6. About Hardware
COM-4C-PE
Table 6.2. Specification
Item
Number of channels
Interface type
Transfer method
Baud rate
Data length
Parity check
Controller chip
Connecting distance
Interrupt requests
I/O address
Power consumption (Max.) 3.3VDC 500mA(Max.)
Operating condition
Bus specification
Dimension (mm)
Interface connector
Weight
*1
These items can be set by software.
For the "Driver Library API-PAC(W32)" and the "Standard COM Driver Software COM Setup
Disk" on the supplied CD-ROM, the range is 15 - 921,600 bps.
*2
Data transmission at high speed may not be performed normally depending on the environment
including the type of status of connected material of cable and environment.
*3
The interrupt signals from all channels are connected as a single interrupt signal on the PCI
Express bus.
50
4ch
RS-232C
Asynchronous serial transfer
2 - 921,600bps *1 *2
5, 6, 7, 8 bits
1, 1.5, 2 stop bits *1
Even, Odd, Non-parity *1
162850 or equivalent
(Each channel has 128-byte receive and 128-byte transmit FIFO buffers.)
15m(Typ.)
1 level use *3
Any 32-byte boundary
0 - 50°C, 10 - 90%RH (No condensation)
PCI Express Base Specification Rev. 1.0a x 1
121.69(L) x 110.18(H)
37-pin D-SUB, female connector DCLC-J37SAF-20L9E (mfd.by JAE)
equivalent
90g
Specification
COM-2C-PE, COM-4C-PE, COM-8C-PE
