Keating Of Chicago PRE-2000 Series Manual

Incredible frying machine
Hide thumbs Also See for PRE-2000 Series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Instructions, Manual
INCREDIBLE FRYING MACHINE™
GAS FRYER
SERIES PRE-2000
MANUAL
IMPORTANT:
THE USER'S MANUAL PROVIDES SPECIFIC OPERATING INSTRUCTIONS
FOR YOUR MODEL. USE THE INCREDIBLE FRYING MACHINE™ ONLY AS
INSTRUCTED IN THIS MANUAL.
KEEP A COPY OF YOUR BILL OF SALE.
The date on the bill establishes the warranty period should service be required.
If service is performed, it is in your interest to obtain and keep all receipts.
KEEP THIS MANUAL FOR TRAINING NEW PERSONNEL.
Record the Serial number and Model number of this Incredible Frying Machine™ in
the spaces provided. Keep these numbers for future reference.
Keating commercial fryers are not intended for household use.
As continuous product improvement occurs, specifi cations may be
changed without notice.
1-800-KEATING | keatingofchicago.com
SERIAL NUMBER
MODEL NUMBER
IFMpre2000_2013
10/13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRE-2000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Keating Of Chicago PRE-2000 Series

Summary of Contents for Keating Of Chicago PRE-2000 Series

  • Page 1 Record the Serial number and Model number of this Incredible Frying Machine™ in the spaces provided. Keep these numbers for future reference. SERIAL NUMBER MODEL NUMBER Keating commercial fryers are not intended for household use. As continuous product improvement occurs, specifi cations may be changed without notice. 1-800-KEATING | keatingofchicago.com...

  • Page 2: For Your Safety

    PURCHASER SHOULD POST IN A PROMINENT LOCATION INSTRUCTIONS TO BE FOLLOWED IN THE EVENT THE USER SMELLS GAS. THIS INFORMATION SHALL BE OBTAINED BY CON- SULTING THE LOCAL GAS SUPPLIER. WARNING Burns Shock Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death.

  • Page 3: Table Of Contents

    INTRODUCTION Instructions in this manual should be read thoroughly before attempting to operate this Keating Gas Fryer. All installation and service on Keating equipment must be performed by qualifi ed, certifi ed, licensed and/or authorized installation or service personnel. Operating information for Keating equipment has been prepared for use by qualifi ed and/or authorized personnel.

  • Page 4: Standard Features

    Keating’s Incredible Frying Machine® (IFM) is de- STANDARD ACCESSORIES signed to give maximum production effi ciency, deliver- • Keating Klenzer Sample ing high quality food products. The following design • Drain clean out rod features are incorporated in Keating’s Incredible Frying Machine®...
  • Page 5 INCREDIBLE FRYING MACHINE™ - SERIES PRE-2000 • Keating fryers are designed to operate on the • NEVER introduce objects or liquids into fryer, while gas fuel specified on the serial plate and must not operational, which are not designed or made for be operated with another gas fuel.

  • Page 6: First Steps

    Keating IFM is returned to LEVELING its originally installed position. The fryer will operate at its highest effi ciency when NOTICE: WHEN THIS APPLIANCE IS INSTALLED WITH properly leveled.

  • Page 7: Gas Connection

    Main Gas Connection NOTE: It is estimated that half of all service calls made on Keating Incredible Frying Machine® (IFM) result from an inadequate gas supply. During installa- tion, have a gas company representative make certain that the fryer is receiving adequate gas pressure and volume (see “Installation”...

  • Page 8: Lighting

    COOKING WATER IN ANY FORM AND HOT OIL DON'T MIX! Keating Incredible Frying Machine® Gas Fryers (IFM) are designed to provide maximum production effi ciency and deliver high quality food products. OIL EXPANDS WHEN HEATED. THE MAX LEVEL LINE...

  • Page 9: Shutdown

    CLEANING AND BOIL-OUT hot oil (if applicable). For fryers with automatic basket When cleaning and boiling out your fryer use Keating lift, a buzzer will sound and the basket(s) will rise Sea Powder and Keating Klenzer to keep your fryer automatically.

  • Page 10: Electronic Timers

    11. Spread Keating Klenzer liberally on tubes and PRESS all 3 buttons in sequence: left-center-right. The sides of fryer vessel. BEEPER will BEEP . If BEEPER does not BEEP , the timer is defective. STOP TESTING. Reset procedure is com- 12.

  • Page 11: Preventative Maintenance

    One screwdriver with 1/8" wide fl at blade repairs other than routine maintenance or cleaning, One accurate fryer thermometer you are required to contact Keating of Chicago (at 1-800-KEATING) before calling a local service com- 1. Set thermostat to desired frying temperature.

