optris PI LightWeight Kit Operator's Manual

Miniature lightweight pc with ir camera for flight applications
Hide thumbs Also See for PI LightWeight Kit:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operator's Manual
®
optris
PI LightWeight Kit
¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯
Miniature lightweight PC with IR camera for flight applications
Operators manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PI LightWeight Kit and is the answer not in the manual?

Questions and answers

Related Manuals for optris PI LightWeight Kit

Summary of Contents for optris PI LightWeight Kit

  • Page 1 ® optris PI LightWeight Kit ¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯ Miniature lightweight PC with IR camera for flight applications Operators manual...
  • Page 3 The freight costs will be paid by the sender. The manufacturer reserves the right to exchange components of the product instead of repairing it. If the failure results from misuse or neglect the user has to pay for the repair. In that case you may ask for a cost estimate beforehand. optris PI LightWeight Kit – E2013-04-B...

  • Page 4: Table Of Contents

    Installation Emissivity Dimensions PI 400 LW/ PI 450 LW Dimensions PI NetBox LW Controls and Connections Operation Stand-alone Operation Start a Recording SD Card Status LEDs Switch Positions Operation Modes of the NetBox LW optris PI LightWeight Kit – E2013-04-B...

  • Page 5: Description

    Thank you for choosing the optris PI LightWeight Kit! The optris PI LightWeight Kit consists of a miniaturized lightweight PC (PI NetBox LW) and a weight- optimized optris PI400 LW or PI450 LW infrared camera. With 380 g the system is ideally suited for radiometric infrared recordings from the air like for maintenance work and quality inspections of solar and wind power systems and for building thermography.

  • Page 6: Important Notes

    Important Notes  The optris PI is a precise instrument and contains a sensitive infrared detector and a high- quality lens. The alignment of the camera to intensive energy sources (high power laser or reflections of such equipment, e.g.) can have effect on the accuracy of the measurement or can cause an irreparable defect of the infrared detector.

  • Page 7: Technical Data Netbox Lw

    2 GB SSD 512 MB (DDR2, 533 MHz) Ports 3x USB 2.0 1x Mini-USB 2.0 (slave mode) VGA/ TV Ethernet (Gigabit Ethernet) Extensions microSDHC card (up to 32 GB) Additional functions 6x Status LEDs (L1-L6) optris PI LightWeight Kit – E2013-04-B...

  • Page 8: Technical Data Pi 400 Lw/ Pi 450 Lw

    -20...100 °C; 0...250 °C; 120...900 °C Detector UFPA, 382 x 288 pixels Spectral range 7.5...13 µm Lenses (FOV) 38° x 29°; 62° x 49° System accuracy ±2 °C or ±2 % At ambient temperature 235 °C; whichever is greater optris PI LightWeight Kit – E2013-04-B...

  • Page 9: Optical Specifications

    (please see table at the end of this section). Note Please make sure that the focus of the infrared camera is adjusted correctly. For focusing please turn the lens. Value is valid at 40 Hz and 25°C room temperature optris PI LightWeight Kit – E2013-04-B...
  • Page 10 PI LightWeight Kit – E2013-04-B...

  • Page 11: Installation

    The separate PI camera sensing head can be mounted on the stabilization platform of a drone together with a visual camera (in the picture: GoPro camera). The NetBox PC can be mounted separate. Installation PI LightWeight on a drone together with GoPro HD camera optris PI LightWeight Kit – E2013-04-B...
  • Page 12 For a mobile use you can arrange all components of the system also inside the camera case as shown in the below picture. Single foam parts of the case can be easily removed for that purpose. Arrangement of the PI LightWeight kit inside the camera case optris PI LightWeight Kit – E2013-04-B...

  • Page 13: Dimensions Pi 400 Lw/ Pi 450 Lw

    Dimensions PI 400 LW/ PI 450 LW optris PI LightWeight Kit – E2013-04-B...

  • Page 14: Dimensions Pi Netbox Lw

    Dimensions PI NetBox LW optris PI LightWeight Kit – E2013-04-B...

  • Page 15: Controls And Connections

    Controls and Connections Cooling fan USB 2.0 socket Video socket Ethernet socket USB 2.0 socket Mode switch (S1/ S2) Power supply socket Mini USB socket (slave mode) Status-LEDs (L1-L6) microSDHC card slot optris PI LightWeight Kit – E2013-04-B...

  • Page 16: Operation

    As a stand-alone PC the NetBox LW expands the IR cameras PI400 LW and PI450 LW to a system for radiometric infrared video recording. For a self-contained power supply we recommend a lithium-polymer battery with a voltage between 8 and 14 VDC. Recommended video system integration of the PI LightWeight optris PI LightWeight Kit – E2013-04-B...

