for SDA-2400:

Advertisement

Quick Links

Owner´s Manual SDA-2400
Version 17-08-2016

Advertisement

loading
Need help?

Need help?

Do you have a question about the SDA-2400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lyngdorf Audio SDA-2400

Summary of Contents for Lyngdorf Audio SDA-2400

  • Page 1 Owner´s Manual SDA-2400 Version 17-08-2016...
  • Page 2 With this purchase, you have joined the ranks of an elite group of people who believe that perfect sound is more than a luxury. It’s a requirement. The SDA-2400 will deliver an audio experience that will far exceed your expectations. We thank you for placing your confidence in Lyngdorf.

  • Page 3: Table Of Contents

    What’s in the box ........4 Connection guide ........10 Cleaning and maintenance ...... 11 Technical assistance ....... 12 Specifications ......... 13...

  • Page 4: What's In The Box

    What’s in the box SDA-2400 Mains cord Trigger cable Owner´s Manual...

  • Page 5: Front Panel

    Front panel Operate indicates the operational status of the SDA-2400: • Strong light - The SDA-2400 is operating normally. • Flashing - The SDA-2400 is in standby mode.

  • Page 6: Rear Panel

    Rear panel ANALOG ANALOG 100-120V / 220-240V UNBALANCED BALANCED 50/60 Hz 145W COAXIAL OPTICAL TRIG. TRIG. Power Right Left Input state CLASS 2 WIRING select...
  • Page 7 If there is a plug in the “Trigger In” socket with no voltage applied, the SDA-2400 is in standby mode. • If a DC voltage of 5-24V or a 50Hz AC voltage of 4-17Vrms is applied, the SDA-2400 will go into Operate mode. •...
  • Page 8 If a signal is not detected for around 30 minutes, the amplifi er will go into standby mode. “On” will keep the SDA-2400 permanently turned on. 3-4. Analog unbalanced and balanced input For connection to products with analog output, you may only connect to one input at a time. The input sockets are internally connected in parallel, so ALWAYS use EITHER the XLR inputs OR the phono inputs.
  • Page 9 10. Mains connector and switch Be sure that the power cord is inserted fi rmly in the connector. The mains switch will remove the amplifi er from your mains power.

  • Page 10: Connection Guide

    When connecting the speakers, always connect + and - from the amplifi er to the corresponding + and - terminals on the speaker. Warning: Never run the SDA-2400 in so-called “bridge mode.” Bridging the speaker output terminals will damage the amplifi er.

  • Page 11: Cleaning And Maintenance

    Cleaning and maintenance The SDA-2400 does not require any regular maintenance except to keep its exterior clean. Simply wipe it with a clean, soft cloth. A small amount of non-abrasive cleaner on the cloth can be used to remove any dirt or fi ngerprints. Do not use abrasive cleaners or cleaners containing liquid solvents.

  • Page 12: Technical Assistance

    Technical assistance For the latest version of this manual, please check the Lyngdorf website: www.lyngdorf.com. If you have any questions regarding your Lyngdorf product, please contact your nearest Lyngdorf representative or: SL Audio A/S Ulvevej 28 7800 Skive Denmark E-mail: sales@lyngdorf.com Web: www.lyngdorf.com...

  • Page 13: Specifications

    Specifications AUDIO Parameter Value Note Coaxial (192kHz / 24 bit) Optical (96kHz / 24 bit) Balanced input impedance 10 KOhm AC-coupled Unbalanced input impedance 200 KOhm AC-coupled Max. input voltage ±15Vp AC, 0-20 VDC Input sensitivity 2 Vrms 400 W/4 Ohms Output power, 8 Ohms 2 x 200 W 1 kHz, 0.05% THD+N...
  • Page 14 AUDIO Parameter Value Note THD+N, 1 W /8 Ohms 0.004% A-wgt. THD+N, 1 W/4 Ohms 0.006% A-wgt. THD+N, 100 W/8 Ohms 0.02% A-wgt. THD+N, 180 W/8 Ohms 0.05% A-wgt. THD+N, 200 W/4 Ohms 0.02% A-wgt. S/N ratio 117 dB A-wgt. ref 200 W/8 Ohms. Channel separation 96 dB 1 kHz, 200 W/8 Ohms.
  • Page 15 MAINS Parameter Value Note Power consumption <0.4 W STANDBY mode Power consumption 26 W OPERATE mode, no output. Power consumption 145 W 2 x 50 W/4R Power consumption 493 W 2 x 200 W/4R TRIGGER Parameter Value Note TRIGGER IN connector 3.5 mm (1/8”) mono jack Case=Gnd, Tip=Input TRIGGER OUT connector...
  • Page 16 SIGNAL DELAY Parameter Value Note Digital Input 0,6 mSec Analog Input 0,0 mSec MECHANICAL Parameter Value Note Width 45 cm Depth 36.7 cm Including loudspeaker connectors. Height 7.2 cm Including feet. Weight 6.5 kg...