  • Page 12: Thermostat Bulb Positioning

    2. For 18" & 20" IFM Fryers: 5. Adjust bulb so at least 2" of bent portion of it is next to heat transfer tube and tighten compression • If the bulb is too loose, the paper will slip nut onto compression fi tting for fryer 18 & up. The through with little or no resistance.
  • Page 13 fl ame characteristics over the complete adjustment range of the air shutter. It can be used to more accurately determine the burner air/gas mixture to see if any adjustments are needed. Each burner should be checked independently of the other. 1-800-KEATING...

  • Page 14: Service Diagnosis

    The following diagnosis is only to be used as a guide to qualifi ed service personnel. Keating recommends that you use a qualifi ed & licensed service company. (Equipment still under warranty requires it.) Call 1-800-KEATING if you need assistance in locating a qualifi...
  • Page 15 Hi-Limit has been activated. a. Reset Hi-Limit after oil has cooled down below 425°F. Correct problem which caused Hi-Limit to activate. b. Electronic timer is faulty. b. Replace timer. c. Basket lift relay is faulty. c. Replace relay. 1-800-KEATING...

  • Page 16: Ordering Parts

     ORDERING PARTS Parts may be ordered by calling 1-800-KEATING or your local Keating service company. You may also order on-line at Keating’s part store, www.keatingofchicago.com Refer to the Keating Gas Fryer Limited Warranty for complete service and ordering information.
  • Page 17 INCREDIBLE FRYING MACHINE™ - SERIES PRE-2000 INCREDIBLE FRYING MACHINE® GAS FRYER ASSEMBLY (Corresponds with Parts List on Page 16) SPLASHBACK FLUE FLUE HI-LIMIT BURNER MOUNTING BRACKET CENTER TUBE DIVIDER CENTER TUBE COVER PLATE 1-800-KEATING...
  • Page 18 18" & 20" TUBING, BURNER GAS SUPPLY 022409 14" FLEXIBLE TUBING, BURNER AIR SUPPLY 022031 18" & 20" FLEXIBLE TUBING, BURNER AIR SUPPLY 1-800-KEATING HOSE CLAMP 015393 SPARK ELECTRODE WIRE 037462 FLEXIBLE MAIN TUBING ELBOW 054426 14" FLEXIBLE CONDUIT WITH FITTINGS 1-800-KEATING 18"...
  • Page 19 INDICATING LIGHT, BURNER ON (RED) 015121 INDICATING LIGHT, OVER MAX. TEMP. (RED) 015121 ROCKER SWITCH, LIGHTED, MAIN ON/OFF 015119 ROCKER SWITCH, HI-LIMIT TEST 015384 KEATING TIMER 023709 TIMING RELAY, INSTANT-ON™ 016189 RELAY, BASKET LIFT AND INSTANT-ON™ 008088 CONTROL PANEL, HOODED 1-800-KEATING 14"...
  • Page 20 IFM BURNER ASSEMBLY (Right side shown) Critical Dimensions for Proper Spark Ignitor Gap: 160° ± 2° 1.000 ±0.015 0.125 90° ORIFICE HOLDER BURNER ORIFICE ITEM MODEL DESCRIPTION 14" BURNER REPLACEMENT KIT 016506 18" & 20" BURNER (with ITEMS 5 & 6) 037859 SPARK ELECTRODE REPLACEMENT KIT NATURAL GAS...
  • Page 21 18" & 20" LEFT 025662 14" RIGHT 020607 18" & 20" RIGHT 025663 BLOWER BOX REAR COVER 1-800-KEATING BLOWER BOX COVER 1-800-KEATING BLOWER BOX BASE 1-800-KEATING 14" BLOWER BOX FRONT COVER 1-800-KEATING 18" & 20" BLOWER BOX FRONT COVER 1-800-KEATING 14"...

  • Page 22: Wiring Diagrams

     WIRING DIAGRAMS 14 IFM WOSA — 120V CONNECTION DIAGRAM — KEATING ELECTRONIC TIMERS keatingofchicago.com...
  • Page 23 INCREDIBLE FRYING MACHINE™ - SERIES PRE-2000 18 & 20 ifm — 120v CONNECTION DIAGRAM — KEATING ELECTRONIC TIMERS 1-800-KEATING...

  • Page 25: Service Information

     SERVICE INFORMATION: If you have a service related question call 1-800 -KEATING. Please state the nature of the call; it will ensure speaking with the appropriate person. Have your serial and model number available when ordering parts. As continuous product improvement occurs, specifi cations may be changed without notice.
