DESCRIPTION OF RECEIVER / COLLAR PARTS
Receiver Battery Charging Receptacle & Rubber
Plug
On the inside of the collar receiver, next to the collar
strap, is a battery-charging receptacle with a rubber
plug.
Internal Antenna
All Dogtra E-collars have non-exposed antennas
that are located inside the receiver/collar.
56

BATTERY CHARGER

Charging Cable
Two-dog unit only
The battery charger and charging cables allow you
to charge both the transmitter and receiver at the
same time. The battery charger is designed for a
220-volt wall outlet (U.S.A. 110-volt AC chargers
and 12-volt field charger for your automobile are
also available.) .
To use the battery charger for the two-dog unit,
combine both sets of battery charging (splitter)
cables as shown. This enables you to charge the
transmitter and both receivers at the same time.
BATTERY CHARGER
220 volt
Charger
Wall Outlet
57
