Pearl-2 User Guide
Value
Contrast
Vertical shift
Horizontal shift
Saturation
Sharpness
Powerline
frequency
Timeout
Audio input gain
Audio delay
Description
The contrast of the video can be adjusted by entering a numerical value from 0 to
100. Estimate values and view the result in the preview area until desired result is
achieved.
The vertical positioning of the video can be adjusted by entering a numerical
value from -64 to 64. Estimate values and view the result in the preview area until
desired result is achieved.
The horizontal positioning of the video can be adjusted by entering a numerical
value from -64 to 64. Estimate values and view the result in the preview area until
desired result is achieved.
The saturation of the video can be adjusted by entering a numerical value from 0
to 100. Estimate values and view the result in the preview area until desired result
is achieved.
The sharpness of the video can be adjusted by entering a numerical value from 0
to 100. Estimate values and view the result in the preview area until desired result
is achieved.
The powerline frequency of the video can be adjusted by selecting the desired
output from a drop-down list of frequencies available to your source.
This menu allows you to choose a custom no-signal image for the channel. The
drop-down list gives you the option to choose the default image or any image
you have uploaded through the
The timeout represents the number of seconds after losing the signal that the no-
signal is displayed. You may change this number to adjust how soon you wish the
no-signal image to appear after the signal disappears.
You can add audio gain to your source from this page by selecting the % gain
from the drop-down list. Estimate values and check the result in the preview area
until desired result is achieved.
If your audio is not synchronized with your video, it can be adjusted from -300 to
300 ms. Estimate values and check the result in the preview area until desired
result is achieved.
USB signals
Add a No Signal image to a source
257