  • Page 17: Start A Recording

    At the backside of the IR camera you will find a red sliding switch. To start a recording please move the switch into the right position. If you move the switch back into the left position the recording will be stopped. optris PI LightWeight Kit – E2013-04-B...

  • Page 18: Sd Card

    Please take care when you insert a card that it is placed correctly into the according guide slot. Status LEDs The NetBox LW is equipped with 6 status LEDs (L1-L6). optris PI LightWeight Kit – E2013-04-B...

  • Page 19: Switch Positions

    For powering the NetBox you can use instead of a lithium-polymer battery also the supplied power adapter. Alternatively the NetBox can also be powered via the Ethernet cable (PoE – Power over Ethernet). For this purpose a PoE injector is needed [part#: ACPIPOE]. optris PI LightWeight Kit – E2013-04-B...

  • Page 20: Remote Access To The Netbox Lw

    For remote access from outside to a NetBox LW connected to a company network please ask your system administrator for possibly necessary settings. optris PI LightWeight Kit – E2013-04-B...
  • Page 21 With the UltraVNC Viewer it is possible to have simultaneous access to one NetBox from different PCs inside a network. DHCP – Dynamic Host Configuration Protocol: allows the automatic integration of a computer into an existing network. optris PI LightWeight Kit – E2013-04-B...
  • Page 22 In this case you have to change the time zone settings on the NetBox. ► System time The short cut NetBox Maintain is synchronizing the time automatically with a directly connected NetBox and is starting then automatically the UltraVNC viewer. optris PI LightWeight Kit – E2013-04-B...

  • Page 23: Applications And Start Options

    NetBox: no automatic program start Imager Net Server automatic start of the server application PI Connect automatic start of the PI Connect User defined user defined start of one of the both programs above optris PI LightWeight Kit – E2013-04-B...
  • Page 24 [Args] please select User defined. Example The following configuration starts the PIConnect in the full screen mode: The start options selected in the configuration dialog are saved automatically in the NetBox and are available after a restart. optris PI LightWeight Kit – E2013-04-B...
  • Page 25 Screen of the NetBox LW – Imager Net Server Screen of the NetBox LW – PI Connect If an imager is connected to the NetBox you should see two active applications: Monitor Imager Net Server and Imager Net Server or PI Connect. optris PI LightWeight Kit – E2013-04-B...
  • Page 26 D: Device/ P: Processing/ N: Network Time Time per single frame Queue Number of frames in network queue FOV, TR Field of view (horizontal) of the imager lens, Temperature range Information in the Imager Net Server – application window optris PI LightWeight Kit – E2013-04-B...

  • Page 27: Watchdog

    NetBox and also the elapsed time of the operation period before the last restart. The number of restarts can be reset (right mouse button on WD symbol – Reset counter). Please note that all restarts (also not by the Watchdog initialized ones) will be counted here. optris PI LightWeight Kit – E2013-04-B...

  • Page 28: Autostart

    Write protection filter MouseHider hides the mouse pointer after 10s of inactivity Watchdog starts the Watchdog application Application Start Manager starts the program which was selected in Application Start Config optris PI LightWeight Kit – E2013-04-B...

  • Page 29: File Transfer Between Netbox Lw And Pc

    In the following explorer window you see on the left side your local PC (LOCAL MACHINE) and on the right side the NetBox (REMOTE MACHINE). Now you can copy files between both computers via the network link by marking them and pressing Send or Receive. optris PI LightWeight Kit – E2013-04-B...

  • Page 30: Ethernet Direct Communication

    If you use a PoE injector the power supply for the NetBox is not needed. In this case please connect the PoE injector as shown in the drawing below. At proper functioning now L1, L2 and L5 should light up. The used Ethernet cables should be at least category 5 cables (Cat-5 according ISO/IEC 11801). optris PI LightWeight Kit – E2013-04-B...
  • Page 31 DHCP server is available here. The NetBox is using in this case the IP address 192.168.0.100. On your PC you have to do the following settings once (depending on the operating system the procedure can differ from the here shown – the following description refers to a Windows 7 system). optris PI LightWeight Kit – E2013-04-B...
  • Page 32 3. Go to Local Area Connection – a status screen according [1] will be shown. Then go to Properties. 4. In the following window [2] mark Internet protocol Version 4 (TCP/IPv4) and go again to Properties. optris PI LightWeight Kit – E2013-04-B...
  • Page 33 IP address of the NetBox, thus 192.168.0. For the host part you have to use an address which is different from the one of the NetBox (100), so you may use 1 for example. optris PI LightWeight Kit – E2013-04-B...
  • Page 34 In the window which is appearing you should set a hook on Enable and enter the IP address of the NetBox (192.168.0.100). Press OK. The software will establish a connection to the remote device (imager) automatically. optris PI LightWeight Kit – E2013-04-B...
  • Page 35 Connect manual connection with the remote device Restart restart of the Imager Net Server application on the NetBox Reboot reboot of the NetBox Remove remove of the device entry in this menu optris PI LightWeight Kit – E2013-04-B...
  • Page 36 Now you should see the live picture from the imager on your PC. Alternatively you can copy the calibration data also manually via an USB stick into the NetBox folder D:\Imager\Cali. optris PI LightWeight Kit – E2013-04-B...

