INSTANT RECOVERY
ELECTRIC FRYER
SERIES PRE-2000
MANUAL
IMPORTANT:
THIS MANUAL PROVIDES SPECIFIC OPERATING INSTRUCTIONS FOR
YOUR MODEL. USE THE INSTANT RECOVERY® ELECTRIC FRYER ONLY AS
INSTRUCTED IN THIS MANUAL.
KEEP A COPY OF YOUR BILL OF SALE.
The date on the bill establishes the warranty period should service be required.
If service is performed, it is in your interest to obtain and keep all receipts.
KEEP THIS MANUAL FOR TRAINING NEW PERSONNEL.
Record the Serial number and Model number of this Instant Recovery
Fryer in the spaces provided. Keep these numbers for future reference.
Keating commercial fryers are not intended for household use.
As continuous product improvement occurs, specifi cations may be
changed without notice.
1-800-KEATING | keatingofchicago.com
SERIAL NUMBER
MODEL NUMBER
®
®
Electric
elcFryPre2000_2013
Part # 000784
09/15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRE-2000 SERIES and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Keating Of Chicago PRE-2000 SERIES

Summary of Contents for Keating Of Chicago PRE-2000 SERIES

  • Page 1 ® INSTANT RECOVERY ELECTRIC FRYER SERIES PRE-2000 MANUAL IMPORTANT: THIS MANUAL PROVIDES SPECIFIC OPERATING INSTRUCTIONS FOR YOUR MODEL. USE THE INSTANT RECOVERY® ELECTRIC FRYER ONLY AS INSTRUCTED IN THIS MANUAL. KEEP A COPY OF YOUR BILL OF SALE. The date on the bill establishes the warranty period should service be required. If service is performed, it is in your interest to obtain and keep all receipts.

  • Page 2: For Your Safety

    PURCHASER SHOULD POST IN A PROMINENT LOCATION. WARNING Burns Shock Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. Improper installation can cause damage, injury or death.

  • Page 3: Table Of Contents

    ELECTRIC FRYER - SERIES PRE-2000  TABLE OF CONTENTS Important Safety Instructions ..........i Thermostat Bulb Positioning ........... 10 INTRODUCTION .............. 1 Hi-Limit Check ............... 10 INSTALLATION SERVICE DIAGNOSIS Damage During Shipment ..........1 Troubleshooting Chart ..........11 - 12 Standard Features ............

  • Page 4: Standard Features

    STANDARD FEATURES CM Model: BB and TS Counter Model Fryers are equipped with all of the same features as the BB and • Highly polished stainless steel fryer vessel TS Models respectively, but take up less than three square feet of counter space. The 10x11CM Model •...

  • Page 5: First Steps Positioning

    ELECTRIC FRYER - SERIES PRE-2000  2. The restraint means must be FIRST STEPS NOTICE attached to the rear of the Keating Electric Fryer within 2" of the center POSITIONING line width and approximately 1-5/8" The fryer must be placed under an exhaust hood with from the bottom of the cabinet a fi...

  • Page 6: Operating Filling

    NOTE: Some fryers with Basket-Lifts, Zero-Space™ Filters (model BB ZS or TS ZS) or Central Filters may BE SURE THE HEATING ELEMENTS ARE COM- have separate 120 volt control circuit connections. PLETELY COVERED WITH OIL BEFORE SWITCHING Fryers with Basket-Lifts or Zero-Space™ fi lters will THE FRYER ON.

  • Page 7: Cooking

    ELECTRIC FRYER - SERIES PRE-2000 B. CPU Models NOTE: For a fryer with a Central or Safe & Easy® Filter, always check the rear drain operating handle *See separate computer instructions or call before attempting to use the fryer. A safety switch 1-800-KEATING.

  • Page 8: Shutdown

    8. When cooking cycle is complete, an audible alarm 4. For front drain fryers, slowly turn handle forward will sound and the basket(s) will raise automatically. to avoid splashing. The drain valve will be completely Allow oil to drain before removing baskets. Basket(s) open after 1/4 turn.

