OWC miniStack Assembly Manual & User Manual page 8

3. Holding the base and top cover together, flip the
miniStack again, then carefully lift the cover off as
shown at right.
4. Remove the screw packet found on the base of the
miniStack. Set the screws aside for use in later steps.
5a. 3.5 inch SATA drives: Rotate the base as shown
then connect the SATA power and data cables to
the corresponding ports on the back of the drive.
Set the drive onto the black support strips; make
sure the screw holes are aligned.
6a. Hold the drive in place then flip the base over. Where
the screw holes on the drive and base overlap, affix
four of the coarse thread screws from the packet.
NOTE: most drives will use the pattern shown at
right in red, while some drives will use the pattern
shown in yellow.
OWC miniStack
6
Device Setup
