Specifications - Extech Instruments MO260 User Manual

Specifications

Display
Resolution
Accuracy
Measurement principle
Range
Electrode pin length
Electrode pin type
Power supply
Low Battery Indication
Meter housing
Operating Temperature
Operating Humidity
Dimensions
Weight
Copyright © 2014-2016 FLIRSystems, Inc.
All rights reserved including the right of reproduction in whole or in part in any form
Backlit LCD digital display and tri-color LED bargraph scale
0.1%
Pin mode: ± (5% rdg + 5 digits)
Pinless mode is a relative reading only
Electrical resistance (pins)
Electromagnetic sensor (pinless)
0.0 to 99.9 %Relative (pinless)
6.0 to 94.8 %WME (pins)
11mm (0.44")
Integrated, replaceable
9V alkaline battery
Battery symbol displayed on LCD
Impact-proof plastic
o o
0 to 50 C (32 to 122 F)
80% Relative Humidity maximum
203 x 58 x 43mm (8 x 2.3 x 1.7")
204g (7.2 oz)
ISO-9001 Certified
www.extech.com
8 MO260-en-GB_V1.5 8/16
