Appostar KP-5362 User Manual

Touch pos terminal
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

http://www.appostar.com
KP-5362
Touch POS Terminal
User's Manual
Edtion: NOV 2012
version 1.02


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KP-5362 and is the answer not in the manual?

Questions and answers

Related Manuals for Appostar KP-5362

Summary of Contents for Appostar KP-5362

  • Page 1   http://www.appostar.com KP-5362 Touch POS Terminal User’s Manual Edtion: NOV 2012 version 1.02  ...

  • Page 2: Declaration Of Conformity

    For more information about where to send your waste equipment for recycling, please contact your local city office, your household waste disposal service or where you purchased the product. KP-5362 Fanless POS Terminal  II ...
  • Page 3 The material in this document is for information purpose and is subject to change without prior notice. APPOSTAR has made every effort to ensure that this user’s manual is accurate and complete. However, no liability is assumed for any errors and omissions that may have occurred.

  • Page 4: Important Safety Instructions

    6. Do not place heavy objects on top of the product /or lean against the product, these items may fall and cause injury. 7. Do not block the air vent of the product, this can cause heat to build up inside the box machine and may lead to fire. KP-5362 Fanless POS Terminal  IV ...

  • Page 5: Table Of Contents

      Table Of Contents Chapter 1 Product Overview ............. 2  1.1 Unpacking ..................2   1.2 Appearance ..................3   1.3 I/O Interface ..................5   1.4 Specification ..................7   Chapter 2 Hardware Installation ............9  2.1 Peripheral Installation ................ 9  ...

  • Page 6: Chapter 1 Product Overview

    Check list 1. POS Te erminal M Main Unit 2. Quick k Referenc ce Guide 3. Driver C 4. Po ower Ada pter Power Co KP-5362 Fa anless POS Terminal 2 ...

  • Page 7: Appearance

    PRODUCT OVERVIEW 1.2 Appearance Front View 15” LCD touch  panel  Front panel  Base  Rear View Customer display cover MSR cover MSR cover  Rear cover  Cable management cover KP-5362 Fanless POS Terminal 3 ...

  • Page 8: Side View

    PRODUCT OVERVIEW Side View Left Side Right Side (I/O without cover) (I/O with cover) KP-5362 Fanless POS Terminal  4 ...

  • Page 9: I/O Interface

    PRODUCT OVERVIEW 1.3 I/O Interface KP-5362 Fanless POS Terminal 5 ...
  • Page 10 Off – System is powered off. Reset Button Press to restart your system. Press the Power Button to turn the POS system Power Button ON/OFF. The Power LED Indicator will display the current power status of the POS system. KP-5362 Fanless POS Terminal  6 ...

  • Page 11: Specification

    Finger Print 512dpi x 8bit gray scale, Capture area: 14.6 x 18.1 i-button Dallas Key Wireless LAN 802.11 b/g Customer Display VFD/LCD customer display Second Display TFT-LCD display/non-touch Control / Indicator Power Button 1 Reset Button 1 KP-5362 Fanless POS Terminal 7 ...
  • Page 12 Operating Humidity 15%~80% RH Storage Humidity 20% ~90% RH Mechanical Housing Color Cool White, Dark Gray Construction ABS + SECC Dimension (W x D x H) 390 x 235 x 320 mm Weight N.W. 8.5 kg KP-5362 Fanless POS Terminal  8 ...

  • Page 13: Peripheral Installation

    MSR exten nsion slot. Step p 2 Connect t the MSR c cable correc ctly. Step 3 Fix the M MSR modu le in positio on with 2 screw KP-5362 Fa anless POS S Terminal...
  • Page 14 Figure 2-a Step 2 U Unfasten 2 2 thumb s screws of ff the rear r cover by y a coin. (Figure 2 2-b, 2-c) Figure 2-b gure 2-c KP-5362 Fa anless POS Terminal 10 ...

  • Page 15: Chapter 2 Hardware Installation

    Figure 2-g Step 4 Cover the screw holes with plastic lids and reinstall the rear cover. (Figure 2-h, 2-i) Figure 2-h Figure 2-i ATTENTION If the customer display doesn’t work properly, please refer to CH.6 Troubleshooting. KP-5362 Fanless POS Terminal 11 ...

