2.1.2 Electrical specifications
Power supply:
10 to 48 VDC
Power consumption:
12 W
Cooling:
active via integrated temperature controlled fan
Module:
ODROID-XU4
Processor:
Samsung Exynos5422 (Cortex™ A15 2GHz and Cortex™ A7) Octa core
Memory:
8 GB eMMC flash storage/ 16 GB Micro-SDHC card (not intended to be exchanged by user)
RAM:
2 GB LPDDR3 RAM
Ports:
2 x USB 3.0; 1 x USB 2.0; 1 x Mini-USB for a GoPro Hero 3+ and higher; RJ45 Ethernet (Gigabit Ethernet)
HDMI 1.4a or Mini jack 2.5 mm Video composite (CVBS) NTSC TV
2 x 4-screw terminal
Additional functions
5 x Status-LED; Function button
; 2 x Servo-connector (Uni, Graupner /JR);
out
