OWC miniStack Assembly Manual & User Manual page 9

5b. 2.5 inch SATA drive: Rotate the base as shown then
connect the SATA power and data cables to the
corresponding ports on the back of the drive. Set
the drive onto the black support strips, lining up the
screw holes.
6b. Hold the drive in place then flip the base over. Where
the screw holes on the drive overlap the screw holes
on the base, affix four the fine thread screws from
the packet.
7. Flip the base over then carefully align and re-seat the
top cover as shown at right.
8. Holding the top cover and base together, again flip
the miniStack over. Re-affix the four large corner
screws in the locations shown. Once complete, flip
the miniStack over.
This completes the assembly process.
OWC miniStack
7
Device Setup