  • Page 9: Electronic Timers

    ELECTRIC FRYER - SERIES PRE-2000 14. Prior to refi lling with oil, wipe the inside of the Figure 6 fryer vessel making sure all water and Klenzer has Keating Klenzer been removed. and Sea Powder WATER IN ANY FORM AND HOT OIL DON'T MIX! 15.

  • Page 10: Electronic Timers

    B. Electronic Timer Programming 18 - 34x24 TS MODELS A. Timer Mode Figure 7 1. Turn round knob clockwise (toward “+”) to Electric Timer increase time or counterclockwise (toward “-”) to decrease time. NOTE: When programming the timer up to one min- ute, the display goes up or down in seconds only.

  • Page 11: Warranty Repairs

    ELECTRIC FRYER - SERIES PRE-2000 PROGRAMMING PREVENTIVE MAINTENANCE To program the timers, the unit must be in the idle Preventive maintenance should be done in daily, mode. Press and hold the set button for approxi- weekly, monthly and yearly intervals as neces- mately two seconds.

  • Page 12: Limited Calibration

    3. Non-Stainless Steel Surfaces: When hot oil comes Thermostat Bulb Positioning in contact with iron, steel, aluminum or other met- Keating’s patented thermostat application is accurate als, a chemical breakdown takes place within the oil. within ±2°F of the dial setting between 250°F and Stainless steel has long been recognized as being the 350°F.

  • Page 13: Service Diagnosis

    ELECTRIC FRYER - SERIES PRE-2000  SERVICE DIAGNOSIS The following diagnosis is only to be used as a guide to qualifi ed service personnel. Keating recommends that you use a qualifi ed & licensed service company. (Equipment still under warranty requires it.) Call 1-800-KEATING if you need assistance in locating a qualifi...

  • Page 14: Ordering Parts

    PROBLEM PROBABLE CAUSE SOLUTION Oil in fryer vessel boils over a. Baskets are overfi lled. a. Don’t overfi ll baskets. b. Fryer vessel overfi lled with oil. b. Fill fryer up to “Fill Level” line as oil expands when heated. c.

  • Page 15: Parts List

    ELECTRIC FRYER - SERIES PRE-2000  PARTS LIST - ELECTRIC FRYER P/N 220V ITEM DESCRIPTION MODEL ELEMENT 10x11 34x24 Quantity Per Model HEATING ELEMENT 2500 W 004347 3800 W 005623 4350 W 004349 6000 W 004353 004353 004355 004355 6500 W 014493 TEFLON RING BB, TS...
  • Page 16 ELECTRIC FRYER ASSEMBLY (Part numbers correspond to list on page 13) Bushing Ground Lug Leg Channel with Legs Door and Bullet Feet Splashback Exploded view of heating element wire connection hardware keatingofchicago.com...

  • Page 17: Bb Control Panel Parts List

    ELECTRIC FRYER - SERIES PRE-2000 BB CONTROL PANEL ITEM DESCRIPTION THERMOSTAT 031099 THERMOSTAT DIAL PLATE 058037 THERMOSTAT KNOB, BLACK 060612 RETAINING SCREWS 004610 ON/OFF/MELT SWITCH PLATE 009919 TOGGLE SWITCH, ON/OFF/MELT 004326 INDICATING LIGHT - AMBER 220V 004157 HI-LIMIT TEST PLATE 004305 HI-LIMIT TEST BUTTON 004304...

  • Page 18: Ts Control Panel Parts List

    TS CONTROL PANEL ITEM DESCRIPTION THERMOSTAT 031099 THERMOSTAT DIAL PLATE 058037 THERMOSTAT KNOB, BLACK 060612 RETAINING SCREWS 004610 LIGHTS, WHITE 016639 LIGHT, RED 016640 MOUNTING PLATE ----- TOGGLE SWITCH, ON/OFF/MELT 004326 HI-LIMIT TEST BUTTON 004304 TIMER 023709 MELT CONTROL, 220V 037890 NUT WITH BOOT 009389...

