- Page 1 Millennium MkIV True Digital Amplifier Owners Manual - 1 -...
-
Page 2: Table Of Contents
Table of Contents WARNINGS ...3 Explanation of graphical symbols ...3 Important safety instructions...4 Unpacking and placement of the Millennium ...5 Operating voltage ...6 Product Registration ...6 Introduction ...7 Features:...7 Quick set-up ...8 Front panel...9 Controls ...9 The wheel ...9 Adjusting the volume ...10 Pre-set Volume...10 Maximum output level...10 Power ...10... -
Page 3: Warnings
WARNINGS CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL. TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. Explanation of graphical symbols Exclamation symbol The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions... -
Page 4: Important Safety Instructions
Important safety instructions 1:Read these instructions carefully before installing or operating this apparatus. 2:Keep these instructions. 3:Heed all warnings. 4:Follow all instructions. 5:Do not use this apparatus near water. 6:Clean only with a dry cloth. 7:Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 5: Unpacking And Placement Of The Millennium
When you have carefully removed the unit and accessory kit from the carton, visually check for shipping damage. Contact both the shipper and Lyngdorf Audio immediately if the unit bears any sign of damage from mishandling. All Lyngdorf Audio equipment is carefully inspected before leaving our factory. -
Page 6: Operating Voltage
Please record the serial number of your amplifier here for future reference. The serial number is printed on the label on the Millennium rear panel. You will need this serial number, should you ever require service for your Millennium power amplifier. Millennium MkIV serial number: _____________________ - 6 -... -
Page 7: Introduction
Introduction Lyngdorf Millennium is the world's first true-digital power amplifier where digital audio data is converted directly into sound without analog amplification or conventional low-level D/A conversion involved at any step. The core technology is based on patented EQUlBlT™ processing and output modules. The Lyngdorf Millennium is a modular design, a platform for state-of-the-art music reproduction. -
Page 8: Quick Set-Up
Quick set-up A. Connect your speaker cables to the terminals on the back panel. The speaker impedance should be 4-16 Ohms. If the speakers can be bi-wired, use both sets of terminals. Make sure that the red (+) terminal gets connected with the corresponding positive (+) terminal on your speaker. -
Page 9: Front Panel
Front panel Fig 1: Millennium front panel. Controls The buttons/controls on the front panel of the Millennium can all be used either with direct presses on the front or by operating the similar keys on the included remote control. All keys on the front except from the Mains switch (1) can be found on the remote control as well. -
Page 10: Adjusting The Volume
Adjusting the volume The volume can be adjusted by turning the big wheel or pressing volume up/down on the remote control. The volume level is displayed in decibels (dB where 99.9dB is the maximum setting giving full power for a full-scale input from a digital source. Note that no clipping is possible. -
Page 11: Polarity
Polarity You can switch the polarity 180 degrees with the remote control (explained later). The display confirms the polarity with either "pos" or "neg". Mute When "Mute" is activated from the remote control the display shows "---" and the amp will be muted. -
Page 12: Rear Panel
Rear panel Fig 2: Millennium rear panel. Do not cover or obstruct the ventilation slots on the rear panel. 1) Speaker terminals 2) AD Converter Input 3) D4 Input AES EBU 4) IEC Mains power connector 5) Digital Outputs D AES EBU 6) Digital Output D 7) RS 232 Input and Output 8) Speaker terminals... -
Page 13: Clock Gate
Clock Gate A proprietary 5-pole XLR input is provided for a clock synchronised CD-transport, where the reference clock is controlled by the Millennium. This feature is called Clock Gate. When a compatible device is connected to the 5-pole connector (2) position D4 selects the Clock Gate input as a source. -
Page 14: Remote Control
Remote Control The remote control is used to access the Millennium and replicate some of the buttons directly accessible on the front panel. The four buttons used for selecting which device to control are described below. To control the Millennium the AMP key should be pressed. -
Page 15: Software
Front panel operations The operations of the remote control receiver can be bypassed on the front panel for the Millennium. Bypassing the remote control is done with a long press on the Analog left selection key “A”. When the remote is turned off the Lyngdorf Logo blinks twice after a 2 sec. -
Page 16: Connectors
Connectors Mains Connector Mains voltage to the Millennium is applied via an IEC320 type connector. The supplied cable with safety ground should be used to connect the Millennium to a mains outlet. WARNING: Connect the power input only to the AC source printed on the label. -
Page 17: Technical Specifications
Technical specifications Audio Parameter Balanced input connectors Balanced input impedance Unbalanced input connectors RCA (phono) jack, gold-plated. Case=Gnd, Tip=Hot(+) Unbalanced input impedance 10kOhm DAC Out impedance Input sensitivity Power Supply Variation Output connectors Output power, 8ohms Output power, 4ohms Nominal load impedance Frequency response Frequency response Frequency response... - Page 18 Protection Parameter Grounding Output short circuit current Output DC voltage Over temperature Mains Parameter Mains input connector Mains voltage range Mains voltage range Internal mains fuse Internal mains fuse Power consumption Power consumption Power consumption Power consumption Trigger Parameter TRIGGER OUT connector TRIGGER OUT Voltage Mechanical Parameter...
-
Page 19: Trouble Shooting
Trouble Shooting Protection Mode A sophisticated monitoring circuit controls the operation of the amplifier. When an error is detected, the amplifier shuts down into protection mode immediately and indicates the status by flashing the Lyngdorf logo. Protection mode can be triggered by: 1. -
Page 20: Support
“Support” for latest version of control software, and newest version of this document. Technical assistance If you have any problems with or questions regarding your Lyngdorf Audio product, please contact your nearest Lyngdorf Audio representative or: Lyngdorf Audio Væselvej 114...
