Technical Parameters - Fenix TK25 Operating Instructions Manual

Technical parameters

ANSI/PLATO FL1
Output
Runtime
Distance
Intensity
Impact Resistance
Waterproof
Note: The abovementioned parameters (lab-tested by using one Fenix 3.6V/3500mAh
rechargeable Li-ion battery) may vary between flashlights, batteries and environments.
Uses Cree XP-G2 S3 LED's with a lifespan of 50,000 hours

Powered by one rechargeable 18650 Li-ion battery or two 3V CR123A Lithium batteries

142.6mm Length x 25.4mm Body diameter x 40mm Head diameter

156.5 grams (excluding battery and belt clip)

Rotary flashlight head for switching between white and infrared light

Fitted with 850nm infrared light - compatible with most night-vision devices

Choices of infrared output: High (3000mW) and Low (1000mW)

Quick-release belt clip

Compatible with AER-03 remote pressure switch

Digitally regulated output maintains constant brightness

Reverse polarity protection, to protect from improper battery insertion

Tactical tail switch with instant- and momentary-on activation

Functional tail switch for output selection and instant strobe activation

Made of durable aircraft-grade aluminum

Premium type III hard-anodized anti-abrasive finish

Turbo High
1000 300
Lumens Lumens
5h
2h
20min
225m 124m
12650cd 3840cd
IP68, underwater 2m
Med Low
100 15
Lumens Lumens
22h
110h
20min
75m 25m
1400cd 160cd
1m
Strobe
1000
Lumens
/
/
/
