LCD Backlight ON/OFF
With the meter switched ON, pressing and holding both front panel buttons (MODE and HOLD)
switches the LCD backlight ON and OFF.
Data Hold feature
The Data Hold function freezes the reading in the display. Press the HOLD key momentarily to
activate the Data Hold function. The reading will freeze and the 'key' display icon will appear. Press
the HOLD key again to exit the Data Hold function (the 'key' display icon will switch off).

Meter Setup

To enter the setup mode:

With the meter switched OFF, press and hold both front panel buttons (MODE and HOLD
buttons) simultaneously for two seconds. The display should now read '0 = x' where '0' is the
OPTION and 'x' is the SETTING.
Use the MODE (right arrow) button to change the SETTING.

Use the HOLD button to scroll through the OPTIONS.

The available OPTIONS and SETTINGS:

OPTIONS SETTINGS
0 0
1
1 0
1
2
3
2 0
1
2
3
3 0
1
*FACTORY DEFAULT SETTINGS: 0=0, 1=0, 2=0, 3=0
SET-UP INFORMATION
Switches all settings to '0' (Factory Default*)
Others settings can now be changed. In addition, Backlight
switches ON for 30 seconds and then automatically switches
OFF.
Audible alert beeps with increasing frequency from a nominal
17.0 (REL) or 17% (WME) measurement value upwards
Audible alert divided into 3 frequency levels
Audible alert beeps when user switches from one mode to
another
Beeper OFF. Audio alert display symbol switches OFF
Auto Switch OFF is not active. User must manually switch the
unit OFF
Auto Switch OFF active. Switches OFF after 3 minutes
Auto Switch OFF active. Switches OFF after 5 minutes
Auto Switch OFF active. Switches OFF after 10 minutes
Backlight OFF
Backlight ON
