User Manual
CAN-8123/ CAN-8223/CAN-8423
CANopen Slave Device
Quick Start User Guide
Introduction
This
user
guide
introduces
the
user
how
to
implement
the
CAN-8123/CAN-8223/CAN-8423 into their applications in a quick and easy
way. Therefore, it only provides the basic instructions. For more detail
information about the CAN-8123/CAN-8223/CAN-8423, please refer to the
CAN-8123/CAN-8223/CAN-8423 user manual in the product CD or download
it from following web site:
http://www.icpdas.com/products/Remote_IO/can_bus/can-8123.htm
or
http://www.icpdas.com/products/Remote_IO/can_bus/can-8423.htm
CAN-8123/CAN-8223 Hardware Structure
CAN-8423 Hardware Structure
CAN-8123/CAN-8223/CAN-8423 Quick Start User Guide (Version 2.0 July/2007) --------- 1
