- Page 1 Owner´s manual TDAI 2200 RoomPerfect™...
-
Page 3: Table Of Contents
Table of Contents Operating Voltage Unpacking the TDAI 2200 Serial Number Registration Introduction Accessories Front Panel Rear Panel Display Indicators Remote Control Menu System - Navigating the menu system Menu Tree Introduction to RoomPerfect™ - Global Listening - Focus Listening - Voicing RoomPerfect™... -
Page 4: Operating Voltage
Carefully remove the unit and accessory kit from the carton, visually check for shipping damage. Contact both the shipper and your Lyngdorf Audio representative immediately if the unit bears any sign of damage from mishandeling. All Lyngdorf Audio equipment is carefully inspected before leaving our factory. -
Page 5: Introduction
Introduction Congratulations on your investment in the Lyngdorf Audio TDAI 2200 with RoomPerfect™ The TDAI 2200 is more than just a very good high-end amplifi er, one that’s exceptionally pure and natu- ral sounding with even the most ‘demanding’ speaker loads. It also happens to be a completely unique Digital Control Centre. -
Page 6: Accessories
Accessories You should fi nd the following accessories included: Mains cord Microphone Programming cable 8 m (26.25 feet) XLR – XLR cable 200 mm (7.9 in) Microphone adaptor cable digital info analog menu TUNER channel volume ENTER random repeat Remote control Microphone stand with Mic clamp (delivered in a separate carton) -
Page 7: Front Panel
Front Panel TDAI 2200 Digital Amplifier Controls The buttons/controls on the front panel of the TDAI 2200 can all be operated either with direct presses or by operating the corresponding keys on the supplied remote control. All the keys on the front panel [except the Mains switch (1)] are duplicated on the remote control as well. -
Page 8: Rear Panel
Rear Panel Digital Input 1-3 RCA connectors for SPDIF input Digital Output Selected digital input is sent – full range or fi ltered via the DSP - to the Digital Output connector for daisy- chaining more than one TDAI 2200. The sample rate is fi xed at 96 kHz. This output is also active when Analog input is selected. -
Page 9: Display Indicators
12. Mic. In (left) / Trigger out (right) DC Trigger out for remote start of SDA 2175 power amplifi ers or similar equipment. Mic. in for connection of RoomPerfect™ microphone. 13. RS232 Input/Aux RS232 communication connectors for communication with a PC, remote control from Lyngdorf equip- ment with broadcast commands or linked control between amplifi... -
Page 10: Remote Control
Remote Control The remote control is used to access the menu system and replicate the buttons directly accessible on the front panel. To control the TDAI 2200 the AMP key should be pressed [please note the amplifi er’s volume and mute buttons still work when in CD mode]. The functionality of the buttons when AMP is pressed are as follows: Standby The standby button puts the TDAI 2200 in stand-by mode. -
Page 11: Menu System
13. Tuner No function. 14. Channel -/+ Toggles down/up between inputs. 15. Volume Up/down Changes volume in the chosen direction. 16. Up / Down / Left / Right In normal operation mode the Up/Down toggles between bypass and the available Focus and Global fi... -
Page 12: Menu Tree
Menu Tree This is an overview of the entire TDAI 2200 menu in software version 3.0. RoomPerfect Guided setup Advanced options Measure Focus Pos Measure Room Pos Display Timeout Disp. Brightness TDAI 2200 Main Menu RoomKnowledge TDAI 2200 Main Menu Display Volume Def. - Page 13 TDAI 2200 Main Menu Advanced setup Communication Master/Slave Line Out Routing Crossover freq. Comm Address Comm Speed Line Out Control Line Out Level Advanced setup Filter Type Trigger setup Software versions Delay Remote Control Factory Reset...