  • Page 19: 10X11", 14" Basket-Lift Control Panel

    ELECTRIC FRYER - SERIES PRE-2000 10x11 & 14 BASKET-LIFT CONTROL PANEL ITEM DESCRIPTION THERMOSTAT 031099 THERMOSTAT DIAL PLATE 058037 THERMOSTAT KNOB, BLACK 060612 RETAINING SCREWS 004610 LIGHTS, WHITE 016639 LIGHT, RED 016640 MOUNTING PLATE ----- TOGGLE SWITCH, ON/OFF/MELT 004326 HI-LIMIT TEST BUTTON 004304 TIMER 023709...

  • Page 20: 18 & 34X24 Basket-Lift Control Panel

    18 & 34x24 BASKET-LIFT CONTROL PANEL ITEM DESCRIPTION THERMOSTAT 031099 THERMOSTAT DIAL PLATE 058037 THERMOSTAT KNOB, BLACK 060612 RETAINING SCREWS 004610 LIGHTS, WHITE 016639 LIGHT, RED 016640 MOUNTING PLATE ----- TOGGLE SWITCH, ON/OFF/MELT 004326 HI-LIMIT TEST BUTTON 004304 TIMER 023709 MELT CONTROL, 220V 037890 NUT WITH BOOT...

  • Page 21: 14" Basket-Lift Housing And Roller Guide Parts

    ELECTRIC FRYER - SERIES PRE-2000 14 BASKET LIFT HOUSING AND ROLLER GUIDE Splashback Roller Guide Bracket 4, 5 Push 8, 9 ITEM DESCRIPTION MOTOR AND WIRE COVER ----- HOUSING, S/S OR CRS ----- REAR COVER, S/S OR CRS ----- LEFT SIDE CRANK BAR & CAM (Viewing front of fryer) 016209 RIGHT SIDE CRANK BAR &...

  • Page 22: 34X24" Basket-Lift Housing, Roller Guide And

    18 - 34x24 BASKET-LIFT HOUSING, ROLLER GUIDE and TRANSFORMER BOX Roller Guide Bracket Splashback Push Rod Transformer Leg Channel ITEM DESCRIPTION HOUSING, S/S OR CRS ----- REAR COVER, S/S OR CRS ----- LINEAR ACTUATOR, 24VDC, WITH LIMIT SWITCHES 018471 ROLLER FOR LIFT ROD 015817 ROLLER PIN) 016393...

  • Page 23: Wiring Diagrams

    ELECTRIC FRYER - SERIES PRE-2000  WIRING DIAGRAMS NOTE: A separate wiring diagram has been included with this manual and should be saved for troubleshooting and maintaining the fryer. The wiring diagrams in this section cover standard fryers which may or may not match the diagram sent with the fryer.

  • Page 24: Ts Wiring Diagram

    14 TS 14 TS WITH WHIRL-O-SWIRL-A-WAY keatingofchicago.com...
  • Page 25 ELECTRIC FRYER - SERIES PRE-2000 18, 20 TS 18, 20 TS WITH WHIRL-O-SWIRL-A-WAY 1-800-KEATING...

  • Page 26: Basket-Lift Wiring Diagram

    14 TS WITH BASKET-LIFT 14 TS WITH BASKET-LIFT WITH WHIRL-O-SWIRL-A-WAY keatingofchicago.com...
  • Page 27 ELECTRIC FRYER - SERIES PRE-2000 24 TS WITH BASKET-LIFT 24 TS WITH BASKET-LIFT 1-800-KEATING...

  • Page 28: Fryer Specifications Bb Models

     KEATING FRYER SPECIFICATIONS BB FM-E MODELS: 10x11 BB FM-E 14 BB FM-E AMPS PER LINE - AMPS AMPS PER LINE - AMPS VOLTS THREE PHASE SINGLE VOLTS THREE PHASE SINGLE PHASE PHASE 11.7 13.1 15.5 • 3 ELEMENTS (2500W EACH) •...

  • Page 29: Ts Models

    ELECTRIC FRYER - SERIES PRE-2000 TS MODELS: 10x11 TS FM-E 14 TS FM-E AMPS PER LINE - AMPS AMPS PER LINE - AMPS VOLTS THREE PHASE SINGLE VOLTS THREE PHASE SINGLE PHASE PHASE 10.2 17.4 11.4 19.5 13.6 23.2 • 3 ELEMENTS (3800W EACH) •...

  • Page 32: Service Information