  • Page 16: Second Display Installation

    Unfasten the 2 thumb screws off both the front and rear cover of the main unit. (Figure 3-b, 3-c) Figure 3-b Figure 3-c Step 3 Remove the top hinge cover using a screwdriver. (Figure 3-d, 3-e) Figure 3-d Figure 3-e KP-5362 Fanless POS Terminal  12 ...
  • Page 17 Step 6 Fi t the lowe er hinge c cover to th he second d display a and fix wi ith 1 thum mb screw. Figure 3-i , 3-j)   Figure 3-i gure 3-j KP-5362 Fa anless POS S Terminal...
  • Page 18 Figure 3-l , 3-m) Figure 3-l gure 3-m ATTENT TION If the se cond disp play does n’t work properly, please re efer to CH Trouble eshooting KP-5362 Fa anless POS Terminal 14 ...

  • Page 19: Component Installation

    HDD bracket in place. (Figure 4-c, 4-d) Figure 4-c Figure 4-d Step 4 Unfasten 4 screws from the HDD bracket to remove the HDD and replace with a new one. KP-5362 Fanless POS Terminal 15 ...
  • Page 20 Step 1 Unfasten 2 thumb screws off the rear cover by a coin. (Figure 5-a, 5-b) Figure 5-a Figure 5-b Step 2 Locate the Mini PCI Express Card Slot on the mother board. (Figure 5-d) Plug the Mini PCI Express card into the slot. Figure 5-c Figure 5-d KP-5362 Fanless POS Terminal  16 ...

  • Page 21: Chapter 3 Software Installation

    Microsoft Windows platforms. Insert the driver CD into your CD-ROM drive. Windows will automatically detect it and the Appostar Driver Installer appears on the screen. If not, locate the Setup.exe file at CD:\ and double-click it to execute the one-step driver installation.
  • Page 22 No to continue. g. Select “Install this driver software h. Select “Install” in Windows anyway” in Windows Security window Security window to continue the to continue the installation procedure. installation procedure. i. Select “Yes” to reboot system. KP-5362 Fanless POS Terminal  18 ...

  • Page 23: Peripheral Device Driver Installation

    Select the “Install RS232 interface driver” option. Click Next to driver” option. Click Next to continue. continue. e. Select the None option and click f. Select the “Support Multi-Monitor Next to continue. System” option. Click Next to continue. KP-5362 Fanless POS Terminal 19 ...
  • Page 24 Select the Destination Folder or use h. Type a Folder name or use the the default one listed. default one listed. Click Next to continue. i. A progress window appears. Please j. Click Yes. The installation wait. completes in seconds. KP-5362 Fanless POS Terminal  20 ...

  • Page 25: Chapter 4 Board Setting

    6. Reset your desired password or clear the CMOS data. JPC1/3/4/5/6: Voltage Switch jumper for JCOM1/3/4/5/6 ports This header is for controlling the Pin9 of COM ports to switch Ring/ 5V/12V. Pin 5-6 Pin 1-2 Close: Close: Pin9=12V Pin9=5V Pin 3-4 Close: Pin9=Ring (Default) KP-5362 Fanless POS Terminal 21 ...
  • Page 26 Max output: 12V@500mA for each COM port JCOM2: Serial Port Connector Assignment COM2_RI COM2C_DSR COM2C_TXD COM2C_RXD COM2C_RTS COM2C_CTS COM2C_DTR ATTENTION To avoid system malfunctions, DO NOT change the default setting by yourself. Contact your dealer for assistance if needed. KP-5362 Fanless POS Terminal  22 ...

  • Page 27: Chapter 5 Bios Setup

    General Help Navigation Keys for that particular menu are at the Navigation Keys bottom right corner, and you can use these keys to select item and change the settings. KP-5362 Fanless POS Terminal 23 ...

  • Page 28: Main Menu

    AMI BIOS Shows system information including BIOS version, built date, etc. Total Memory Shows the system memory size, VGA shard memory will be excluded.. System Time Set the system internal clock. KP-5362 Fanless POS Terminal  24 ...

