Samples of Cables for Connection

• For more details of connection and cables, refer to the operation manual of the connecting equipment.
• You may need other cables or connectors not listed below.
Equipment
Audio-visual
equipment
Camera/video game
Computer
Downloaded From projector-manual.com Sharp Manuals
Input signal
HDMI video HDMI cable (commercially available)
Component Component cable (commercially available)
video
3 RCA to 15-pin D-sub cable (sold separately: AN-C3CP2)
DVI to 15-pin D-sub adaptor (sold separately: AN-A1DV)
3 RCA to 15-pin D-sub cable DVI to 15-pin D-sub adaptor
Terminal for Dedicated cable attached to the connected equipment COMPONENT/
using the
dedicated
cable
RGB video 5 RCA RGB cable (commercially available)
S-video S-video cable (commercially available)
Terminal for Dedicated cable attached to the connected equipment
using the
dedicated
cable
Video Video cable (commercially available)
Terminal for Dedicated cable attached to the connected equipment
using the
dedicated
cable
RGB video DVI to D-sub cable (supplied accessory)
DVI cable (sold separately: AN-C3DV)
Cable
Terminal on the
projector
HDMI1, 2
COMPONENT/
RGB1, 2
DVI
RGB1, 2
COMPONENT/
RGB1, 2
S-VIDEO
VIDEO
DVI
