Ambirad SmartCom 3 Owner's Manual page 21

ENGINEERS SETTINGS FOR
WARM AIR PRODUCTS
DF & I DF
OFF
Turn 'ON' to put the controller into a DF & IDF
configuration.
VENT 3 FUNCT I ON
FAN
Toggle between 'FAN' for warm air and
'DAMPER' for heat/cooling systems.
MOVE TO TOP OF NEXT PAGE
21
SET/OK
I NTERNAL SENSOR
ON
Turn 'ON' for in-built internal sensor.
EXTERNAL SENSOR
OFF
Turn 'ON' for optional External Black Bulb or
Air sensor.
NETWORKING
OFF
Turn 'ON' for Master and slave configuration.
Up to 16 zones can be networked.
MASTER UN I T
OFF
(If Networking is on)
Turn 'ON' for Master control panel.
SLAVE NUMBER
0
SLAVE UNITS ONLY:
Set figure for unique zone number. Max 16.
ZONE TOTAL
0
MASTER UNIT ONLY:
Set figure for total number of ZONES.
SLAVE RESPOND
ON
SLAVE UNITS ONLY: Slave responds to
remote off command from Master control.
SET/OK
21
ENGINEERS SETTINGS FOR
RADIANT PRODUCTS
ARC HEATERS
OFF
Turn 'ON' for ARC configuration.
RAD/ARC/HB SPL I T
OFF
Turn 'ON' split zone/single fan configuration
under network conditions.
SET/OK
SET/OK
SET/OK
SET/OK
SET/OK
SET/OK
SET/OK
EXAM MODE
OFF
Turn 'ON' for 2 stage temperature in sports
halls (ie sports/exam modes.)
SET/OK
SET/OK
SET/OK