  • Page 29: Advanced Menu

    This item m allows y you to en able or d isable Bo ot Option n for Lega acy Mass Storage Devices with Opti on ROM. Options: Enabl ed (Defau ult) / Disa abled KP-5362 Fa anless POS S Terminal...
  • Page 30 Disabled (Default) / Enabled PERR# Generation This item enables or disables PCI Device to generate PERR#. Options: Disabled (Default) / Enabled SERR# Generation This item enables or disables PCI Device to generate SERR#. Options: Disabled (Default) / Enabled KP-5362 Fanless POS Terminal  26 ...
  • Page 31 This item enables or disables Lock of Legacy Resources. Options: Disabled (Default) / Enabled PME Wake up from S5 The item enables the system to wake from S5 using PME event. Options: Disabled (Default) / Enabled KP-5362 Fanless POS Terminal 27 ...
  • Page 32 When EuP is enabled, the system will meet EuP requirement. Options: Disabled (Default) / Enabled Ring-In Wake up from S5 This item enables the system to wake from S5 using Ring-In event. Options: Disabled (Default) / Enabled KP-5362 Fanless POS Terminal  28 ...
  • Page 33 Before it can do so, it must first query the processor to find out the highest input value CPUID recognizes. This determines the kind of basic information CPUID can provide the operating system. Options: Disabled (Default) / Enabled KP-5362 Fanless POS Terminal 29 ...

  • Page 34: Sata Configuration

    Options: Enabled (Default) / Disabled Configure SATA as This item selects a configuration for SATA controller. Options: IDE (Default) / AHCI SATA Port1 Options: Enabled (Default) / Disabled SATA Port2 Options: Enabled (Default) / Disabled KP-5362 Fanless POS Terminal  30 ...
  • Page 35 Microsoft DOS or Windows NT). Options: Enabled (Default) / Disabled / Auto EHCI Hand-Off This is a workaround for OSes without EHCI hand-off support. The EHCI ownership change should be claimed by EHCI driver. Options: Disabled (Default) / Enabled KP-5362 Fanless POS Terminal 31 ...
  • Page 36 Host Controller. Options: Auto (Default) / Manual Note: The following item appears only when you set the Device power-up delay item to [Manual] Device power-up delay in Second Options: 5 (Default) / 1 ~ 40 KP-5362 Fanless POS Terminal  32 ...
  • Page 37 RPM. FAN Ctrl ON(℃):When temperature is higher than this value,the fan controller will turn on. FAN Ctrl Start Value:Set FAN Start Speed Value. FAN Ctrl Sensltive:SMART FAN Control. Options: Quiet / Aggressive / Manual(Default) KP-5362 Fanless POS Terminal 33 ...

  • Page 38: Super Io Configuration

    BIOS SETUP Super IO Configuration KP-5362 Fanless POS Terminal  34 ...
  • Page 39 10, 11, 12 / IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12 / IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12 / IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12 KP-5362 Fanless POS Terminal 35 ...
  • Page 40 10, 11, 12 / IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12 / IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12 / IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12 KP-5362 Fanless POS Terminal  36 ...
  • Page 41 Standard Printer Port) / EPP Mode (Using Parallel Port as Enhanced Parallel Port) / ECP Mode (Using Parallel port as Extended Capabilities Port) / EPP Mode & ECP Mode (Using Parallel port as ECP & EPP mode) KP-5362 Fanless POS Terminal 37 ...
  • Page 42 Power Off (Default) / Power On / Last State Watch Dog Degree This item allows you to determine the functional degree of Watch Dog. Options: Second (Default) / Minute Watch Dog Timer Options: 0 for disabled (Default) / Min=1, Max=65536 H/W Monitor KP-5362 Fanless POS Terminal  38 ...
  • Page 43 BIOS SETUP F81216 Second Super IO Configuration KP-5362 Fanless POS Terminal 39 ...
  • Page 44 This item enables or disables Serial Port (COM). Options: Enabled (Default) / Disabled Change Settings This item allows you to select an optimal setting for Super IO device. Options: IO=3E8h; IRQ=5 (Default) / IO=2E8h; IRQ=5 / IO=2F0h; IRQ=5 / IO=2E0h; IRQ=5 KP-5362 Fanless POS Terminal  40 ...
  • Page 45 This item enables or disables Serial Port (COM). Options: Enabled (Default) / Disabled Change Settings This item allows you to select an optimal setting for Super IO device. Options: IO=2E8h; IRQ=5 (Default) / IO=3E8h; IRQ=5 / IO=2F0h; IRQ=5 / IO=2E0h; IRQ=5 KP-5362 Fanless POS Terminal 41 ...
  • Page 46 This item enables or disables Serial Port (COM). Options: Enabled (Default) / Disabled Change Settings This item allows you to select an optimal setting for Super IO device. Options: IO=2F0h; IRQ=5 (Default) / IO=3E8h; IRQ=5 / IO=2E8h; IRQ=5 / IO=2E0h; IRQ=5 KP-5362 Fanless POS Terminal  42 ...
  • Page 47 IO=2E0h; IRQ=5 (Default) / IO=3E8h; IRQ=5 / IO=2E8h; IRQ=5 / IO=2F0h; IRQ=5 / UART IRQ Mode This item allows you to determine the PCI IRQ Sharing for OS (ex. Windows) or ISA IRQ for DOS. Options: PCI IRQ Sharing (Default) / ISA IRQ KP-5362 Fanless POS Terminal 43 ...
  • Page 48 / Slo C-state POPDOW When n this item m is disabl ed, it prev vents aut tomatic re eturn to a previous s C3 or C4 state. Optio nabled (D Default) / Disabled C-state POPUP KP-5362 Fa anless POS Terminal 44 ...

