Pearl-2 User Guide
NTP uses UDP packets and port 123. If the system is behind a firewall and accessing an
external NTP server, UDP packets must be permitted on port 123.
7. If RDATE is selected:
a. Enter the IP address or server name for the RDATE server in the Server IP Address field.
b. Select an update interval from the drop down box.
8. If PTP v1 is selected:
a. Select the multicast address of PTP v1 server from the PTP domain drop-down.
PTP Domain
Default
Alternative 1
Alternative 2
Alternative 3
PTP uses UDP packets and ports 319 and 320 . If the system is behind a firewall and
accessing an external PTP server, UDP packets must be permitted on ports 319 and 320.
9. Click Apply.

Configure the date and time manually

By default Pearl-2 uses NTP for time synchronization. If your system does not have access to a time
synchronization server, or if you do not wish to use one, you can choose to manually set the date and time.
To manually set the date and time:
1. Login to the Admin panel as admin. See
2. Select the Date and Time link in the Configuration menu; the date and time configuration page
opens.
3. Type the desired date in the Date field. Use the format yyyy-mm-dd.
4. Type the desired time in the Time field. Use the format hh:mm:ss.
5. Click Apply.
Configure the date and time manually
Description
PTP at multicast address 224.0.1.129
PTP at multicast address 224.0.1.130
PTP at multicast address 224.0.1.131
PTP at multicast address 224.0.1.132
Connect to the Admin panel.
151
