Backup battery replacement
The Recording box is equipped with a Real Time Clock supplied by a 3V lithium battery (CR 1632). The
battery can be exchanged if necessary.
Unscrew the four screws on the bottom of the
Recording box and remove the cover. Remove the
battery from mount carefully using a thin screw
driver. Replace it only with a 3 V lithium battery
CR 1632 or equivalent.
Figure 14: Open view for the localization of the RTC battery
