6.5. Parameter Group 0 – Monitoring Parameters (Read Only)
Par. Description
P0-01 Bipolar analog input value
P0-02 2nd Analog input value
P0-03 Speed controller reference
P0-04 Digital speed reference
P0-05 Reserved
P0-06 PID Reference
P0-07 PID Feedback
P0-08 PID error
P0-09 PID P Term
P0-10 PID I term
P0-11 PID D term
P0-12 PID Output
P0-13 Motor Voltage
P0-14 Magnetising current
P0-15 Reserved
P0-16 Field Strength
P0-17 Stator resistance
P0-18 Reserved
P0-19 Reserved
P0-20 DC Bus Voltage
P0-21 Drive Temperature
P0-22 Supply voltage L1 – L2
P0-23 Supply voltage L2 – L3
P0-24 Supply voltage L3 – L1
P0-25 Reserved
P0-26 kWh meter
P0-27 MWh meter
P0-28 Software ID – IO Processor
P0-29 Software ID – Motor Control
P0-30 Drive serial number

6.6. Fire Mode

Optidrive VTC has an integrated 'Fire Mode' function, designed to ensure that the Optidrive can continue to operate without interruption in the
event of a fire. Fire mode disables non-critical trip functions of the Optidrive, so that the Optidrive will continue to operate until either the drive
itself, the motor or the cabling is destroyed by the fire.
Since normal operation of the Optidrive is overridden when fire mode is active, it is possible that damage to the ventilation system may result from
over-pressure. It is also possible that the Optidrive may itself fail or cause damage to the motor.
Invertek Drives Ltd accepts no liability for damage to the Optidrive VTC itself, other components or equipment, HVAC installations, property or
injury to personnel when operated in Fire mode.
In no event shall Invertek Drives Ltd be liable to any party for loss or damage, whether direct or indirect as a result of operating the drive in Fire
Mode.
Optidrive VTC – User Guide
Display range Units
-100.0 to 100.0 %
0.0 to 100.0 %
-500.0 to 500.0 %
-P1-01 to P1-01 Hz / Rpm
0.0 to 100.0 %
0.0 to 100.0 %
0.0 to 100.0 %
0.0 to 100.0 %
0.0 to 100.0 %
0.0 to 100.0 %
0.0 to 100.0 %
Rating Dependent V
Drive dependent A
0.0 to 100.0 %
Drive dependent Ohms
0 to 1000 Volts
0 to 120 ºC
Drive dependent Volts
Drive dependent Volts
Drive dependent Volts
0 to 999.9 kWh
0 to 60,000 MWh
Drive dependent -
Drive dependent -
Drive dependent -
www.invertek.co.uk
Explanation
100% = max input voltage
100% = max input voltage
100% = P1-09
Digital speed reference
PID reference / setpoint
PID controller feedback value
Actual PID error
Proportional component
Integral component
Differential component
Output from PID controller
Output Voltage
Motor rms magnetising current
Magnetic field strength
Phase to phase stator resistance
Internal DC Bus voltage
Measured heatsink temperature
Phase to phase supply voltage
Phase to phase supply voltage
Phase to phase supply voltage
Cumulative energy consumption
Cumulative energy consumption
Version number & checksum
Version number & checksum
Unique drive serial number