-
Page 14: Introduction To Roomperfect
Introduction to RoomPerfect™ Once the guided set-up has been successfully completed you have the option to listen to music through two listening settings; Focus 1 and Global room correction fi lters. The RoomPerfect™ fi lters are stored on the numerical buttons from 1 to 9 on the remote control. To change from one fi lter to the other you simply press the numerical button corresponding to the desired fi... -
Page 15: Roomperfect
RoomPerfect™ The sub menus accessible in the RoomPerfect™ menu are: Advanced options is available when Guided set-up has been performed. Guided Setup When you enter the RoomPerfect™ Main Menu for the fi rst time, only the Guided setup is available. Press Enter to initiate the guided set-up. -
Page 16: Setting The Measurement Volume Level
Setting the Measurement Volume Level The calibration volume is a recommended maximum volume. It is important that you always judge whether the calibration volume is too loud. The calibration volume should not be so loud that it causes: • uncomfortably loud sounds that are inconvenient to you or your environment, or •... -
Page 17: Focus Measurement
Focus Measurement When the calibration is OK, press Enter to start the measuring process and ‘Measuring Focus position …’ will be displayed. Each measurement comprises four steps: • A low and a high frequency measuring signal fi rst in the left and then in the right channel. The length of each measurement depends on a combination of the measurement volume, set in the calibration process, and the background noise in your local environment. -
Page 18: Adding More Room Measurements
When a random measuring position and microphone orientation has been chosen press Enter. The measur- ing process will start and the display will show ‘Measuring room position 1’. The measurement will stop prematurely if an error occurs during the measuring process. In this case, the error message ‘Retry room measurement –... -
Page 19: Calculation Of Focus 1 And Global Filters
Calculation of Focus 1 and Global Filters When RoomPerfect™ calculates the fi lters the display shows the following, ‘Calculating fi lters - Please wait’. The fi lter calculation process can be expected to take anywhere between 5 seconds and a minute de- pending on the specifi... -
Page 20: Roomperfect™ Advanced Menu
Advanced Options This section describes the options in the advanced menu, which is available after Guided Setup has been completed. Here you can add new listening positions and room measurements, check the RoomKnowl- edge of your current set-up, and check the RoomCorrection for the different fi lters. Measure Focus Pos Measure Focus Pos. -
Page 21: Roomknowledge
‘Add more room meas.? Yes/No’ will show in the display: • choose Yes to add another room measurement or, • choose No to stop adding more room measurements. If No is chosen the volume is returned to the default or lower. ‘Save room measurement(s)? Yes/No’... -
Page 22: Display
Display The sub menus accessible in the Display menu are: Display Display Timeout Disp. Brightness Volume Disp.Timeo. Display Timeout Display timeout set-up is used for enabling/disabling the 10 sec. display ’switch’off’ feature. If enabled the Main Display reading will switch off after 10 sec of inactivity from the remote control or front panel buttons. -
Page 23: Volume
Volume The sub menus accessible in the Volume menu are: Volume Def. Volume Max. Volume Def. Vol. The Default Volume setting controls the default volume at start-up and can be set from 0 to 99 dB. However, a setting over 88 is not recommended as this corresponds to max output with full scale digital input. -
Page 24: Input Name
Input Name As default, digital inputs are called Digital 1-5 and Analog inputs are called Analog 1-4. To change the name, choose an input and then between the following preset names: • ADC, Analog 1-4, AUX, CD, CD-1, CD-2, DAB, DAT, DBS, DCC, Digital 1-5, DVD, DVD-1, DVD-2, FM, LD, MD, PC, PHONO, RADIO, RIAA, SACD, SAT, TAPE, TUNER, TV, VCR, VDP, VIDEO, VIDEO-1, VIDEO-2. -
Page 25: Advanced Setup
Advanced setup The sub menus accessible in the Advanced menu are: Advanced setup Routing Delay Software versions Communication Master/Slave Crossover freq. Trigger setup Factory Reset Remote Control Line Out Filter Type Communication The sub menus accessible in the Communication menu are: Communication Comm Address Comm Speed... -