  • Page 49: Chipset Menu

    Notice Bewa re of that t setting i inappropr riate valu es in item ms of this s menu m may cause system m to malf function. KP-5362 Fa anless POS S Terminal...
  • Page 50 BIOS SETUP Host Bridge KP-5362 Fanless POS Terminal  46 ...
  • Page 51 TOLUD automatically based on largest MMIO length of installed graphic controller. Options: Dynamic (Default) / 1 GB / 1.25 GB / 1.5 GB / 1.75 GB / 2 GB / 2.25 GB / 2.5 GB / 2.75 GB / 3 GB / 3.25 GB KP-5362 Fanless POS Terminal 47 ...
  • Page 52 Auto (Default) / Force Scaling / Off / 1Maintain Aspect Ratio Active LVDS This item selects the Active LVDS Configuration. No LVDS: VBIOS does not enable LVDS; Int-LVDS: VBIOS enables LVDS driver by Integrated encoder. Options: Int-LVDS (Default) / No LVDS KP-5362 Fanless POS Terminal  48 ...
  • Page 53 B B IOS SETUP Fixed G raphics Memory Size This item m configu res the Fi ixed Grap phics Mem mory Size. Options: 128M B (Defau lt) / 256M South B Bridge KP-5362 Fa anless POS S Terminal...
  • Page 54 (Defa ault) / By y Ports UHCI # 1 (ports 0 and 1 ) / UHCI I #2 (po orts 2 and d 3) / UH HCI #3 ( (ports 4 and 5) / KP-5362 Fa anless POS Terminal 50 ...
  • Page 55 This item enables or disables the High Precision Event Timer. Options: Enabled (Default) / Disabled SLP_S4 Assertion Width This item selects a minimum assertion width of the SLP_S4# signal. Options: 1-2 Seconds (Default) / 2-3 Seconds / 3-4 Seconds / 4-5 Seconds KP-5362 Fanless POS Terminal 51 ...

  • Page 56: Boot Menu

    ALWAYS – it doesn’t allow disabling the GA20; this option is useful when any code is executed above 1MB. Options: Upon Request (Default) / Always Option ROM Messages This item can set the display mode for Option ROM. Options: Force BIOS (Default) / Keep Current KP-5362 Fanless POS Terminal  52 ...
  • Page 57 The BIOS will attempt to arrange the hard disk boot sequence automatically. can also change the booting sequence. The number of device items that appears on the screen depends on the number of devices installed in the system.   KP-5362 Fanless POS Terminal 53 ...

  • Page 58: Security Menu

    BIOS SETUP 5.5 SECURITY MENU This menu allows you to provide/revise supervisor and user password. Administrator Password This item sets Administrator Password. User Password This item sets User Password.   KP-5362 Fanless POS Terminal  54 ...

  • Page 59: Exit Menu

    Boot Ov verride This item m allows y you to ex it the sys stem setu p without t saving a any chang ges. KP-5362 Fa anless POS S Terminal...

  • Page 60: Bios Setup Program Function Keys

    <Enter>: Exits the menu, saves changes, and boots from the selected device <Esc>: Exits the menu without saving changes ATTENTION To avoid system malfunctions, DO NOT change the BIOS default setting by yourself. Contact your dealer for assistance if needed. KP-5362 Fanless POS Terminal  56 ...

  • Page 61: Chapter 6 Trouble Shooting

    CHAPTER 6 Trouble Shooting This chapter provides suggestions on how to locate and solve problems that may arise while using your KP-5362. If you cannot solve a problem with the following information, contact your dealer for further assistance. With the power on, there is no image on the terminal screen.
  • Page 62 Press <F9> during POST to load the default configuration values for the current menu. NOTE: If the problem goes beyond the scope of this manual or remains unresolved, DO NOT repair it by yourself, contact your dealer for assistance. KP-5362 Fanless POS Terminal  58 ...
