OPERATIONS MANUAL
DJI Inspire 1
Document Reference: droneswork Operations Manual/ 1.0
st
Issue 1.0 – 1
December 2015
All rights reserved. Copies of this publication may not be reproduced for personal,
company or organisation use without the expressed permission of droneswork.