  • Page 37: Ethernet Network Communication

    If you use a PoE injector the power supply for the NetBox is not needed. In this case please connect the PoE injector as shown in the drawing below. At proper functioning now L1, L2 and L5 should light up. optris PI LightWeight Kit – E2013-04-B...
  • Page 38 Detect devices. The fourth block should have the range 0 to 255. If you now press Ping all computers inside the selected address range will be shown. Under Remote framerate you can enter the desired frame rate which should be transmitted via the network. optris PI LightWeight Kit – E2013-04-B...
  • Page 39 NetBox shows up now. The following functions can be selected here: Connect manual connection with the remote device Restart restart of the Imager Net Server application on the NetBox Reboot reboot of the NetBox Remove remove of the device entry in this menu optris PI LightWeight Kit – E2013-04-B...
  • Page 40 Now you should see the live picture from the imager on your PC. Alternatively you can copy the calibration data also manually via an USB stick into the NetBox folder D:\Imager\Cali. optris PI LightWeight Kit – E2013-04-B...
  • Page 41 NetBox with the recommended standard components. If you connect other USB devices which need a specific driver installation it might be necessary to start the installation process manually in the device manager. optris PI LightWeight Kit – E2013-04-B...

  • Page 42: System Time

    ► Remote Access to the NetBox You can change the set time zone in the tab Time Zone. To save the new setting permanently you have to deactivate the ► Write Protection Filter temporarily. optris PI LightWeight Kit – E2013-04-B...

  • Page 43: Write Protection Filter

    The colors have the following meaning: red dot: safe mode green dot: write mode The NetBox should be used only with an activated write protection filter [red dot]. Write protection filter as short cut in folder Autostart optris PI LightWeight Kit – E2013-04-B...
  • Page 44 The SSD drive of the NetBox has by factory default two partitions. The write protection refers to partition C only. On the partition D you can save application data. On drive D also the calibration data of the infrared imager are stored. optris PI LightWeight Kit – E2013-04-B...

  • Page 45: System Recovery

    Please connect a VGA monitor and a USB keyboard with the NetBox. Connect the USB recovery stick to a free USB port and switch on the NetBox. If you see the following start screen please press the ESC button for at least 2 seconds (keep pressed). Start screen of the NetBox LW optris PI LightWeight Kit – E2013-04-B...
  • Page 46 Now you should see the following screen – select USB device and then press Enter. The next screen shows the available USB stick. Please confirm with Enter. Confirm with Enter Screens during system recovery optris PI LightWeight Kit – E2013-04-B...
  • Page 47 In the next window you can rename the NetBox (optional). Please note that the new name should have at maximum 15 characters. Press two times Next. Now the system will be shut down again. Your NetBox is now ready for use again. optris PI LightWeight Kit – E2013-04-B...
  • Page 48 Rename the NetBox (optional) optris PI LightWeight Kit – E2013-04-B...

  • Page 49: Basics Of Infrared Thermometry

    The temperature rose even more in the area behind the red end of the spectrum. Finally he found the maximum temperature far behind the red area. Nowadays this area is called “infrared wavelength area”. optris PI LightWeight Kit – E2013-04-B...
  • Page 50 Distance to Spot size. The spectral filter selects the wavelength range, which is relevant for the temperature measurement. The detector in cooperation with the processing electronics transforms the emitted infrared radiation into electrical signals. optris PI LightWeight Kit – E2013-04-B...
  • Page 51 Application examples: Monitoring of Process control extruding R&D of electronics R&D of electronic parts electronic cabinets plastic parts Process control at Monitoring of cables R&D of mechanical parts Process control manufacturing calendering solar modules optris PI LightWeight Kit – E2013-04-B...

  • Page 52: Emissivity

    Capability of an object to emit radiation Spectral emissivity of some materials 1 Enamel, 2 Plaster, 3 Concrete, 4 Chamotte optris PI LightWeight Kit – E2013-04-B...