Page 26: Line Out
Fixed means there’s a constant full scale output – most often used as ‘tape out’ or when using a Lyngdorf Audio TDAI or SDAI as a ‘slave’ amplifi er in a bi-amping set-up. Regulated means that the output level will follow the level of the volume control. This setting is chosen if you have, for instance, a power amplifi... -
Page 27: Crossover Frequency
By using a high crossover frequency, the rear wall quarter wavelength refl ection is removed from the main speakers. If a Lyngdorf Audio corner woofer is used in a 2+2 set-up, a crossover frequency of 400 is recommended due to the high bandwidth of the corner woofer. -
Page 28: Delay
However, if the distance isn’t identical and/or you are using a sub- woofer, or a Lyngdorf Audio 2+2 system, you need to set a delay in order to ensure that the sound from each loudspeaker reaches the listening position simultaneously. -
Page 29: Remote Control
Remote Control Remote Control Remote Control set-up makes it possible to activate or de-activate the remote control. This is useful in set-ups with more than one TDAI 2200 amplifi er in the room. The master amplifi er then becomes the only one receiving signals from the remote, processes them and controls the rest of the TDAI 2200’s over the Lyngdorf RS232 link. -
Page 30: Roomperfect™ Troubleshooting
RoomPerfect™ Troubleshooting No microphone connected The error message ‘No microphone connected’ is displayed when no microphone is connected to the TDAI 2200. Solution: • Connect the microphone on the right-hand side of the back panel. No signal 1. The error message ‘Fault – No signal’ is displayed when the incoming signal is classifi ed as pure noise. -
Page 31: Software Upgrading
Software upgrading The TDAI 2200 fi rmware can be upgraded using the ‘Lyngdorf Audio – Serial Load’ software. This is in the PC package available from www.Lyngdorf.com. Follow the upgrade steps shown below to bring the product into upgrade mode. -
Page 32: Connectors
Connectors Mains Connector Mains voltage to the TDAI 2200 is applied via an IEC320 type connector. The supplied cable with safety ground should be used to connect the TDAI 2200 to a mains outlet. Connect the power input only to the AC source printed on the label. The warranty will not cover any damage caused by connecting to the wrong type of AC mains. -
Page 33: Optional Ad Converter Board
Optional AD Converter Board The Optional AD Converter card for the TDAI 2200 has input connectors for both balanced (XLR) and unbalanced (RCA) signals. The input impedance of the inputs are 10 kOhm. Balanced inputs The balanced XLR inputs are wired in accordance with IEC268: Pin 1: Chassis and ground. -
Page 34: Technical Specifi Cations
Technical Specifi cations Audio Parameter Balanced input connectors Balanced input impedance Unbalanced input connectors Unbalanced input impedance DAC Out impedance Input sensitivity Power Supply Variation Output connectors Output power, 8ohms Output power, 4ohms Nominal load impedance Frequency response Frequency response Frequency response Output impedance Output impedance... -
Page 35: Protection
Protection Parameter Grounding Output short circuit current Output DC voltage Over temperature Mains Parameter Mains input connector Mains voltage range Mains voltage range Internal mains fuse Internal mains fuse Power consumption Power consumption Power consumption Power consumption Trigger Parameter Trigger Out connector Trigger Out voltage Mechanical Parameter... -
Page 36: Technical Assistance
For latest version of control software, newest version of this document and ‘Questions and Answers’, please check the ‘Support’ section on the Lyngdorf Audio website. If you have any problems with or questions regarding your Lyngdorf Audio product, please contact your nearest Lyngdorf Audio representative or:... -
Page 37: Appendix
Appendix Voicing Curves Music 1 Ma gnitude R esponse: Music 1 10 Hz 100 Hz 1kHz 10kHz F requency (Hz) Relaxed Ma gnitude R esponse: R ela x ed 10 Hz 100 Hz 1kHz 10kHz F requency (Hz) Open Air Ma gnitude R esponse: Open Air 10 Hz 100 Hz... - Page 40 www.lyngdorf.com...
