DESCRIPTION OF THE VACUUM

1
3
4
1
Ergonomic Handle
2
On/Off Power Switch
3
Bag Compartment
4
Vacuum Nozzle
5
Headlight
6
Furniture Guard
7
Handle Release Pedal
8
Battery Pack
9
Charge Point
10
Battery Life Display
11
Battery Release Button
12
Carry Handle
13
Charger
2
5
6
4
10
7
