3.6 Setting the Mode
Press the SETTING button till
SET MODE? appears in the display.
SET AUTO MODE?
OK =yes SET =next
Press SET to advance
to the next mode to
choose. Press OK to accept
new mode.
Auto mode: Heating and
v e n t i l a t i o n
o p e r a t e
automatically depending on
the room temperature, time/
set
temperature
program
and
the
control
method
selected.
Ventilation
disabled during off periods
of the time program.
Frost Only mode: Heating
operates
automatically
depending
on
the
room
temperature
and
control
method selected. The set
temperature is fixed at 41°F.
Ventilation is disabled.
Fan Only mode: Ventilation
operates
automatically
depending
on
the
room
t e m p e r a t u r e ,
t i m e / s e t
temperature program and
the control method selected.
H e a ti n g
i s
d i s a b l e d .
Ventilation is disabled during
off
periods
of
the
time
program.
Th 09 : 30
HEAT
Use the SET button to advance to the
next display.
Press the OK button to accept the value
and advance to the next display.
SET MODE?
OK =yes SET =next
press
press
SET EXAM MODE?
OK =yes SET =next
SET FROST ONLY?
OK =yes SET =next
is
SET HEAT ONLY?
OK =yes SET =next
SET FAN ONLY?
OK =yes SET =next
Menu End
OK =yes SET =redo
press
ON
Press the OK button to change this user
mode.
or
SET TEMPS?
OK =yes SET =next
follow 'Setting the MODE' menu
or
SET AUTO MODE?
OK =yes SET =next
repeat procedure above
Press the UNDO button to cancel setting
but save any previous changes.
12
Exam Heating mode:
If the control is used
on a system installed in a
sports
hall, a temporary
increase in temperature can
be set to improve comfort for
people sitting in the building.
Heating will be controlled to
"temperature
2".
Exam
Heating mode can only be
set during an ON period and
will last only until the next
OFF period unless cancelled
by the UNDO button.
Heat Only mode: Heating
operates
automatically
depending
on
the
room
t e m p e r a t u r e ,
t i m e / s e t
temperature program and
the control method selected.
Ventilation is disabled.
Pressing SET at 'Menu
End' will scroll round
back
to
the
first
mode
setting.
